Powerdot Device & Accessories - PowerDot Uno Instruction Manual

POWERDOT
DEVICE
& ACCESSORIES
Power/Stimulation
Indicator
Multifunction Button
Micro USB connector
(dual function:
connects either leads
or charging cable)
Charging Indicator
Female magnetic
connector
Lead cable with two
female magnetic
connectors
Rectangular pad
with male magnetic
connector
Round pad with male
magnetic connector
10
POWER/STIMULATION
INDICATOR :
Can be either WHITE (when
PowerDot is on or on standby mode)
or ORANGE (when it's being used for
stimulation).
MULTIFUNCTION BUTTON
MODES :
The touch-enabled Multifunction Button
carries out these PowerDot functions:
Multifunction PowerDot PowerDot Re-
Button Action Initial State sulting State
PowerDot is
Hold for ~1 PowerDot is
now ON (white
second OFF (no lights)
light is on)
PowerDot is PowerDot is
Hold for ~1
ON (white light now OFF
second
is on) (no lights)
PowerDot is Stimulation
in Stimulation stops
Quick Click
(orange light (orange light
is on) is on)
Full Factory
Reset: acti-
vation lock
is released,
Hold for 5
Device is ON Power LED
seconds
blinks several
times, and
the PowerDot
becomes OFF
Soft Reset:
Activation lock
Hold for 3 is released,
Device is OFF
seconds Power LED
blinks several
time
PowerDot
stimulation has
been manually
Quick Double or program-
the
Click matically
suspended
(white light is
ON)
MICRO-USB CONNECTOR
PowerDot PD-01M uses the same high
voltage micro-USB connector (3) for lead
cable connection and for charging.
If the device is being used for stimulation,
it will immediately stop once the lead
cables are disconnected from the micro-
USB connector.
CHARGING INDICATOR
While the device is still charging, you will
see the ORANGE Charging Indicator (4)
next to the micro-USB charging connector.
Refer to the Recharging
section below for more information on
PowerDot PD-01M charging.
MAGNETIC CONNECTOR
Used to attach and hold the PowerDot
PD-01M device in place on the rectangular
pad.
LEAD CABLE :
For an easier, more
PowerDot stimulation, two lead cables of
different lengths (10 cm and 30 cm) (6)
are provided with each PowerDot PD-
11
Manually
resumed stim-
ulation session
(orange light
is ON)
:
:
PowerDot
:
comfortable
