Table of Contents
Safety
Instructions......................................................
Assembly Instructions:
Assembly Instructions:
SAFETY INSTRUCTIONS
WARNING: Read and understand these instructions before assembling the
shed.
• DO NOT attempt to assemble/install this product until you read and
understand the entire owner's manual. All persons who will install, use, or
care for this product must be familiar with this material.
Ensure that all labeling applied to the shed is in place and legible.
• DO NOT modify the unit without the manufacturer's approval. Unapproved
modifications automatically void the limited warranty (p. 19), and might
make the shed unsafe to use.
• Maintenance and repairs are to be done only by personnel qualified to
perform the required work. Consideration will not be given for warranty
repair charges without prior written authorization by the manufacturer.
STOR-44-G-W-1RH
STOR-612-G-W-1RH
TABLE OF CONTENTS
M
C
.
ANUFACTURING
ORP
STOR-44/66/96..................
STOR-612/912...................
STOR-96-G-W-1RH
Copyright 2021 Vestil Manufacturing
Page
1 Exploded
Views........................................................
2-5 Limited
Warranty....................................................
6-12
STOR-66-G-W-1RH
O
WNER
M
ANUAL
Table of Contents
R
I
ECEIVING
NSTRUCTIONS
It is possible that this product
could
incur
damage
transit.
Inspect the unit closely when
it arrives.
If you see evidence
of damage or rough handling to
either the packaging or to the
product
when
unloaded, immediately make a
note of it on the Bill Of Lading!
It
is
important
remove the product's packaging
upon its arrival to ensure that
there is no concealed damage
or to enable a timely claim with
the carrier for freight damage.
Also verify that the product
and its specifications are as
ordered.
T
R
OOLS
EQUIRED
-7/16" socket or wrench
-1/2" socket or wrench
-5/16" nut driver for drill
-Level
-Eye/Hand protection advised
Note – At least two people
required
to
product;
three
STOR-912-G-W-1RH
'
S
Page
13-18
19
during
it
is
being
that
you
assemble
this
suggested.
Page 1 of 19

Advertisement

loading

Summary of Contents for Vestil STOR-44-G-W-1RH

  • Page 1 ’ WNER ESTIL ANUFACTURING 2999 N. Wayne St., Angola, IN 46703 ANUAL Ph: 260-665-7586 · Fax: 260-665-1339 E-mail: info@vestil.com · Website: www.vestil.com : STOR-96-G-W-1RH & STOR-912-G-W-1RH TORAGE HED MODELS Table of Contents Page Table of Contents Page Safety Instructions……………………………………………… 1 Exploded Views…………………………………….….………...
  • Page 2 TORAGE NIT MODEL Place WOODEN FLOOR BASE on clean and level surface. Position BACK WALL SUBASSEMBLY as shown above. NOTE: Install on one of the lengthwise sides of the FLOOR BASE. Copyright 2016 Vestil Mfg. Co. Page 2 of 15...
  • Page 3 LOCK STRIP Install a CORNER LOCK STRIP on both (vertical) edges of the BACK WALL. Insert the edge of one SIDE WALL into one of the LOCK STRIPS installed in Step 4. Copyright 2016 Vestil Mfg. Co. Page 3 of 15...
  • Page 4 Install a LOCK STRIP on the free edge of both SIDE WALLS. Insert the side edges of the FRONT WALL SUBASSEMBLY into the LOCK STRIPS. Fasten FRONT WALL to the floor with ¼”x2” lag screws installed through the 5 predrilled holes in the bottom flange of each SIDE WALL. Copyright 2016 Vestil Mfg. Co. Page 4 of 15...
  • Page 5 Fasten the ROOF to the front and back walls with 8pc of 1” long self-tapping screws (part no. 31806; 4 pcs. per wall). There are no predrilled holes. Space screws evenly across both walls. Assembly is now complete. STOR-44-G-W-1RH STOR-66-G-W-1RH STOR-96-G-W-1RH Copyright 2016 Vestil Mfg. Co. Page 5 of 15...
  • Page 6 Using 20pc of 2” long wood screws fasten the plywood spacer strips directly to the 2”X4” joints. Evenly space wood screws along entire length of spacer strip. NOTE: Attach screws evenly to both 2x4’s. Copyright 2016 Vestil Mfg. Co. Page 6 of 15...
  • Page 7 ¼” x 2” lag screw (part no. 22061) – one bolt per face joint on each side for the wooden floors. Begin shed assembly with wooden floors on clean level surface. Position BACK WALL SUBASSEMBLY as shown above. Copyright 2016 Vestil Mfg. Co. Page 7 of 15...
  • Page 8 Lock strip Install a CORNER LOCK STRIP on both (vertical) side edges of the back wall. Install a SIDE WALL SUBASSEMBLY by inserting a side edge into one of the lock strips. Copyright 2016 Vestil Mfg. Co. Page 8 of 15...
  • Page 9 WALL and then install a SIDE WALL CONNECTOR (part no. 41-014-032), as seen above on right hand side. See step 13 for installation. NOTE: The concavity of the SIDE WALL CONNECTOR should face outwards. Copyright 2016 Vestil Mfg. Co. Page 9 of 15...
  • Page 10 Install a LOCK STRIP on the free end of each SIDE WALL; then insert FRONT WALL assembly into the LOCK STRIPS. Install 5pc of ¼”x2”lag screws into predrilled holes to attach the FRONT WALL to the floor. Copyright 2021 Vestil Mfg. Co. Page 10 of 15...
  • Page 11 Fasten the ROOF SEAM COVER PLATE to roof and walls with 4 self-tapping screws. (2 screws at each end of the cover plate) Copyright 2016 Vestil Mfg. Co. Page 11 of 15...
  • Page 12 Secure roof to front and back walls with 16pc 1” long self-tapping screws (4pc per side). Holes are not predrilled. Space screws evenly. Step 20 The assembly process is complete. STOR-612-G-W-IRH STOR-912-G-W-1RH TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Page 12 of 19...
  • Page 13 TABLE OF CONTENTS Rev. 8/16/2021 STOR, MANUAL STOR-44-G-W-1RH EXPLODED VIEW (41-006-065) ITEM NO. PART NUMBER DESCRIPTION QTY. 41-514-107 ASSEMBLY, FRAME, WOOD FLOOR BASE, SMALL 41-514-104 WELDMENT, FRAME, SIDING, RIGHT WALL 41-514-105 WELDMENT, FRAME, SIDING, LEFT WALL 41-514-106 WELDMENT, FRAME, SIDING, BACK WALL...
  • Page 14 41-514-095 WELDMENT, FRAME, BACK WALL SUBASSEMBLY 41-514-099 ASSEMBLY, FRAME, FRONT WALL 22061 1/4"-10 x 2" HEX HEAD LAG SCREW 41-514-100 WELDMENT, FRAME, ROOF WALL SUBASSEMBLY 31806 SCREW, SELF-TAPPING SCREW Page 14 of 19 TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing...
  • Page 15 WELDMENT, BACK WALL SUB-ASS'Y 41-514-016 WELDMENT, ROOF WALL SUB-ASS'Y 41-514-048 ASSEMBLY, FRONT WALL 41-037-003 LOCK, CORNER LOCK STRIP, FORMED 22061 1/4"-10 x 2" HEX HEAD LAG SCREW 31806 SCREW, SELF-TAPPING SCREW Page 15 of 19 TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing...
  • Page 16 WELDMENT, BACK WALL SUB-ASS'Y 41-514-016 WELDMENT, ROOF WALL SUB-ASS'Y 41-514-048 ASSEMBLY, FRONT WALL 41-037-003 LOCK, CORNER LOCK STRIP, FORMED 22061 1/4"-10 x 2" HEX HEAD LAG SCREW 31806 SCREW, SELF-TAPPING SCREW Page 16 of 19 TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing...
  • Page 17 SCREW, SELF-TAPPING SCREW 41-014-030 FRAME, FLOOR SEAM COVER PLATE, FORMED 41-014-032 FRAME, SIDE WALL CONNECTOR, FORMED 41-014-218 FRAME, ROOF SEAM ANGLE, FORMED 41-014-219 FRAME, ROOF SEAM COVER PLATE, FORMED 22061 Page 17 of 19 TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing...
  • Page 18 41-014-027 FRAME, ROOF SEAM ANGLE, FORMED 41-014-026 FRAME, ROOF SEAM COVER PLATE, FORMED 41-037-003 LOCK, CORNER LOCK STRIP, FORMED 22061 1/4"-10 x 2" HEX HEAD LAG SCREW 31806 SCREW, SELF-TAPPING SCREW 22061 Page 18 of 19 TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing...
  • Page 19 Warrantee (you) for warranty service. Who may request service? Only a warrantee may request service. You are a warrantee if you purchased the product from Vestil or from an authorized distributor AND Vestil has been fully paid.
