Galvanized Storage Cabinet, Model GCAB-4415-72
Identifier Item Description
A4
Top panel
B7
Left side panel
B8
Right side panel
C5
Left rear panel
C6
Right rear panel
D4
Shelf
E3
Front leg assembly
F3
Rear leg assembly
G1
Divider
L3
Left door
R3
Right door
I
Shelf support
#8 10mm self-tapping
J
screw
Assembly Instructions
Quantity
Product specifications:
1
1
1
Capacity per shelf = 66lbs (30kg)
1
1
Dimensions = 72in. (H) x 44in. (W) x 15in. (D)
5
1
1
Overall weight = 112lbs (~51kg)
1
1
1
30
21
~(183cm x 112cm x 38cm)
Advertisement
Related Manuals for Vestil GCAB-4415-72
Summary of Contents for Vestil GCAB-4415-72
- Page 1 Galvanized Storage Cabinet, Model GCAB-4415-72 Assembly Instructions Identifier Item Description Quantity Product specifications: Top panel Left side panel Right side panel Capacity per shelf = 66lbs (30kg) Left rear panel Right rear panel Dimensions = 72in. (H) x 44in. (W) x 15in. (D)
- Page 2 Step 1: Insert the front leg assembly (E3) and rear leg assembly (F3) into the Step 2: Install the left rear panel (C5) and then the right rear panel (C6) bottom end (has flange with 2 holes for screws) of the left side panel (B7) and [NOTE: C6 will overlap C5];...
