STOR-SERIES STORAGE SHEDS
STOR-96-G-W-1RH
STOR-912-G-W-1RH
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to
determine whether it sustained damage during transport. If damage is discovered, record a
complete description of it on the bill of lading. If the product is undamaged, discard the
packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is
used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts,
labels, and accessories, call our Technical Service and Parts Department at (260) 665-7586. The
Department can also be contacted online at https://www.vestil.com/page-parts-request.php.
Electronic Copies of Instruction Manuals
Additional
copies
https://www.vestil.com/page-manuals.php.
Words...................................................................................................................
Instructions........................................................................................................
Shed.....................................................................................................
Diagram.................................................................................................................
Warranty............................................................................................................
Table of Contents
Rev. 5/6/2025
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Web:
STOR-44-G-W-1RH
of
this
instruction
Table of Contents
Materials.................................................................................
Condition....................................................................................
Shed.................................................................................
Copyright 2025 Vestil Manufacturing Co.
Vestil Manufacturing Co.
Fax: (260) 665-1339
www.vestil.com
e-mail:
STOR-612-G-W-1RH-WD
manual
may
STOR, MANUAL
info@vestil.com
STOR-66-G-W-1RH-WD
be
downloaded
Page
2
2 - 3
3
-
15
20
20
21
22
Page 1 of 22
from
2
14
-
19
Advertisement
Table of Contents
Related Manuals for Vestil STOR Series
Summary of Contents for Vestil STOR Series
-
Page 1: Table Of Contents
For answers to questions not addressed in these instructions and to order replacement parts, labels, and accessories, call our Technical Service and Parts Department at (260) 665-7586. The Department can also be contacted online at https://www.vestil.com/page-parts-request.php. Electronic Copies of Instruction Manuals... -
Page 2: Signal Words
SAFETY INSTRUCTIONS Vestil strives to identify all foreseeable hazards associated with the use of its products. Material handling is dangerous and no manual can address every conceivable risk. Ultimately, the most effective way to prevent injury is to apply sound judgment whenever assembling, inspecting, maintaining, or using this shed. -
Page 3: Warranty
DO NOT modify the product in any way UNLESS you first obtain written approval from Vestil. Unapproved modifications automatically void the LIMITED WARRANTY on p. 22 and might make the product unsafe to use. -
Page 4: Assembling The Shed
Step 2: Position BACK WALL SUBASSEMBLY as shown above. NOTE: Install on one of the lengthwise sides of the FLOOR BASE. Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 4 of 22... - Page 5 Step 4: Install a CORNER LOCK STRIP on both (vertical) edges of the BACK WALL. Step 5: Insert the edge of one SIDE WALL into one of the LOCK STRIPS installed in Step 4. Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 5 of 22...
- Page 6 FRONT WALL SUBASSEMBLY into the LOCK STRIPS. Fasten FRONT WALL to the floor with ¼”x2” lag screw s ins tall ed throu gh the 5 predrilled holes in the bottom flange of each SIDE WALL. Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 6 of 22...
- Page 7 1” long self-tapping screws (part no. 31806; 4 pcs. per wall). There are no predrilled holes. Space screws evenly across both walls. Assembly is now complete. STOR-44-G-W-1RH STOR-66-G-W-1RH STOR-96-G-W-1RH Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 7 of 22...
- Page 8 2”X4” joints. Evenly space wood screws along entire length of spacer strip. NOTE: Attach screws evenly to both 2x4’s. Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 8 of 22...
- Page 9 Step 5: Begin shed assembly with wooden floors on clean level surface. Apply paint, stain, or varnish as desired to protect the flooring. Step 6: Position BACK WALL SUBASSEMBLY shown above. Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 9 of 22...
- Page 10 Step 8: Install a CORNER LOCK STRIP on both side edges of the back wall. Step 9: Install SIDE WALL SUBASSEMBLY by inserting a side edge into one of the lock strips. Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 10 of 22...
- Page 11 WALL CONNECTOR (part no. 41-014-032), as seen above on right hand side. See step 13 for installation. NOTE: The concavity of the SIDE WALL CONNECTOR should face outwards. Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 11 of 22...
- Page 12 SIDE WALL; then insert FRONT WALL assembly into the LOCK STRIPS. Install 5pc of ¼”x2”lag screws into predrilled holes to attach the FRONT WALL to the floor. Table of Contents Copyright 2025 Vestil Manufacturing Page 12 of 22...
- Page 13 Step 18: Step 18: Fasten the ROOF SEAM COVER PLATE to roof and walls with 4 self-tapping screws. (2 screws at each end of the cover plate). Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 13 of 22...
- Page 14 Step 19: Secure roof to front back walls with 16pc 1” long self- tapping screws (4pc per side). Holes predrilled. Space screws evenly. The assembly process is complete. Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 14 of 22...
-
Page 15: Exploded View And Bill Of Materials
¼”-10 X 2” HEX HEAD LAG SCREW, GRADE A 41-514-113 ROOF, WALL SUB-ASSEMBLY 31806 SELF-TAPPING SCREW 41-016-028 CORNER COVER BRACKET 32106 #12-24 X 7/8” DRILL & TAP SCREW Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 15 of 22... - Page 16 ¼”-10 X 2” HEX HEAD LAG SCREW, GRADE A 41-514-100 ROOF WALL SUB-ASSEMBLY 31806 SELF-TAPPING SCREW 41-016-028 CORNER COVER BRACKET 32106 #12-24 X 7/8” DRILL & TAP SCREW Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 16 of 22...
- Page 17 CORNER LOCK STRIP ¼”-10 X 2” HEX HEAD LAG SCREW, GRADE A 22061 31806 SELF-TAPPING SCREW 41-016-028 CORNER COVER BRACKET #12-24 X 7/8” DRILL & TAP SCREW 32106 Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 17 of 22...
- Page 18 FLOOR SEAM COVER PLATE 41-014-032 SIDE WALL CONNECTOR 41-014-218 ROOF SEAM ANGLE 41-014-219 ROOF SEAM COVER PLATE 41-016-028 CORNER COVER BRACKET #12-24 X 7/8” DRILL & TAP SCREW 32106 Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 18 of 22...
- Page 19 CORNER LOCK STRIP ¼”-10 X 2” HEX HEAD LAG SCREW, GRADE A 22061 31806 SELF-TAPPING SCREW #12-24 X 7/8” DRILL & TAP SCREW 32106 41-016-028 CORNER COVER BRACKET Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 19 of 22...
-
Page 20: Inspecting & Maintaining The Shed
If rusting is purely superficial, remove the rust/corrosion. Clean the affected area and apply touchup paint. If rusting, rot, or thinning has weakened the material, contact TECHNICAL SERVICE for advice. Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 20 of 22... -
Page 21: Labeling Diagram
Replace all labels that are damaged, missing, or not easily readable (e.g. faded). To order replacement labels, contact the technical service and parts department online at https://www.vestil.com/page-parts-request.php. Alternatively, you may request replacement parts and/or service by calling (260) 665-7586 and asking the... -
Page 22: Limited Warranty
After Vestil receives your request for warranty service, an authorized representative will contact you to determine whether your claim is covered by the warranty. Before providing warranty service, Vestil will require you to send the entire product, or just the defective part (or parts), to its facility in Angola, IN.
