- Page 1 INSTALLATION DATA MANUAL MODEL 544 PRESSURE TRANSMITTER 199 Fire Tower Drive Tonawanda, NY 14150 Int’l: 1-716-629-3800 Toll Free: 1-800-688-0030 Fax: 1-716-693-9162 www.viatran.com solutions@viatran.com 98MANAL544 Rev. C 3/21/17...
- Page 2 INSTALLATION REQUIREMENTS AND CAUTIONS 1. All electrical and pressure connections should be compatible with the above specifications. 2. The Model 544 is susceptible to sensor damage by being dropped, struck, or installed in a high vibration environment. 3. Due to the effects of gravity on oil fill of the sensor, it is recommended that the product be mounted as shown above.
- Page 3 98MANAL544 Rev. C 3/21/17...
- Page 4 NSR calibration. NSR EXAMPLE You have Viatran’s Model 544 with a standard range of 0 to 100 PSI. You would like to set an NSR of 0 to 50 PSI. Refer to the Performance Certificate and obtain the following: Zero = 0 PSI = 4.00 mA...
- Page 5 If a product is perceived to be exhibiting problems, it can be returned to Viatran for analysis and/or repair. It is suggested that only Viatran personnel attempt repair of the product. Any damage resulting from customer disassembly would result in a loss of coverage under the warranty policy.
