- Page 1 INSTALLATION DATA MANUAL Model 517, LP717, WW517 & 817 Pressure Transmitters 3829 Forest Parkway, Suite 500 Wheatfield, NY 14120 Int’l: 1-716-629-3800 Toll Free: 1-800-688-0030 Fax: 1-716-693-9162 www.viatran.com solutions@viatran.com 98MANALX17 Rev. A 6/23/10 Page 1...
- Page 2 The output is model dependent. The model 817 has a 0-50 or 0-100 mV output signal (range dependent), the 517 and WW517 provides an amplified current output signal of 4-20mA and the LP717 has a standard 0-4 VDC output signal.
- Page 3 When shipped in quantities, units should be packaged individually to eliminate possible damage. DIMENSIONAL DRAWINGS - VIATRAN MODEL 517/LP717/817 Note: The drawing below is for informational purposes only and is not to scale. All dimensions are nominal, in inches and for reference purposes only.
- Page 4 Mechanical Installation: Models 517, LP717 and 817 are generally suspended directly into the media. An optional nose cone can be ordered to replace the standard cap for hanging weights on the unit to prevent movement. It is recommended that the weight be limited to a maximum of two pounds.
- Page 5 If a product is perceived to be exhibiting problems, it can be returned to Viatran for analysis and/or repair. It is suggested that only Viatran personnel attempt repair of the product. Any damage resulting from customer disassembly would result in a loss of coverage under the warranty policy.
