- Page 1 INSTALLATION DATA MANUAL MODEL 118/218/318 PRESSURE TRANSMITTER 3829 Forest Parkway, Suite 500 Wheatfield, NY 14120 Int’l: 1-716-629-3800 Toll Free: 1-800-688-0030 Fax: 1-716-693-9162 www.viatran.com solutions@viatran.com 98MANALX18 Rev. B 9/4/14...
- Page 2 98MANALX18 Rev. B 9/4/14...
- Page 3 External shunt calibration is achieved by placing the specified resistor across Pins 2 and 4 of the electrical connector. The value of the resistor is listed on the Performance Certificate. Internal shunt calibration is optional on the Model 118. Units with internal shunt calibration have a 6 pin connector.
- Page 4 If a product is perceived to be exhibiting problems, it can be returned to Viatran for analysis and/or repair. It is suggested that only Viatran personnel attempt repair of the product. Any damage resulting from customer disassembly would result in a loss of coverage under the warranty policy.
