Viatran IDP10-A Installation, Calibration And Operations Manual

I/a series intelligent differential pressure transmitters
Hide thumbs
Table of Contents

Advertisement

Quick Links

I/A Series ® Intelligent
Differential Pressure Transmitters
IDP10-A with 4 to 20 mA Output Signal
IDP10-V with 1 to 5 VDC Output Signal
Installation, Calibration, Configuration, and Maintenance
3829 Forest Parkway, Suite 500
Toll Free: 1-800-688-0030
Wheatfield, NY 14120
Int'l: 1-716-629-3800
Fax: 1-716-693-9162
www.viatran.com
solutions@viatran.com
[1]
98MANALIDP10AV Rev. A 8/16/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDP10-A and is the answer not in the manual?

Questions and answers

Related Manuals for Viatran IDP10-A

Summary of Contents for Viatran IDP10-A

  • Page 1 I/A Series ® Intelligent Differential Pressure Transmitters IDP10-A with 4 to 20 mA Output Signal IDP10-V with 1 to 5 VDC Output Signal Installation, Calibration, Configuration, and Maintenance 3829 Forest Parkway, Suite 500 Wheatfield, NY 14120 Int’l: 1-716-629-3800 Toll Free: 1-800-688-0030 Fax: 1-716-693-9162 www.viatran.com...

  • Page 2: Table Of Contents

    Filling System with Seal Liquid ....................... 17 Positioning Housing ........................17 Positioning Display ......................... 17 Cover Locks ............................ 18 Transmitter Wiring for IDP10-A ..................... 18 Accessing Transmitter Field Terminals ................19 Wiring the Transmitter to a Control Loop ................ 20 Putting Transmitter into Operation ....................22 Taking the Transmitter Out of Operation ..................
  • Page 3 Zero Adjustment Using External Zero Button ..............38 Configuration ........................38 IDP10-A and IDP10-V Configuration ................40 Re-ranging and IDP10-A or IDP10-V Transmitter ............42 IDP10-A and IDP10-V Character Lists ................43 Testing the Display ......................... 44 Error Messages ..........................45 4.

  • Page 4: Figures

    Figures 1 Transmitter Identification ........................6 Minimum Allowable Absolute Pressure vs. Process Temperature w/Fluorinert Fill Fluid ....9 Process Mounted Transmitter ......................13 Mounting Transmitter to a Pipe or Surface ..................14 Example of Horizontal Process Line Installation ................. 16 Example of Vertical Process Line Installation ..................

  • Page 5: Tables

    Tables 1 Electrical Safety Specifications ......................11 2 Calibration Menu ........................... 36 3 IDP10-A and IDP10-V Configuration Menu ................... 38 4 Alphanumeric Character List ......................... 43 5 Numeric Character List .......................... 43 6 Error Messages ............................45 98MANALIDP10AV Rev. A 8/16/11...

  • Page 6: Introduction

    4 to 20 mA or 1to 5 VDC signal proportional to differential pressure or to the square root of differential pressure. The measurement signal for the IDP10-A is transmitted to remote receivers over the same two wires that supply power to the transmitter electronics.

  • Page 7: Standard Specification

    Standard Specifications Span and Range Limits Span Limits Range Limits Span Limit ∆P ∆P Code 0.12 and 7.5 kPa (0.5 and 30 inH2O) -7.5 and +7.5 kPa (-30 and +30 inH2O) 0.87 and 50 kPa (3.5 and 200 inH2O) -50 and +50 kPa (-200 and +200 inH2O) 7.0 and 210 kPa (28 and 840 inH2O) -210 and +210 kPa (-840 and +840 H2O) 0.07 and 2.1 MPa (10 and 300 psi)
  • Page 8 -7 and +82°C (20 and 180°F) Electronics Temperature With LCD Display -40 and +85°C (-40 and +185°F)(a) Relative Humidity 0 and 100% Supply Voltage IDP10-A 11.5 and 42 VDC(b) IDP10-V 9 to 15.5 VDC Output Load IDP10-A 0 and 1450 Ohms...
  • Page 9 Supply Current Power supply must be capable of providing 22 mA current for the IDP10-A and 3 mA current for the IDP10-V. Ripple of up to 2 V pp (50/60/100/120 Hz) is tolerable, but instantaneous voltage must remain within specified range.

  • Page 10: Product Safety Specifications

    Test Points The banana plug receptacles (designated CAL) can be used to check transmitter output of the IDP10-A. Measurements should be 100 to 500 mV dc for 0 to 100% transmitter output. Refer to Figure 9. HHT Terminals As the top terminal is blocked, this transmitter does not communicate with the HHT, PC10, PC20, HART Communicator, or IFDC.

  • Page 11: Electrical Safety Specifications

    1. These transmitters have been designed to meet the electrical safety description listed in Table 1. For detailed information or status of testing laboratory approvals and certifications, contact Viatran. 2. Wiring restrictions required to maintain electrical certification of the transmitter are provided in the “Transmitter Wiring”...

  • Page 12: Installation

    2. Installation The following material provides information and procedures for installing the IDP10-A and IDP10-V Differential Pressure Cell Transmitter. CAUTION To avoid damage to the transmitter sensor, do not use any impact devices, such as an impact wrench or stamping device, on the transmitter.

  • Page 13: Process Mounted Transmitter

    Process-Mounted Transmitter Figure 3 shows the transmitter mounted to and supported by the process piping. Pipe or Surface Mounted Transmitter To mount the transmitter to a pipe or surface, use the Optional Mounting Set (Model Code Option -M). Referring to Figure 4, secure the mounting bracket to the transmitter using the two screws pro- vided.
  • Page 14 [14] 98MANALIDP10AV Rev. A 8/16/11...

  • Page 15: Installation Of Flow Measurement Piping

    4. For gas flow without a seal liquid, the transmitter should be mounted above the pressure connections at the pipe; for gas flow with a seal liquid, the transmitter should be mounted below the pressure connections. 5. Viatran recommends the use of snubbers in installations prone to high levels of flow pulsations. [15]...
  • Page 16 [16] 98MANALIDP10AV Rev. A 8/16/11...

  • Page 17: Filling System With Seal Liquid

    Filling System with Seal Liquid If the process fluid being measured must not come in contact with the transmitter, the transmitter lines must be filled with a suitable seal liquid. The procedure to do this is as follows: 1. If the transmitter is in service, follow the procedure for “Taking the Transmitter Out of Operation”...

  • Page 18: Cover Locks

    Electronic housing cover locks, shown in Figure 8, are provided as standard with certain agency certifications and as part of the Custody Transfer Lock and Seal option. Transmitter Wiring for IDP10-A (4-20 mA Output Signal) The installation and wiring of your transmitter must conform to local code requirements.

  • Page 19: Accessing Transmitter Field Terminals

    NOTE Viatran recommends the use of transient/surge protection in installations prone to high levels of electrical transients and surges. Accessing Transmitter Field Terminals For access to the field terminals, thread the cover lock (if present) into the housing to clear the threaded cover and remove the cover from the field terminals compartment as shown in Figure 8.

  • Page 20: Wiring The Transmitter To A Control Loop

    Wiring the Transmitter to a Control Loop When wiring your transmitter, the supply voltage and loop load must be within specified limits. The supply voltage vs. the output load relationship is shown in Figure 10. Any combination of supply voltage and loop load resistance in the shaded area can be used. To determine the loop load resistance (transmitter output load), add the series resistance of each component in the loop, excluding the transmitter.
  • Page 21 ground the shield at the transmitter. Cut and/or tape the shield so it cannot contact the metal housing. 4. Plug unused conduit connection with the PG 13.5 or 1/2 NPT metal plug provided (or equivalent). To maintain specified explosion proof and dust-ignition proof protection, plug must engage a minimum of five full threads.

  • Page 22: Putting Transmitter Into Operation

    Putting Transmitter into Operation The following procedure explains how to sequence the valves in your flow measurement piping or optional bypass manifold to ensure that your transmitter is not over-ranged and that seal liquid is not lost. Refer to Figure 5 or Figure 6. NOTE Procedure assumes that Process shutoff valves are open.

  • Page 23: Transmitter Wiring For Idp10-V

    Transmitter Wiring for IDP10-V (1-5 VDC Output Signal) The field terminals on a transmitter with a 1 to 5 V dc output signal are shown in Figure 13. The transmitter is equipped with an internal ground connection within the field wiring compartment and an external ground connection at the base of the electronics housing.

  • Page 24: Four-Wire Connection

    For wiring runs with high resistance due to long lengths or other reasons, or for maximum accuracy, a four-wire connection as shown in Figure 15 can be used to provide input-output isolation. With four-wire configuration, voltage drop in the power supply loop does not affect measurement accuracy.

  • Page 25: Wiring To A Control Loop

    The setup with multiple transmitters connected to a single power supply is shown in Figure 17. 9. For installations with long runs, Viatran recommends using two twisted pair with one pair connected to the power supply terminals and one pair connected to the output terminals.
  • Page 26 [26] 98MANALIDP10AV Rev. A 8/16/11...

  • Page 27: Putting Transmitter Into Operation

    Putting Transmitter into Operation The following procedure explains how to sequence the valves in your flow measurement piping or optional bypass manifold to ensure that your transmitter is not over-ranged and that seal liquid is not lost. Refer to Figure 5 or Figure 6. NOTE Procedure assumes that Process shutoff valves are open.

  • Page 28: Calibration And Configuration

    NOTE The IDP10-A and IDP10-V transmitters can be re-ranged to a new calibrated range without application of pressure. See EGU LRV and EGU URV in Figure 24.
  • Page 29 The pressure source can be connected to the transmitter process connection with pipe fittings or it can be connected to the vent screw assembly using a calibration screw. The calibration screw has a Polyflo fitting and can be used for pressures up to 700 kPa (100 psi). It is available from Viatran. NOTE...

  • Page 30: Bench Calibration Setup

    Bench Calibration Setup The bench calibration setup requires disconnecting the process piping. For calibration setup with- out disconnecting the process piping, refer to the “Field Calibration Setup” procedure. The input setup is shown in Figure 20. Connect the input piping to the high pressure side of the transmitter as shown.

  • Page 31: General Calibration Setup

    NOTE For vacuum applications, connect the calibrating pressure source to the low pressure side of the transmitter. Also connect electronic equipment as shown in Figure 19 . General Calibration Setup 1. Each transmitter is factory characterized over its full rated differential pressure range. One benefit of this process is that every transmitter can measure any applied differential pressure within its range limits regardless of the calibrated range.

  • Page 32: Notes For Electronic Version -A And -V

    3. Each transmitter is factory calibrated to either a specified or a default calibrated range. This calibration optimizes the accuracy of the internal digital value of differential pressure over that range. If no range is specified, the default range is zero to the sensor upper range limit (URL).
  • Page 33 3. LCD Indicator The display can show any measured differential pressure in selected units regardless of the calibrated range and the values of LRV and URV (within the limits of the transmitter and display). The display can also be 0 to 100 percent. If the measured differential pressure is outside the range established by the LRV and URV values in the database, the display shows the measurement but also continually blinks to indicate that the measurement is out of range.

  • Page 34: Calibration And Configuration Using The Local Display

    When zeroing the transmitter, the internal digital value of the differential pressure is trimmed to be equal to zero and the mA output (VDC for IDP10-V) set to an appropriate value such that the mA output (VDC for IDP10-V) is a nominal 4 mA (1 VDC for IDP10-V) when the LRV pressure is applied later.
  • Page 35 [35] 98MANALIDP10AV Rev. A 8/16/11...

  • Page 36: Calibration

    2. The IDP10-A transmitter can be re-ranged without the application of pressure. See EGU LRV and EGU URV in Figure 24. Proceed to calibrate your transmitter by using the Next key to select your item and the Enter key to specify your selection per Figure 23.

  • Page 37: Idp10-A And Idp10-V Calibration

    IDP10-A and IDP10-V Calibration [37] 98MANALIDP10AV Rev. A 8/16/11...

  • Page 38: Zero Adjustment Using External Zero Button

    Enter button. The display will show the first item in the Configuration menu. You can then configure items shown in Table 3 for the IDP10-A or IDP10-V transmitter. The initial factory configuration is also given in these tables.
  • Page 39 Proceed to configure your transmitter by using the Next key to select your item and the Enter key to specify your selection per Figure 24 (IDP10-A or IDP10-V). At any point in the configuration you may Cancel your changes and return to the online mode or Save your changes.

  • Page 40: Idp10-A And Idp10-V Configuration

    IDP10-A and IDP10-V Configuration [40] 98MANALIDP10AV Rev. A 8/16/11...
  • Page 41 OUT DIR: To configure the Output Direction, go to OUT DIR with the Next button and press Enter .. Use the Next button to select FORWARD (4-20 mA for IDP10-A or 1-5 VDC for IDP10-V) or REVERSE (20-4 mA for IDP10-A or 5-1 VDC for IDP10-V) and press Enter ..

  • Page 42: Re-Ranging And Idp10-A Or Idp10-V Transmitter

    Enter. Re-ranging an IDP10-A and IDP10-V Transmitter The IDP10-A and IDP10-V Transmitter can be re-ranged without application of pressure. To do this in linear mode, just reconfigure EGU LRV and EGU URV. To re-range the transmitter being used in Square Root mode, perform the following procedure: 1.

  • Page 43: Idp10-A And Idp10-V Character Lists

    IDP10-A and IDP10-V Character Lists Table 4. Alphanumeric Character List Characters space (shown as – 0 through 9 < > A through Z (upper case) - (underscore) Table 5. Numeric Character List Characters – 0 through 9 [43] 98MANALIDP10AV Rev. A 8/16/11...

  • Page 44: Testing The Display

    Testing the Display You can access the Test Display mode by the same multi-level menu systems was used to enter Calibration and Configuration mode. Entry to the Mode Select menu is made (from normal operating mode) by pressing the button. The display reads , the first item on the Next CALIB...

  • Page 45: Error Messages

    Error Messages Table 6. Error Messages Message Interpretation OVR RNG Normalized calculation result greater than 2% above calibrated span. a. Overrange input; correct input condition. b. Bad span calibration; recalibrate span. c. Bad sensor connection; check electronics module to sensor connection. d.
  • Page 46 Table 6. Error Messages (Continued) Message Interpretation BADZERO Recalculation of offset during CAL AT0, CAL LRV , or EX ZERO resulted in out of range value. a. Applied pressure too high during operation. b. Improper calibration setup. BADSPAN Recalculation of slope during CAL URV operation resulted in out of range value. a.

  • Page 47: Maintenance

    Parts replacement is generally limited to the electronics module assembly, housing assembly, sensor assembly, terminal block assembly, and cover O-rings. For part numbers relating to the trans mitter and its options, contact Viatran. Replacing the Electronics Module To replace the electronics module assembly, proceed as follows: 1.

  • Page 48: Removing And Reinstalling The Housing Assembly

    7. Turn on transmitter power source. The module replacement procedure is now complete. NOTE The transmitter configuration is stored in the sensor assembly. Therefore, the configuration settings are retained when replacing the electronics module. Recalibration, however, is recommended. Removing and Reinstalling the Housing Assembly To remove and reinstall the housing assembly, proceed as follows: 1.

  • Page 49: Replacing The Sensor Assembly

    Figure 26. Replacing the Sensor Assembly Figure 27. Replacing the Sensor Assembly (Code 78/79 pvdf Inserts) [49] 98MANALIDP10AV Rev. A 3/23/11...

  • Page 50: Replacing The Terminal Block Assembly

    Replacing the Terminal Block Assembly 1. Turn off transmitter power source. 2. Screw in cover lock (if present) and remove the Field Terminals compartment cover by rotating it counterclockwise. 3. Remove the four socket head screws securing the terminal block. 4.
  • Page 51 To rotate the process covers, refer to Figure 7 and proceed as follows: 1. Remove the process covers from sensor by removing two hex head bolts. 2. Replace gaskets in process covers. 3. Rotate the process covers so that the longer tab is at the bottom. 4.

  • Page 52: Index

    Index Bench Calibration Setup Calibration Calibration and Configuration Calibration Notes Calibration Setup Configuration Cover Locks Electronics Module, Replacing Error Messages Field Calibration Setup Field Terminals Filling System with Seal Liquid General Description Housing Assembly, Removing and Reinstalling Identification Installation Maintenance Mounting Parts Replacement Piping...
  • Page 53 Taking Transmitter Out of Operation Terminal Block Assembly, Replacing Testing the Display Venting, Rotating Process Covers for Wiring Zero Adjustment Using External Zero Button Viatran Corporation 3829 Forest Parkway, Suite 500 Wheatfield, NY 14120 Int’l: 1-716-629-3800 Toll Free: 1-800-688-0030 Fax: 1-716-693-9162 www.viatran.com...
