Multimedia Projector
LC-WB100
MODEL
Owner's Manual
Network Supported
Wired LAN
□
100-Base-TX/10-Base-T
Refer to the Owner's Manuals below for
details about network function.
Network Set-up and Operation
□
PJ Network Manager
□

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC-WB100 and is the answer not in the manual?

Questions and answers

Related Manuals for Eiki LC-WB100

Summary of Contents for Eiki LC-WB100

  • Page 1 Multimedia Projector Network Supported LC-WB100 Wired LAN □ MODEL 100-Base-TX/10-Base-T Refer to the Owner's Manuals below for details about network function. Network Set-up and Operation □ PJ Network Manager □ Owner’s Manual...

  • Page 2: Features And Design

    Features and Design This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. ♦ ♦ Compact Design Security Function This projector is designed compact in size and weight. The Security function helps you to ensure security of the projector. With the Key lock function, you can It is easy to carry and installed anywhere you wish to lock the operation on the top control or remote control use. (p.54). PIN code lock function prevents unauthorized ♦ use of the projector (pp.19, 56-57). Simple Computer System Setting The projector has the Multi-scan system to conform to ♦ Helpful Maintenance Functions almost all computer output signals quickly (p.29). Up to Lamp and filter maintenance functions provide for UXGA resolution can be accepted. better and proper maintenance of the projector. ♦ Useful Functions for Presentations ♦ LAN Network Function - The digital zoom function allows you to focus on the This projector is loaded with the Wired LAN network...

  • Page 3: Table Of Contents

    Table of Contents Auto PC adjustment Features and Design . . . . . . . . . . . . . . . . . . . Manual PC adjustment Table of Contents .

  • Page 4: To The Owner

    To the Owner Before installing and operating this projector, read this Safety Precaution manual thoroughly. This projector provides many convenient features and ● WARNING: THIS APPARATUS MUST BE EARTHED . functions. Operating the projector properly enables ● TO REDUCE THE RISK OF FIRE OR you to manage those features and maintains it in good ELECTRIC SHOCK, DO NOT EXPOSE THIS condition for many years to come.

  • Page 5: Safety Instructions

    Safety Instructions All the safety and operating instructions should be read Do not install the projector near the ventilation duct of before the product is operated. air-conditioning equipment. Read all of the instructions given here and retain them This projector should be operated only from the type for later use. Unplug this projector from AC power supply of power source indicated on the marking label. If you before cleaning. Do not use liquid or aerosol cleaners. are not sure of the type of power supplied, consult your Use a damp cloth for cleaning. authorized dealer or local power company. Follow all warnings and instructions marked on the Do not overload wall outlets and extension cords as this projector. can result in fire or electric shock. Do not allow anything to rest on the power cord. Do not locate this projector For added protection to the projector during a lightning where the cord may be damaged by persons walking on storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet. This will prevent damage due to lightning and power line surges. Do not attempt to service this projector yourself as opening or removing Covers may expose you to dangerous voltage or other hazards. Refer all servicing Do not expose this unit to rain or use near water... for to qualified service personnel. example, in a wet basement, near a swimming pool, etc... Unplug this projector from wall outlet and refer servicing Do not use attachments not recommended by the to qualified service personnel under the following manufacturer as they may cause hazards.

  • Page 6: Air Circulation

    Safety Instructions Installing the Projector in Proper Position Air Circulation Openings in the cabinet are provided for ventilation. To Install the projector properly. Improper Installation may reduce the lamp life and cause a fire hazard. ensure reliable operation of the product and to protect it from overheating, these openings must not be blocked Do not tilt the projector more than 20 or covered. 20° degrees from side to side. 20° CAUTION Do not tilt the projector more than 30 Hot air is exhausted from the exhaust vent. When using 30° degrees from above and below. or installing the projector, the following precautions 30° should be taken. – Do not put any flammable object or spray can near the Do not point the projector up to project an projector, hot air is exhausted from the air vents.

  • Page 7: Compliance

    – R eorient or relocate the receiving antenna. – I ncrease the separation between the equipment and receiver. – C onnect the equipment into an outlet on a circuit different from that to which the receiver is connected. – C onsult the dealer or an experienced radio/TV technician for help. Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of FCC Rules. Do not make any changes or modifications to the equipment unless otherwise specified in the instructions. If such changes or modifications should be made, you could be required to stop operation of the equipment. Model Number : LC-WB100 Trade Name : EIKI Responsible party : EIKI International,Inc. Address : 30251 Esperanza Rancho Santa Margarita CA 92688-2132 Telephone No. : 800-242-3454 (949-457-0200) AC Power Cord Requirement The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it. AC Power Cord for the United States and Canada: AC Power Cord used in the United States and Canada is listed by the Underwriters Laboratories (UL) and certified by the Canadian Standard Association (CSA).

  • Page 8: Part Names And Functions

    Part Names and Functions ① Infrared Remote Receiver Front ② Zoom Ring ③ Focus Ring ④ Projection Lens ⑤ Lens Cap (See page 63 for attaching.) CAUTION Do not turn on a projector with lens cap attached. High temperature from light beam may damage lens cap and result in fire hazard. ⑥ Speaker ① ② ③ ④ ⑤ ⑨ ⑦ Exhaust Vents Back ⑦ ⑧  ⑨ ⑩ ⑪ ⑫ CAUTION Hot air is exhausted from the exhaust vent. Do not put heat-sensitive objects near this side.

  • Page 9: Rear Terminal

    Part Names and Functions Rear Terminal ① ② ③ ⑤ ④ ⑨ ⑧ ⑦ ⑥ ⑩ ① CONTROL PORT ⑦ AUDIO OUT (VARIABLE) When controlling the projector with RS-232C, Connect an external audio amplifier to this jack connect the control equipment to this connector with (pp.14-16). the serial control cable. This terminal outputs sound from AUDIO IN terminal (⑧ or ⑨). ② COMPUTER IN 1 / COMPONENT IN ⑧ COMPUTER 1 / COMPUTER  AUDIO IN Connect output signal from a computer, RGB scart Connect the audio output (stereo) from a 21-pin video output or component video output to...

  • Page 10: Top Control

    Part Names and Functions Top Control ⑨ ⑤ ⑧ ④ ⑦ ③ ② ① ⑥ ① SELECT button ⑦ AUTO SETUP button – E xecute the selected item (p.21). Execute the setting of Auto setup (includes Input – E xpand or compress the image in the Digital zoom search, Auto PC adj. and Auto Keystone functions) mode (p.36). in the setting menu (pp.23, 45). ② POINT ▲▼◄► (VOLUME +/–) buttons ⑧ WARNING indicator – S elect an item or adjust the value in the On-Screen – L ights red when the projector detects an abnormal Menu (p.21).

  • Page 11: Remote Control

    Part Names and Functions Remote Control ① ON/STAND-By button Turn the projector on or off. (pp.18-20) ② AUTO SET button Execute the setting of Auto setup (includes Input search, Auto PC adj. and Auto Keystone functions) in the setting menu. (pp.23, 45) ③ COMPUTER 1/ buttons Select the COMPUTER 1 or COMPUTER 2 input source. (pp.27-28, 38) ④ VIDEO button Select the VIDEO input source. (p.37) ① ② ⑤ S-VIDEO button Select the S-VIDEO input source. (p.37) ㉒ ③ ⑥ Point buttons ▲▼◄► – Select an item or adjust the value in the On-Screen Menu. (p.21) – Pan the image in the Digital zoom +/- mode. (p.36) ㉑ ④ ⑳ ⑦ SCREEN button ⑤...

  • Page 12: Remote Control Battery Installation

    Part Names and Functions Remote Control Battery Installation Open the battery Install new batteries Replace the compartment lid. into the compartment. compartment lid. Two AAA size batteries For correct polarity (+ and –), be sure battery terminals are in contact with pins in compartment. To ensure safe operation, please observe the following precautions : ● Use two (2) AAA or LR03 type alkaline batteries. ● Always replace batteries in sets. ● Do not use a new battery with a used battery. ● Avoid contact with water or liquid. ● Do not expose the remote control to moisture or heat. ● Do not drop the remote control. ● If the battery has leaked on the remote control, carefully wipe the case clean and install new batteries. ● Risk of an explosion if battery is replaced by an incorrect type. ● Dispose of used batteries according to the instructions or your local disposal rule or guidelines.

  • Page 13: Installation

    Installation Positioning the Projector For projector positioning, see the figures below. The projector should be set perpendicularly to the plane of the screen.  Note: • The brightness in the room has a great influence on picture quality. It is recommended to limit ambient lighting in order to obtain the best image. • All measurements are approximate and may vary from the actual sizes. 49:1 25.2’(7.67m) 16.7’(5.10m) 12.5(3.82m) 186" 8.3’(2.54m) 2.4’(0.74m) 124" 93" 30" 62" 30" 3231 x 2019 4308 x 2692 6462 x 4039 646 x 404 2154 x1346 16:10 12.5’(3.82m) 16.7’(5.10m) 25.2’(7.67m) 2.4’(0.74m) 8.3’(2.54m)

  • Page 14: Connecting To A Computer

    Installation Connecting to a Computer Cables used for connection • VGA cables (Mini D-sub 15 pin) * • Audio cables • HDMI-DVI cable (*One cable is supplied; other cables are not supplied with the projector.) Monitor Output DVI output Audio Output Monitor Output /Monitor Input External Audio Equipment VGA VGA HDMI-DVI cable cable cable Audio Input Audio cable (stereo) COMPUTER IN 1 / COMPUTER IN 2 HDMI COMPONENT IN / MONITOR OUT Audio cable (stereo) AUDIO OUT (stereo) COMPUTER 1 / COMPUTER 2 AUDIO IN Note: Note: • Input sound to the COMPUTER1 /COMPUTER 2 AUDIO IN...

  • Page 15: Connecting To Video Equipment

    Installation Connecting to Video Equipment Cables used for connection • Video and Audio cable (RCA x 3) • S-Video cable • Audio cable (Cables are not supplied with the projector. ) External Audio Equipment Video and Audio Output Audio Input (Video) S-Video Output Video and audio cable Audio cable S-Video cable (stereo) AUDIO OUT (stereo) VIDEO AUDIO IN S-VIDEO Unplug the power cords of  Note: both the projector and external When the AUDIO OUT is plugged-in, the projector's built- equipment from the AC outlet in speaker is not available. before connecting cables.

  • Page 16: Connecting To Component Video Equipment

    Installation Connecting to Component Video Equipment Cables used for connection • Audio cables • Scart-VGA cable • HDMI cable • Component cable • Component-VGA Cable (Cables are not supplied with this projector.) RGB Scart 21- Component Video Output pin Output (Y, Pb/Cb, Pr/Cr) Audio Output HDMI output Component cable Audio HDMI Scart-VGA cable cable cable (stereo) External Audio Equipment Component- VGA cable COMPUTER 1 / Audio Input COMPUTER 2 HDMI COMPUTER IN 1/ COMPONENT IN AUDIO IN Audio cable (stereo) AUDIO OUT...

  • Page 17: Connecting The Ac Power Cord

    Installation Connecting the AC Power Cord This projector uses nominal input voltages of 100-120 V or 200–240 V AC and it automatically selects the correct input voltage. It is designed to work with single-phase power systems having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any other type of power system. If you are not sure of the type of power being supplied, consult your authorized dealer or service station. Connect the projector with all peripheral equipment before turning the projector on. Connect the AC power cord (supplied) to the projector. CAUTION The AC outlet must be near this equipment and must be easily accessible.  Note: Unplug the AC power cord when the projector is not in use. When this projector is connected to an outlet with the AC power cord, it is in Stand-by mode and consumes a little electric power. NOTE ON THE POWER CORD AC power cord must meet requirement of the country where you use the projector. Confirm the AC plug type with the chart below and proper AC power cord must be used.

  • Page 18: Basic Operation

    Basic Operation Turning On the Projector Complete peripheral connections (with a computer, VCR, etc.) before turning on the projector. Connect the projector’s AC power cord into an AC outlet. The POWER indicator lights red. Open the lens cap (see pages 8, 63). http://www.eiki.com Press the ON/STAND-BY button on the top control or on the remote control. The POWER indicator lights The preparation display will disappear green and the cooling fans start to operate. The after 30 seconds. preparation display appears on the screen and the Selected Input Source and Lamp Control countdown starts. After the countdown, the input source that was Video Lamp control status selected the last time and the lamp control status icon (see page 55) appear on the screen. (See page 55 for Lamp control status.) If there is no signal input when start on the projector, Note: or the current signal is missed while operating the The Filter warning and Lamp replacement projector, the Video/PC selection window will be icons may appear on the screen depending displayed on the screen, please move the pointer to on the usage state of the projector. input source desired by pressing the Point ▲▼ buttons and press the SELECT button. And then follow the...

  • Page 19: Enter A Pin Code

    Basic Operation Enter a PIN code Use the Point buttons to enter a number. Press the ▲▼ PIN Code Input Dialog Box Point button to fix the number and move the red frame ► pointer to the next box. The number changes to . If you fixed an incorrect number, use the Point button to move ◄ the pointer to the number you want to correct, and then enter the correct number. Repeat this step to complete entering a four-digit number. After the OK icon disappears, you can operate the projector. After entering the four-digit number, move the pointer to Set. Press the SELECT button so that you can start to operate the projector. If you entered an incorrect PIN code, PIN code and the number () will turn red for a moment. Enter the correct PIN code all over again. What is PIN code? PIN (Personal Identification Number) code is a security code that allows the person who knows it to operate the projector. Setting a PIN code prevents unauthorized use of the projector.

  • Page 20: Turning Off The Projector

    Basic Operation Turning Off the Projector Press the ON/STAND-BY button on the top control or on the remote control, and Power off? appears on the screen. Press the ON/STAND-BY button again to turn off the projector. The POWER indicator starts to blink red, and the cooling fans keep running. (You can select the level of fans’ quietness and speed. See “Fan” on page 58.) At this time, you can unplug the AC power cord even if Power off? disappears after 4 seconds. the fans are still running. When the projector has cooled down enough, the POWER indicator stops blinking and you can turn on the projector. TO MAINTAIN THE LIFE OF THE LAMP, ONCE YOU TURN THE PROJECTOR ON, WAIT AT LEAST FIVE MINUTES BEFORE TURNING IT OFF. DO NOT OPERATE THE PROJECTOR CONTINUOUSLY WITHOUT REST. CONTINUOUS USE MAY RESULT IN SHORTENING THE LAMP LIFE. TURN OFF THE PROJECTOR AND LET STAND FOR ABOUT AN HOUR IN EVERY 24 HOURS. Note: • When the On start function is set to On, the projector will be turned on automatically by connecting the AC power cord to an AC outlet (p.53). • The running speed of cooling fans is changed according to the temperature inside the projector. • Do not put the projector in a case before the projector is cooled enough. • If the WARNING indicator blinks or lights red, see “WARNING indicator” on page 61.

  • Page 21: How To Operate The On-Screen Menu

    Basic Operation How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Top Control Menu. The menus have a hierarchical structure, with a main menu that is divided into submenus, which are further divided into other submenus. For each adjustment and setting procedure, refer to respective sections in this POINT buttons manual. (arrowhead) Press the MENU button on the top control or the SELECT button remote control to display the On-Screen Menu. Use the Point buttons to highlight or select a main ▲▼ MENU button menu item. Press the Point or the SELECT button ► to access the submenu items. (The selected item is Remote Control highlighted in orange.) POINT buttons (arrowhead) Use the Point buttons to select the desired ▲▼...

  • Page 22: Menu Bar

    Basic Operation Menu Bar For detailed functions of each menu, see “Menu Tree” on pages 70-71. Main Menu Sub-Menu           Input  Used to select an input source from Computer 1, Computer , HDMI, Video or S-video (pp.27-28,37-38). PC adjust  Select Fine sync ., Total dots, Horizontal, Vertical, Clamp, Display area H, Display area V and Auto PC adj . to adjust the parameters to match with the PC input signal format (pp.30-32).  Image select For computer source, used to select an image mode from among Dynamic, Standard, Real, Blackboard(Green), Colorboard and image 1 - 4 (p.33).

  • Page 23: Zoom And Focus Adjustment

    Basic Operation Zoom and Focus Adjustment Rotate the Zoom Ring to zoom in and out. Rotate the Focus Ring to adjust the focus of the image. Focus Ring Auto Setup Function Auto setup function is provided to automatically execute the setting of Auto setup (includes Input search, Auto PC adj. Zoom Ring and Auto Keystone functions) in the setting menu by just pressing the AUTO SETUP button on the top control or the AUTO SET button on the remote control. Refer to page 45 for the setting of the Auto setup function. Top Control AUTO SETUP button Notes: POINT ▲▼buttons • Auto Keystone corrects vertical distortion only; it does not correct horizontal distortion. • Auto Keystone cannot work when Ceiling feature is set to On in the Setting menu (p.50). • Perfect correction of the image distortion cannot be ensured with the Auto setup function. If the distortion cannot be corrected properly by pressing the AUTO Remote Control SETUP or AUTO SET button, adjust manually by pressing the KEYSTONE button on the remote control AUTO SET button or selecting Keystone in the Setting menu (p.46).

  • Page 24: Sound Adjustment

    Basic Operation Sound Adjustment Top Control Direct Operation VOLUME+/- buttons Volume Press the VOLUME+/– buttons on the top control or on the remote control to adjust the volume. The volume dialog box appears on the screen for a few seconds. Mute Remote Control Press the MUTE button on the remote control to select On to temporarily turn off the sound. To turn the sound back on, press the MUTE button again to select Off or press the VOLUME+ button VOLUME +/– buttons. The Mute function is also effective for MUTE button the AUDIO OUT jack. VOLUME- button Menu Operation Press the MENU button to display the On-Screen Menu. Use the Point buttons to select Sound. Press the ▲▼...

  • Page 25: Remote Control Operation

    Basic Operation Remote Control Operation Using the remote control for some frequently used operations is advisable. Just pressing one of the buttons enables you to make the desired operation quickly without calling up the On-Screen Menu. COMPUTER 1/, HDMI, VIDEO, S-VIDEO and Remote Control COMPONENT buttons HDMI COMPUTER 1/ Press the COMPUTER 1/2, HDMI, VIDEO, S-VIDEO and button buttons COMPONENT buttons on the remote control to select the S-VIDEO button input source. See pages 27-28,37-38 for details. COMPONENT FREEZE button VIDEO button button Press the FREEZE button on the remote control to freeze the picture on the screen. To cancel the Freeze function, POINT▲▼ press the FREEZE button again or press any other button. buttons INFO . INFO .
  • Page 26 Basic Operation NO SHOW button Press the NO SHOW button on the remote control to black out the image. To restore to normal, press the NO SHOW button again or press any other button. The screen changes each time you press the NO SHOW button as follows. black out → normal → black out → normal → • • • • • No show disappears after 4 seconds. P-TIMER button Press the P-TIMER button on the remote control. The P-Timer display 00:00 appears on the screen and the countdown starts (00:00–59:59). To stop the countdown, press the P-TIMER button. To cancel P-Timer display the P-Timer function, press the P-TIMER button again. SCREEN button IMAGE button P-TIMER button Press the IMAGE button on the remote control to select a NO SHOW button desired image mode of the screen. See pages 33, 40 for IMAGE button details. SCREEN button Select the screen size (See pages 35-36, 43 for details).  Note: See the previous page for the description of other buttons.

  • Page 27: Computer Input

    Computer Input Input Source Selection (Computer 1: RGB ) Direct Operation Choose Computer 1(RGB) by pressing the INPUT button on the top control or press the COMPUTER 1 button on the remote control. Before using INPUT button, correct input source should be selected through Menu operation as described below. Top Control Remote Control Computer 1 COMPUTER 1 button INPUT button  Computer  Computer 1(RGB) HDMI Computer 1(Scart) Video S-video  COMPUTER  can not be selected when using the COMPUTER IN 2/ MONITOR OUT terminal as MONITOR OUT output.

  • Page 28: Input Source Selection (Computer 2: Rgb)

    Computer Input Input Source Selection (Computer : RGB) Direct Operation Choose Computer (RGB) by pressing the INPUT button on the top control or press the COMPUTER 2 button on the remote control. Remote Control Top Control INPUT button COMPUTER  button Computer 1 Computer (RGB)  Computer  HDMI  COMPUTER  can not be selected when using the COMPUTER IN 2/ MONITOR OUT terminal as MONITOR OUT output. Video S-video Menu Operation Press the MENU button to display the On-Screen Input Menu Menu. Use the Point buttons to select Input and ▲▼...

  • Page 29: Computer System Selection

    Computer Input Computer System Selection This projector automatically tunes to various types of computers based on VGA, SVGA, XGA, SXGA, WXGA, UXGA or WUXGA with its Multi-scan system and Auto PC adjustment. If a computer is selected as a signal source, this projector automatically detects the signal format and tunes to project a proper image without any additional settings. (Signal formats provided in this projector are shown on pages 73-74.) One of the following messages may appear when: The projector cannot recognize the connected PC System Menu Auto signal conforming to the provided PC Systems. Auto is displayed on the System Menu box and the Auto PC adjustment function works to display proper images. If the image is not projected properly, a manual adjustment is required (pp.31-32). There is no signal input from the computer. ----- Check the connection between your computer and the projector. (See “Troubleshooting” on page 67.) The preset system is manually adjusted in the Mode 1 The PC System Menu PC adjust Menu. The adjusted data can be Selected system is stored in Mode 1–5 (pp.31-32). displayed. PC Systems provided in this projector is chosen. SVGA 1 The projector chooses a proper system provided in the projector and displays it. *Mode 1 and SVGA 1 are examples.

  • Page 30: Auto Pc Adjustment

    Computer Input Auto PC adjustment Auto PC adjustment function is provided to automatically adjust Fine sync, Total dots, Horizontal and Vertical positions to conform to your computer. Menu Operation PC adjust Menu Auto PC adj . Press the MENU button to display the On-Screen Menu. Use the Point buttons to select PC adjust ▲▼ and then press the Point ► button. Use the Point buttons to select Auto PC adj . and ▲▼ then press the SELECT button. buttons Use Point to select Auto PC ▲▼ To store adjustment parameters adj .

  • Page 31: Manual Pc Adjustment

    Computer Input Manual PC adjustment Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector. Manual PC adjustment enables you to precisely adjust several parameters to match those signal formats. The projector has five independent memory areas to store those parameters manually adjusted. It allows you to recall the setting for a specific computer. Press the MENU button to display the On-Screen PC adjust Menu Menu. Use the Point buttons to select PC adjust ▲▼ and then press the Point ► or the SELECT button. Use the Point buttons to select the desired item ▲▼ and then press the SELECT button to display the adjustment dialog box. Use the Point buttons to ◄► adjust the setting value. Fine sync . Use the Point buttons to adjust the value, eliminating a ◄► flicker from the image displayed (from 0 to 31). Total dots Use the Point buttons to adjust the number of total dots ◄► in one horizontal period to match your PC image. Horizontal Use the Point buttons to adjust the horizontal picture ◄►...
  • Page 32 Computer Input Mode free Reset To reset the adjusted data, select Reset and press the SELECT button. A confirmation box appears and then select yes. All adjustments will return to their previous figures. Mode free To clear the stored data, select Mode free and then press the Point or the SELECT button. Move the highlight to the ► Mode that you want to clear and then press the SELECT This Mode has stored button. parameters. Store To store the adjusted data, select Store and then press the Point or the SELECT button. Move the highlight to one of ► the Modes 1 to 5 in which you want to store, and then press the SELECT button. Values of Total dots, Horizontal, Vertical, Display area H, and Display area V. Vacant Store Store store Press MENU button Press SELECT button to to close this dialog...

  • Page 33: Image Mode Selection

    Computer Input Image Mode Selection Direct Operation Remote Control IMAGE button Select the desired image mode among Dynamic, Standard, Real, Blackboard (Green), Colorboard, Image 1, Image , Dynamic Image , and Image 4 by pressing the IMAGE button on the remote control. Standard Real Blackboard (Green) IMAGE button Colorboard Image 1 Image  Menu Operation Press the MENU button to display the On-Screen Image  Menu. Use the Point buttons to select Image ▲▼ or the SELECT ►...

  • Page 34: Image Adjustment

    Computer Input Image Adjustment Press the MENU button to display the On-Screen Image adjust Menu Menu. Use the Point buttons to select Image ▲▼ ► or the SELECT adjust and then press the Point button. Use the Point buttons select the desired item ▲▼ and then press the SELECT button to display the adjustment dialog box. Use the Point buttons to ◄► adjust the setting value. Contrast Press the Point button to decrease the contrast; press the ◄ Point button to increase the contrast (from 0 to 63). ► Selected Image mode Brightness Press the Point button to decrease the brightness; press ◄ the Point button to increase the brightness (from 0 to 63). ► Color temp . Use the Point buttons to select the desired Color temp.

  • Page 35: Screen Size Adjustment

    Computer Input Store To store the adjusted data, select Store and press the Point the SELECT button. Use the Point buttons to ► or ▲▼ select one from Image 1 to 4 and press the SELECT button. A confirmation box appears and then select yes. Stored data can be called up by selecting an Image (1–4) in the Image Mode Selection on page 33. A confirmation box appears and then select yes . Screen Size Adjustment This projector has the picture screen resize function, which Screen Menu enables you to customize the image size. Press the MENU button to display the On-Screen Menu. Use the Point buttons to select Screen and ▲▼ then press the Point button. ► or the SELECT Use the Point buttons select the desired item and ▲▼ then press the SELECT button . Normal Provide the image to fit the screen size. True Provide the image in its original size. When the original image size is larger than the screen size (1280 x 800), the projector enters to the panning mode automatically. Use the Point buttons to pan the image. When adjusted, the...
  • Page 36 Computer Input Custom Adjust the screen scale and position manually with this function. Press the Point ► button at Custom and the Custom is displayed on the screen, you can use the Point ▲▼ buttons to choose the item you want to adjust. Scale H/V .. Adjust the Horizontal/Vertical screen scale. H&V .... When set to On, the aspect ratio is fixed. Scale V appears dimmed and becomes unavailable. Adjust Scale H, then the screen scale is automatically modified based on the aspect ratio. Position H/V .. Adjust the Horizontal/Vertical screen position. Common ... Save the adjusted scale to all the inputs. Press the SELECT button at Common to display a confirmation box. To save Note: the scale, press the SELECT button • When no signal is detected, Normal is set at yes. When Custom is selected, the automatically and the Aspect dialog box saved scale is used. disappears. Reset .... Reset the all adjusted values. Press • The adjustable range for Scale H/V and the SELECT button at Reset to display Position H/V is limited depending on the input...

  • Page 37: Video Input

    Video Input Input Source Selection (Video, S-video) INPUT button Direct Operation Top Control Choose Video or S-video by pressing the INPUT button on the top control or the VIDEO button or the S-video button on Computer 1 the remote control. Before using INPUT button, correct input source should be  Computer  selected through menu operation as described below. HDMI Remote Control VIDEO button Video Video S-VIDEO button S-video S-video ...

  • Page 38: Input Source Selection (Component, Rgb Scart 21-Pin, Hdmi)

    Video Input Input Source Selection (Component, RGB Scart 1-pin, HDMI) Direct Operation Choose Computer 1 by pressing the INPUT button on the top control or press the COMPUTER button on the remote control; choose HDMI by pressing the INPUT button on the top control or press the HDMI button on the remote control. Before using these buttons, correct input source should be selected through Menu operation as described below. Top Control Remote Control COMPUTER 1 button INPUT button Computer 1(RGB) Computer 1  Computer 1(Scart) Computer  COMPONENT button HDMI Computer 1 Video (Component)

  • Page 39: Video System Selection

    Video Input Video System Selection Press the MENU button to display the On-Screen AV System Menu (Video or S-video) Menu. Use the Point buttons to select Input and ▲▼ then press the Point or the SELECT button. ► Use the Point buttons to select Video or S-video ▲▼ or Computer 1(Component) and then press the SELECT button. Use the Point buttons to select System and then ▲▼ press the Point or SELECT button. Use the Point ► ▲ buttons to select the desired system and then press ▼ the SELECT button. Video or S-video Auto The projector automatically detects an incoming video system, and adjusts itself to optimize its performance. When Video System is PAL-M or PAL-N, select the system manually.

  • Page 40: Image Mode Selection

    Video Input Image Mode Selection Direct Operation IMAGE button Remote Control Select the desired image mode from among Dynamic, Dynamic Standard, Cinema, Blackboard (Green), Colorboard, Image 1, Image , Image  and Image 4 by pressing the Standard IMAGE button on the remote control. Cinema Blackboard (Green) Colorboard IMAGE button Image 1 Menu Operation Image  Press the MENU button to display the On-Screen Menu. Use the Point buttons to select Image ▲▼ Image  or the SELECT ►...

  • Page 41: Image Adjustment

    Video Input Image Adjustment Press the MENU button to display the On-Screen Image adjust Menu Menu. Use the Point buttons to select the Image ▲▼ or the SELECT adjust and then press the Point ► button. Use the Point buttons select the desired item ▲▼ and then press the SELECT button to display the adjustment dialog box. Use the Point ◄► buttons to adjust the setting value. Contrast Press the Point ◄ button to decrease the contrast; press the Point ► button to increase the contrast (from 0 to 63). Selected Image mode Brightness Press the Point ◄ button to decrease the brightness; press the Point ► button to increase the brightness (from 0 to 63). Color Press the Point ◄ button decrease the intensity of the color; press the Point ► button increase the intensity of the color (from 0 to 63). Tint Use the Point ◄► Press the Point ◄► buttons to adjust the tint value to get a buttons to adjust the proper color balance (from 0 to 63). setting value. Color temp . Use the Point ◄► buttons to select the desired Color temp.
  • Page 42 Video Input Sharpness Press the Point ◄ button to decrease the sharpness of the image; press the Point ► button to increase the sharpness of the image (from 0 to 15). Gamma Use the Point ◄► buttons to adjust the gamma value to obtain a better balance of contrast (from 0 to 15). Noise reduction Noise interference on the screen can be reduced. Select one of the following options to get smoother images. Off ..Disabled. L1 ..Lower reduction L2 ..Higher reduction Progressive An interlaced video signal can be displayed in progressive mode. Select one of the following options. Off ..Disabled. L1 ..For an active picture. L2 ..For a still picture. Film ..For watching a film. With this function, the projector reproduces pictures faithful to the original film quality. Store Menu Reset To reset the adjusted data, select Reset and press the SELECT button. A confirmation box appears and then select yes. All adjustments will return to their previous figures. Store To store the adjusted data, select Store and press the SELECT button. Use the Point buttons to select one ▲▼...

  • Page 43: Screen Size Adjustment

    Video Input Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. Screen Menu Press the MENU button to display the On-Screen Menu. Use the Point buttons to select Screen and ▲▼ then press the Point or the SELECT button. ► Use the Point buttons select the desired item and ▲▼ then press the SELECT button. Normal Provide the image to fit the screen size while maintaining the aspect ratio of input signal. Full Provide the full screen image. Zoom Pan the horizontal direction of the image and cut the vertical direction of the image to fit the screen size (16:9). Only for 4:3 video aspect ratio signals. Wide Provide the image at the 16:9 wide screen ratio. Only for 4:3 video aspect ratio signals. Natural wide Modify the 4:3 aspect ratio image to fit the screen size(16:9 aspect ratio) by stretching the image to make it look natural. Custom Adjust the screen scale and position manually with this function. Press the Point ► button at Custom and the Custom is displayed on the screen, you can use the Point ▲▼ buttons to choose the item you want to adjust.

  • Page 44: Setting

    Setting Setting This projector has a Setting menu that allows you to set up Setting Menu the other various functions described below. Press the MENU button to display the On-Screen Menu. Press the Point buttons to select Setting ▲▼ and press the Point or the SELECT button to access ► the submenu items. Use the Point buttons to select the desired item ▲▼ and then press the Point or the SELECT button to ► Picture in Picture access the selected item. Standby mode Network Use the Point ▲▼ buttons to select the desired item and then press the SELECT button. Language Language The language used in the On-Screen Menu is available in English, German, French, Italian, Spanish, Portuguese, Dutch, Swedish, Finnish, Polish, Hungarian, Romanian, Russian, Chinese, Korean, japanese and Thai. Picture in Picture Standby mode Network Menu position This function is used to change the position of the...
  • Page 45 Setting Auto setup Auto setup This function enables Input search, Auto Keystone correction and Auto PC adjustment by pressing the AUTO SETUP button on the top control or the AUTO SET button on the remote control. Settings for those functions can be altered as follows: Input search This function detects the input signal automatically. When a signal is found, the search will stop. Use the Point ▲▼ Picture in Picture Picture in Picture buttons to select one of the following options. Standby mode Network Off ... Input search will not work. On1..Input search works under the following situation. – When pressing the AUTO SETUP button on the top control. – When pressing the AUTO SET button on the remote control. On..Input search works under the following situation. – When turning on the projector by pressing the ON/STAND-BY button on the top control or the remote control. – When pressing the AUTO SET button on the remote control.
  • Page 46 Setting Keystone This function is used to store or reset the keystone Keystone correction when the AC power cord is unplugged. Use the Point buttons to switch between each option. ▲▼ Store .. Keep the keystone correction even when the AC power cord is unplugged. Reset .. Release the keystone correction when the AC power cord is unplugged. To correct keystone distortion, press the SELECT button. Picture in Picture Picture in Picture ▲▼ Keystone appears on the screen. Use the Point Standby mode Network buttons to correct keystone distortion (p.23). Background Select the background screen for when no input signal is detected. Press the Point buttons to switch between ▲▼ each option. Blue .
  • Page 47 Setting Logo (Logo and Logo PIN code lock settings) Logo select This function allows you to customize the screen logo with Logo select, Capture, Logo PIN code lock and Logo PIN code change functions. Note: When On is selected in the Logo PIN code lock function, Logo select and Capture functions cannot be selected. Picture in Picture Standby mode Network Logo select This function decides on the starting-up display from among following options.
  • Page 48 Setting Capture This function enables you to capture an image being projected to use it for a starting-up display or interval of Capture presentations. Select Capture and press the SELECT button. A confirmation box appears and select yes to capture the projected image. After capturing the projected image, go to the Logo select function and set it to User. Then the captured image will be displayed the next time you turn on the projector. To cancel the capture function, select yes in the "Quit?" confirmation box. Note: • Before capturing an image, select Standard in the Image select Menu to capture a proper image (pp.33, 40). • A signal from a computer can be captured up to WXGA (1280 x 800). A signal from video equipment can be captured except for 1035i, and 1080i. • When capturing the image that has been adjusted by the Keystone function, the adjusted data is automatically reset and the projector captures an image without keystone correction. • When Logo PIN code lock is set to On, capture cannot be selected. • When starting to capture a new image, the previously stored image is cleared even if you cancel the capturing. • When there is no captured image or it is interrupted while capturing an image, User is not included in Logo Select menu, you can only switch between Default and Off. Logo PIN code lock This function prevents an unauthorized person from Logo PIN code lock changing the screen logo.
  • Page 49 Setting Enter a Logo PIN code Enter a Logo PIN code Use the Point buttons to enter a number. Press the ▲▼ Point button to fix the number and move the red frame ► pointer to the next box. The number changes to “”. If you fixed an incorrect number, use the Point button to ◄ move the pointer to the number you want to correct, and then enter the correct number. Repeat this step to complete entering a four-digit number. After entering the four-digit number, move the pointer to Set. Press the SELECT button so that you can start to operate the projector. If you entered an incorrect Logo PIN code, Logo PIN code and the number () will turn red for a moment. Enter the correct Logo PIN code all over again. Change the Logo PIN code lock setting Use the Point buttons to switch On or Off, and then ▲▼...
  • Page 50 Setting Ceiling Ceiling When this function is set to On, the picture will be top/ bottom and left/right reversed. This function is used to project the image from a ceiling-mounted projector. Rear When this function is set to On, the picture will be left/right Rear reversed. This function is used to project the image from rear of the screen. HDMI setup HDMI setup This function is only used for HDMI input source. Image Normal: When the output of Digital R/G/B equipment is set to Standard. Enhanced: When the output of Digital R/G/B equipment is set to Enhanced. Sound Picture in Picture HDMI: When Digital input source is input, Standby mode Network Sound is set to HDMI. Computer : When DVI input source is changed to HDMI input source, Sound is set to Computer . The names for the output setting of Digital R/G/B vary from equipment to equipment. For details, refer to the owner’s manual of your Digital R/G/B equipment. When the black parts of the image are destroyed or stand out, please switch to Normal or Enhanced, and then switch the output type of the HDMI Digital R/G/B output equipment.
  • Page 51 Setting Picture in Picture This function is used to project two videos simultaneously Picture in Picture by placing a separate small sub screen within the main screen. (Picture in Picture combinations provided in this projector are shown on pages 75.) Only the sound on the main picture is heard, the sound on the sub picture cannot be heard.( In P in P, the big picture is main picture, and the small one is sub picture; in P by P, the left picture is main picture, and the right one is sub picture.) more... Picture in Picture Standby mode Network Mode ..P in P : The sub picture in the main picture. P by P: The sub picture by the main picture. Off : Exit the Picture in Picture menu. Subpicture size . . . Select the subpicture display size. Subpicture can be changed between Large, Small and Middle.
  • Page 52 Setting Standby mode This function is available when operating the projector via network. Network .. Supply the power to the network function even after turning off the projector. You can turn on/ off the projector via network, modify network environment, and receive an e-mail about projector status while the projector is powered off. Eco .... Select Eco when you do not use the projector via network. The projector’s network function will stop when turning off the projector. Refer to the owner’s manual of “Network Set-up and Operation”. Note: • Factory default is Eco. • When selecting Network, the cooling fans may be running depending on the temperature inside the projector even if the projector is turned off. Power management Power management For reducing power consumption as well as maintaining the lamp life, the Power management function turns off the projection lamp when the projector is not operated for a certain period. Timer left before Lamp is off. Select one of the following options: Ready .... When the lamp has been fully cooled down, the POWER indicator changes to green blinking. In this condition, the projection lamp will be turned on if the input signal is reconnected or any button...
  • Page 53 Setting On start When this function is set to On, the projector will be On start automatically turned on just by connecting the AC power cord to a wall outlet. Note: • Be sure to turn off the projector properly (see "Turning Off the Projector" on page 20). If the projector is turned off in the incorrect sequence, the On start function does not work properly. • On start function is available only when Network is selected in Standby mode function. (p.52)
  • Page 54 Setting Closed caption Closed Caption is a function that displays the audio portion Closed Caption of a TV program as text on the screen. If the input signal contains closed captions, you can turn on the feature and Power management switch the channels. Press the Point ▲▼ buttons to select On start Off, CC1, CC, CC or CC4. If the closed caption is not clear, you can change the text from Color to White. Note: The Closed Caption is available only under the situation Press the Point buttons to ▲▼ below. select Off, CC1, CC, CC or CC4, • When the input signal is NTSC of composite and and then Press Select button. S-video, and the system is set according to the signal or set on Auto. • The system must be set on NTSC or Auto in Video System Selection. (p.39) • The icon of Closed caption is displayed in gray while it is not available. • The Closed caption is unavailable when On-Screen menu and P-Timer are displayed, and Picture in Picture is active.
  • Page 55 Setting Lamp life control Lamp control Lamp control Power management This function allows you to change brightness of the On start screen. Normal .. Normal brightness Eco .... Lower brightness reduces the lamp power consumption and extends the lamp life. Lamp life control Select the lamp operation when the total lighting time of a lamp exceeds the recommended total hours of use. Mode 1 .... A lamp can be turned on even after exceeding the recommended total hours of use. Mode  .... A lamp can be turned on even after exceeding the recommended total hours of use. But the projector turns off automatically after 3 minutes.  Note: • Lamp mode cannot be changed for a while after turning on the projector. Lamp needs some time to stabilize after the power is turned on. Stored lamp mode will be active after the lamp is stabilized.
  • Page 56 Setting Key lock Security (Key lock and PIN code lock) This function allows you to use the Key lock and PIN code Power management On start lock function to set the security for the projector operation. Key lock This function locks the top control and remote control buttons to prevent operation by unauthorized persons. Select Key lock and then press the SELECT button, and select the desired item by pressing the Point buttons ▲▼ .. Unlocked.. Lock the operation of the top control. To unlock, use the remote control.. Lock the operation of the remote control. To unlock, use the top control.
  • Page 57 Setting Enter a PIN code Use the Point buttons to enter a number. Press the Enter a PIN code ▲▼ Point button to fix the number and move the red frame ► pointer to the next box. The number changes to “”. If you fixed an incorrect number, use the Point button to ◄ move the pointer to the number you want to correct, and then enter the correct number. Repeat this step to complete entering a four-digit number. After entering the four-digit number, move the pointer to “Set.” Press the SELECT button so that you can start to operate the projector. If you entered an incorrect PIN code, PIN code and the number () will turn red for a moment. Enter the correct PIN code all over again.
  • Page 58 Setting This function provides the following options in the cooling fans’ operation when the projector is turned off (p.20). L1 ..Normal operation L ..Slower and lower-sound than the normal operation (L1), but it takes more time to cool the projector down. Fan control This projector provides Fan control function in the Setting menu. Choose the running speed of cooling fans from the following options according to the ground elevation under which you use the projector. Off....Normal speed. Set this function to Off when using the projector in non-high altitude environment. On 1..... Faster than Off mode. Select this mode when using the projector in high altitudes (about 1,200 meters or more above the sea level) where the fans have less cooling effect. On ..... Faster than On 1 mode. Select this mode when using the projector in higher altitudes than above where the fans have lesser cooling effect. Note: The fan noise becomes louder in On 1 and On. Filter counter This function is used to set a frequency for the filter Filter counter cleaning.
  • Page 59 Setting WARNING log This function records anomalous operations while the projector is in operation and use it when diagnosing faults. Up to 10 warning logs are displayed with the latest warning message at the top of the list, followed by previous warning messages in chronological order.  Note: When the Factory default function is executed, all the warning log records will be deleted. Factory default This function returns all setting values except for the User Factory default logo, PIN code lock, Logo PIN code lock, Lamp counter and Filter counter to the factory default settings.

  • Page 60: Information

    Information Input Source Information Display The Information Menu is used for checking the status of the image signal being projected and the operation of the projector. Direct Operation Press the INFO. button on the remote control to display the Remote Control Information Menu. INFO . button Menu Operation Press the Point buttons to select the Information. The ▲▼ Information Menu is displayed. See below for displayed information. Input The selected input source is displayed. Information Menu H-sync freq . The horizontal frequency of the input signal is displayed in KHz, or - - - - - when no signal. V-sync freq . The vertical frequency of the input signal is displayed in Hz, or - - - - - when no signal. Numbers of Hz doubles when during Interlace.

  • Page 61: Maintenance And Cleaning

    Maintenance and Cleaning WARNING indicator The WARNING indicator shows the state of the function which protects the projector. Check the state of the WARNING indicator and the POWER indicator to take proper maintenance. The projector is shut down and the WARNING Top Control indicator is blinking red . When the temperature inside the projector reaches a WARNING blinking certain level, the projector will be automatically shut down to protect the inside of the projector. The POWER indicator is blinking while the projector is being cooled down. When the projector has cooled down enough (to its normal operating temperature), it can be turned on again by pressing the ON/ STAND-BY button. Note: The WARNING indicator continues to blink even after the temperature inside the projector returns to normal.

  • Page 62: Cleaning The Filters

    Maintenance and Cleaning Cleaning the Filters Filter prevents dust from accumulating on the optical elements inside the projector. Should the filters become clogged with dust particles, it will reduce cooling fans’ effectiveness and may result in internal heat buildup and adversely affect the life of the projector. If a “Filter warning” icon appears on the screen, clean the filters immediately. Clean the filters by following the steps below. Turn off the projector, and unplug the AC power cord from the AC outlet. Turn the projector over and remove the filters . Clean the filters softly by using a brush. Replace the filters properly. Make sure that the filters are fully inserted to the projector. CAUTION Filters. Do not operate the projector with the filters removed. Dust may accumulate on the optical Note: elements degrading picture quality. When reinserting this Do not put anything into the air vents. Doing so filter, be sure that the may result in malfunction of the projector. slit part is facing the outer side. RECOMMENDATION We recommend avoiding dusty/smoky environments when you operate the projector . Usage in these Filter counter environments may cause poor image quality .

  • Page 63: Attaching The Lens Cap

    Maintenance and Cleaning Attaching the Lens Cap When moving this projector or while not using it over an extended period of time, replace the lens cap. Attach the lens cap according to the following procedures. Thread the string through the hole on the lens cap and then tie a knot in the string to secure it in place. To pass the other end of the string into the hole on the top of the projector and pull at it. Cleaning the Projection Lens Unplug the AC power cord before cleaning. Gently wipe the projection lens with a cleaning cloth that contains a small amount of non-abrasive camera lens cleaner, or use a lens cleaning paper or commercially available air blower to clean the lens. Avoid using an excessive amount of cleaner. Abrasive cleaners, solvents, or other harsh chemicals might scratch the surface of the lens. Cleaning the Projector Cabinet Unplug the AC power cord before cleaning.

  • Page 64: Lamp Replacement

    (p.55). ORDER REPLACEMENT LAMP Replacement lamp can be ordered through your dealer. When ordering a projection lamp, give the following information to the dealer. Model No. of your projector : LC-WB100 ● Replacement Lamp Type No. : POA-LMP131 ●...

  • Page 65: Lamp Handling Precautions

    Maintenance and Cleaning LAMP HANDLING PRECAUTIONS This projector uses a high-pressure lamp which must be handled carefully and properly. Improper handling may result in accidents, injury, or create a fire hazard. Lamp life may differ from lamp to lamp and according to the environment of use. There is no guarantee ● of the same life for each lamp. Some lamps may fail or terminate their life in a shorter period of time than other similar lamps. If the projector indicates that the lamp should be replaced, i.e., if the LAMP REPLACE indicator lights ● up, replace the lamp with a new one IMMEDIATELY after the projector has cooled down. (Follow carefully the instructions in the Lamp Replacement section of this manual.) Continuous use of the lamp with the LAMP REPLACE indicator lighted may increase the risk of lamp explosion. A Lamp may explode as a result of vibration, shock or degradation as a result of hours of use as its ● lifetime draws to an end. Risk of explosion may differ according to the environment or conditions in which the projector and lamp are being used.

  • Page 66: Appendix

    Appendix Troubleshooting Before calling your dealer or service center for assistance, check the items below once again. – M ake sure you have properly connected the projector to peripheral equipment as described on pages 14-16. – M ake sure all equipment is connected to AC outlet and the power is turned on. – W hen the projector does not project an image from the connected computer, restart the computer. – Solutions Problem: – Plug the power cord of the projector into the AC outlet. No power – See if the POWER indicator lights red. – W ait until the POWER indicator stops blinking to turn on the projector again. The projector can be turned on after the POWER indicator turns red. See page 18. – Check the WARNING indicator. If the WARNING indicator lights red, projector cannot be turned on. See page 61. – Check the projection lamp. See page 64. – Unlock the Key lock function for the projector. See page 56. – Make sure Off or Countdown off are not chosen at display The initial display is not shown . function. See page 46. – Make sure User or Off are not chosen at Logo (select) The initial display is not same function. See page 47.
  • Page 67 Appendix – Check the connection between your computer or video equipment No image and the projector. See pages 14-16. – See if the input signal is correctly output from your computer. Some laptop computers may need to change the setting for monitor output when connecting to a projector. See your computer’s instruction manual for the setting. – It takes about 30 seconds to display an image after turning on the projector. See page 18. – C heck the Input signal, color system, video system or computer system mode. – Make sure the temperature is not out of the specified Operating Temperature ( 41˚F–95˚F [5˚C–35˚C]) – When No Show is operating, the image cannot be displayed. Press the NO SHOW button or any other button on the remote control. – Check the audio cable connection from audio input source. No sound – Adjust the audio source. – Press the Volume + button. See page 24. – Press the Mute button. See page 24. – When the AUDIO OUT is plugged-in, the projector's built-in speaker is not available. – Is the image projected? You will hear the sound only when the image is projected. – Check the Input signal, color system, video system or computer The color is strange . system mode. – Make sure the Blackboard is not selected on Image select menu. See pages 33,40.
  • Page 68 Appendix – Check PC adjustment menu or Screen and adjust them. The image is distorted or runs off . See pages 31-32, 35-36. – PIN code lock is being set. Enter a PIN code (the “1234” or numbers PIN code dialog box appears at start-up . you have set). See pages 19, 56-57. – Check the batteries. The Remote Control does not work . – Make sure no obstruction is between the projector and remote control. – Make sure you are not too far from the projector when using the remote control. Maximum operating range is 16.4'(5 m). – Make sure the code of the remote control is conformed to the projector’s code. See page 55. – Unlock the Key lock function for the remote control function. See page 56.
  • Page 69 Appendix WARNING : High voltages are used to operate this projector . Do not attempt to open the cabinet . If problems still persist after following all operating instructions, contact the dealer where you purchased the projector or the service center. Specify the model number and explain about the problem. We will advise you how to obtain service. This symbol on the nameplate The CE Mark is a Directive conformity means the product is Listed mark of the European Community (EC).

  • Page 70: Menu Tree

    Appendix Menu Tree Computer Input/Video Input Input Input RGB Computer 1 Component RGB (Scart) Computer 2 HDMI Video S-video Sound Volume 0–63 Sound Mute On/Off Computer Input Dynamic Image select SVGA 1 Standard System Mode 1 Real Mode 2 Blackboard (Green) Colorboard Red/Blue/Yellow/Green - - - - Image 1 Image 2 * Systems displayed in the System Menu vary depending on an input signal.
  • Page 71 Appendix Video Input Setting Auto System 1080i Language 17 languages provided. Setting 1035i Menu position 720p Auto setup Input search Off/On1/On2 575p Auto PC adj. 480p On/Off 575i Auto Keystone 480i Auto Manual Auto System Keystone Store/Reset SECAM Background Blue/User/Black NTSC Display On/Countdown off/Off NTSC 4.43 Logo Logo select PAL-M User PAL-N Default Capture...

  • Page 72: Indicators And Projector Condition

    Appendix Indicators and Projector Condition Check the indicators for projector condition. Indicators Projector Condition LAMP POWER WARNING REPLACE red/green yellow The projector is off. (The AC power cord is unplugged.) The projector is in stand-by mode. Press the ON/STAND-BY button  to turn on the projector.  The projector is operating normally. The projector is preparing for stand-by or the projection lamp is  being cooled down. The projector cannot be turned on until cooling is completed and the POWER indicator stops blinking.  The projector is in the Power management mode. The temperature inside the projector is abnormally high. The projector cannot be turned on. When the projector is cooled down  enough and the temperature returns to normal, the POWER indicator stops blinking and the projector can be turned on. (The WARNING indicator keeps blinking.) The projector has been cooled down enough and the temperature  returns to normal. When turning on the projector, the WARNING indicator stops blinking. The projector detects an abnormal condition and cannot be turned on. Unplug the AC power cord and plug it again to turn on the projector. If the projector is turned off again, unplug the AC power ...

  • Page 73: Compatible Computer Specifications

    Appendix Compatible Computer Specifications Basically this projector can accept the signal from all computers with the V-, H-Frequency mentioned below and less than 140 MHz of Dot Clock. When selecting these modes, PC adjustment can be limited. ON-SCREEN H-Freq . V-Freq . ON-SCREEN H-Freq . V-Freq . RESOLUTION RESOLUTION DISPLAy (KHz) (Hz) DISPLAy (KHz) (Hz) VGA 1 640 x 480 31.47 59.88 SXGA 1 1152 x 864 64.20 70.40 VGA 2 720 x 400 31.47 70.09 SXGA 2 1280 x 1024 62.50 58.60 VGA 3 640 x 400...
  • Page 74 Appendix When the input signal is digital from HDMI terminal, refer to the chart below. ON-SCREEN H-Freq . V-Freq . ON-SCREEN H-Freq . V-Freq . RESOLUTION RESOLUTION DISPLAy (KHz) (Hz) DISPLAy (KHz) (Hz) D-480p 640 x 480 31.47 59.88 D-SXGA1 1280 x 1024 63.98 60.02 D-480p 720 x 480 ---- 59.94 D-SXGA2 1280 x 1024 60.276 58.069 D-480p 720 x 480 ---- 60.00 D-SXGA3 1280 x 1024 31.65...

  • Page 75: List Of Picture In Picture

    Appendix List of Picture in Picture : Picture in Picture combinations are enabled - : Picture in Picture combinations are disabled  Note: • W hen the input signal(s) is/are incompatible, X mark will be displayed on the Main/Sub picture. • D epending on the frequency or signal type of PC/AV input, the display resolution may be lowered or images may not be displayed on the Main/Sub picture. 　　<Display resolution is lowered when;> • I nputting PC analog signals: Between 100-140 MHz 　　<Images are not displayed and X mark appears when;> • I nputting PC analog signals: More than 140MHz • I nputting PC digital signals: More than 100MHz • I nputting AV digital signals: 1080p 　　<Picture in Picture is disabled when;> • I nputting signal formats: SXGA20, WUXGA 1, WUXGA 2, WSXGA+ 1, WXGA+2, UXGA 1, UXGA 2, UXGA 3, UXGA4, D-1080p...

  • Page 76: Technical Specifications

    Appendix Technical Specifications Mechanical Information Projector Type Multi-media Projector Dimensions (W x H x D) 12.80" x 3.27" x 9.12" (326mm x 83.1mm x 231.6mm) (Not including protrusions) Net Weight 6.18 lbs (2.8 kg) Feet Adjustment 0˚ to 12˚ Panel Resolution LCD Panel System 0.59" TFT Active Matrix type, 3 panels Panel Resolution 1,280 x 800 dots Number of Pixels 3,072,000 (1,280 x 800 x 3 panels) Signal Compatibility Color System PAL, SECAM, NTSC, NTSC4.43, PAL-M, and PAL-N SD/HDTV Signal Analog: 480i, 480p, 575i, 575p, 720p, 1035i, and 1080i HDMI: 480p, 575p, 720p, 1080i, and 1080p Scanning Frequency H-sync. 15 kHz–100 kHz, V-sync. 50–100 Hz Optical Information Projection Image Size (Diagonal) Adjustable from 30” to 300” Throw Distance 2.4' ~ 25.2' (0.74 m ~ 7.67 m) Projection Lens F 1.65 ~ 2.33 lens with f 15.47 mm ~ 24.53 mm with manual zoom and focus Projection Lamp 225 W Interface Video Input Jack RCA Type x 1 S-video Input Jack...

  • Page 77: Optional Parts

    Appendix Accessories Owner’s Manual (CD-ROM) Quick Reference Guide & Safety Manual Soft Carrying Case AC Power Cord Remote Control and Batteries VGA Cable Lens Cap with String PIN Code Label Network Application (CD-ROM) The specifications are subject to change without notice. ● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are ● effective, a tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels. Optional Parts The parts listed below are optionally available. When ordering those parts, specify the item name and Model No. to the sales dealer. Model No. COMPONENT-VGA Cable : AH-8771 SCART-VGA Cable : AH-8881...

  • Page 78: Pj Link Notice

    Appendix Pj Link Notice This projector is compliant with PJLink Standard Class 1 of JBMIA (Japan Business Machine and Information System Industries Association). This projector supports all commands defined by PJLink Class 1 and is verified conformance with PJLink Standard Class 1. For PJ Link password, see the owner’s manual of “Network Set-up and Operation.” Projector Input PJLink Input Parameter Computer 2 (Analog) RGB 1 HDMI(Digital) DIGITAL 1 RGB 2 Computer 1 Component RGB 3 RGB (Scart) RGB 4 Video VIDEO 2 Video S-video VIDEO 3 PJLink is a registered trademark of JBMIA and pending trademark in some countries.

  • Page 79: Configurations Of Terminals

    Appendix Configurations of Terminals COMPUTER IN 1 /COMPONENT IN /COMPUTER IN /MONITOR OUT (ANALOG) Terminal: Analog RGB (Mini D-sub 15 pin) Red (R/Cr) Input/Output +5V Power/----- Green (G/Y) Input/Output Ground (Vert.sync.) Blue (B/Cb) Input/Output Ground/----- DDC Data /----- ----- Ground (Horiz.sync.) Horiz. sync. Input/Output (Composite H/V sync.) Ground (Red) Vert. sync. Ground (Green) DDC Clock /----- Ground (Blue) CONTROL PORT CONNECTOR (D-sub  pin) Serial ----- R X D...

  • Page 80: Pin Code Number Memo

    Appendix PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service station. PIN Code Lock No . Factory default set No: 1 2 3 4* Logo PIN Code Lock No . Factory default set No: 4 3 2 1* *Should the four-digit number be changed, the factory set number will be invalid. While the projector is locked with the PIN code. Put the label below (supplied) on in a prominent place of the projector's body while it is locked with a PIN code.

  • Page 81: Dimensions

    Appendix Dimensions Unit: mm(inch) Screw Holes for Ceiling Mount Screw: M4 Depth: 12.0(0.472) 219.4(8.64) 93.5(3.68) 232.5(9.15) 101(3.98) 55(2.17) º 80.5(3.17)
  • Page 82 U.S.A. Canada EIKI International, Inc. EIKI CANADA - Eiki International, Inc. 30251 Esperanza P.O. Box 156, 310 First St. - Unit 2, Rancho Santa Margarita Midland, ON, L4R 4K8, Canada CA 92688-2132 Tel : 800-563-3454 (705)-527-4084 U.S.A. Fax : 800-567-4069 (705)-527-4087...
