M101SR
Rugged Windows Tablet
Intel® Kaby Lake Core i5-7200U
Windows 10 IoT Enterprise
User Guide
Version 1.0
Please read these instructions carefully before using this product, and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M101SR and is the answer not in the manual?

Questions and answers

Related Manuals for Winmate M101SR

Summary of Contents for Winmate M101SR

  • Page 1 M101SR Rugged Windows Tablet Intel® Kaby Lake Core i5-7200U Windows 10 IoT Enterprise User Guide Version 1.0 Please read these instructions carefully before using this product, and save this manual for future use.

  • Page 2: Table Of Contents

    Rugged Windows Tablet M101SR User Guide Contents CHAPTER 1: READ ME FIRST 1.1 A DVISORY ONVENTIONS 1.2 S AFETY NFORMATION 1.3 H ANDLING AND AINTENANCE 1.4 D ECLARATION OF ONFORMITY CHAPTER 2: GETTING STARTED 2.1 I NTRODUCTION 2.2 U NPACKING 2.3 D...

  • Page 3: Chapter 1: Read Me First

    Chapter 1: Read Me First Chapter 1: Read Me First 1.1 Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings.

  • Page 4: Safety Information

    M101S Rugged Tablet User Guide 1.2 Safety Information Precaution on Battery Pack When the Battery Pack Has Deteriorated, Précaution avec le bloc-pile Replace It with a New Battery. Continued use of a damaged battery pack may result in heat generation, ignition or battery rupture. [FR] Lorsque la pile est détériorée, la Do Not Disassemble, Modify, or Insert Sharp remplacer par une nouvelle pile.
  • Page 5 Chapter 1: Read Me First General Product Safety  Use only accessories specified by the Sécurité générale des manufacturer. [FR] Utiliser uniquement les accessoires produits spécifiés par le fabricant.  Do not block any ventilation openings. Do not  This product should not be used near water place the product against a wall or in an such as bathtubs, sinks, swimming pools, wet enclosed space as doing so might impede the...

  • Page 6: Handling And Maintenance

    M101S Rugged Tablet User Guide 1.3 Handling and Maintenance Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the product. General Guideline [FR] Essuyer délicatement l'écran avec un Guide Général chiffon doux non pelucheux. Ne pas utiliser d'alcool ou un détergent sur le produit.

  • Page 7: Declaration Of Conformity (Doc)

    Chapter 1: Read Me First 1.4 Declaration of Conformity (DoC) FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference.  This device must accept any interference received including ...

  • Page 8: Chapter 2: Getting Started

    2.1 Introduction Congratulations on purchasing Winmate® 10.1-inch Rugged Windows Tablet M101SR. M101SR is a rugged tablet with robust set of features designed to withstand industrial use while providing high tech solutions that increase productivity, improve safety, and reduce operational costs.

  • Page 9: Description Of Parts

    Chapter 2: Getting Started   Hand Strap Mobile Printer MX20/MX30 2.3 Description of Parts Front: Right: Item Description Item Description Micro HDMI HDMI output to external Display and act as one of 10.1”Resisitve display the inputs for the Tablet Touch Screen Computer Reset Button...
  • Page 10 Rugged Windows Tablet M101SR User Guide Rear: Top: Bottom: Item Description Item Description Optional Barcode Scanner for Camera LED camera flash to Barcode reading of 1D/2D Flash provide flash lighting barcode. when use with camera. Volume Buttons Volume Control. Rear Camera 8MP Autofocus Camera.

  • Page 11: Indicators

    Chapter 2: Getting Started 2.4 Indicators Icon Indicator Description Power Indicator Blue– Tablet is ON No light– Tablet is OFF Battery Status Orange–AC adapter is plugged in and charging Green–AC adapter is plugged in and battery is full charged Solid Red - Low battery (<10%) Blinking Red –...

  • Page 12: First-Time Operation

    Rugged Windows Tablet M101SR User Guide 2.6 First-Time Operation To get started: 1. Install SIM card. 2. Install storage card. 3. Install the battery. 4. Charge your tablet. 5. Start the tablet. 2.6.1 Installing SIM card (For 3G/LTE Equipped Devices) The Tablet Computer supports 3G/LTE data connection and fits a Micro-SIM card.

  • Page 13: Installing A Micro Sd Card

    Chapter 2: Getting Started 2.6.2 Installing a Micro SD Card Your tablet supports up to 128GB additional storage with an optional microSD card slot. To install Micro SD Card: 1. Open I/O protective cover by pulling out the latch. 2. Insert microSD card into slot with contacts facing down. 3.

  • Page 14: Charging Your Tablet

    Rugged Windows Tablet M101SR User Guide 2.6.4 Charging Your Tablet The Tablet operates either on external AC power or internal battery power. It is recommended to use AC power when you start up the Tablet for the first time. Caution : Use only the AC adapter included with your Tablet Computer.

  • Page 15: Chapter 3: Setting Up Windows For The First Time

    Chapter 3: Setting Up Windows for the First Time Chapter 3: Setting Up Windows for the First Time This chapter details how to setup the Windows that may be installed on the tablet for the first time. 3.1 Introduction The M101S Tablet Computer operates on Windows 10 IoT Enterprise operating system. Caution : Make sure the battery is full charged before starting the Tablet Computer for the first time with internal battery power.
  • Page 16 M101S Rugged Tablet User Guide 3. On the Here's the legal stuff screen, read through the disclosures, then tap Accept. 4. Windows will then try to connect to network. Tap Skip this step to continue without a wireless connection as you can then set up the network later. 5.
  • Page 17 Chapter 3: Setting Up Windows for the First Time 6. To create a local account, type your User name, password, and Password hint in the fields provided, then tap Next. 7. The initial setup screens are complete, and the desktop is displayed. 8.

  • Page 18: Chapter 4: Operating The Device

    Rugged Windows Tablet M101SR User Guide Chapter 4: Operating the Device This chapter describes how to operate the M101SR Tablet Computer, including camera, Hottab, barcode, RFID, WWAN, WLAN, GPS features. Note: Please download the SDK from Winmate Download Center here.

  • Page 19: Shortcuts

    Chapter 4: Operating the Device Icon Description Allows users to configure short cut to quickly access programs with a few tabs. Shortcuts Allows users take a picture or record a video. User can also adjust setting related to camera in this menu option. Camera Enables/disables tablet computer’s hardware functions.

  • Page 20: Using Camera

    Rugged Windows Tablet M101SR User Guide 4.3 Using Camera This Hottab menu option allows users take a picture or record a video. Before use, make sure the camera is powered on under Devices ON/OFF menu with the following scenarios. To open camera interface: 1.

  • Page 21: Built-In Devices On/Off

    Chapter 4: Operating the Device 4.4 Built-in Devices On/Off This section describes how to get a quick access to set-up built-in devices, including turning on/off RF modules, setting up barcode reader, and RFID reader. 4.4.1 Using the Wireless LAN (Wi-Fi) To use the wireless LAN (Wi-Fi) feature to connect to the network, perform the following procedure: 1.

  • Page 22: Using The Wireless Wan (3G/Lte)

    Rugged Windows Tablet M101SR User Guide 4.4.2 Using the Wireless WAN (3G/LTE) The Tablet Computer supports data connection with 3G/LTE modules and fits Micro-SIM card. (Note: 3G/LTE feature is optional). 4.4.2.1 Installing a SIM card Caution Power off the tablet before installing the 3G/LTE module and Micro SIM card, or the tablet computer might be damaged by the incorrect installation behaviors.

  • Page 23: Using The Gps

    Chapter 4: Operating the Device 4.4.3 Using the GPS To enable the GPS: 1. Open the Hottab utility by press the (Menu) Button located on the front panel, OR launching the Hottab Utility application. 2. Tap on the Device ON/OFF button. 3.

  • Page 24: Using The Barcode Reader

    4.4.6 Using the Barcode Reader The 2D/1D Barcode Reader is optional for M101SR Tablet PC and is not re-workable by the end user. To use this feature, please make sure the tablet PC is built-in barcode reader before use, or contact our sales contact window for more details.
  • Page 25 Chapter 4: Operating the Device 2.Click on EZConfig-Scanning v4_IE and allow the blocked content if browser is blocking the content. 3.Click on “Connected Device” icon and wait for system to discover the device (Honeywell N660X). 4.Once Honeywell N660X is discovered please click “Configure Device” button as shown.
  • Page 26 Rugged Windows Tablet M101SR User Guide 4.4.6.2 Scanning mode Settings 1. Click on Device Settings under the Input/Output settings section. 2. Select the desire scanning mode from the drop-down menu shown as below.
  • Page 27 Chapter 4: Operating the Device 3. After selecting a desire scanning mode, click on the “Save to Device” on the side bar. Scanning Description mode Manual When in manual trigger mode, the scanner scans until a bar code is read, or until the trigger is released.
  • Page 28 Rugged Windows Tablet M101SR User Guide 4.4.6.3 Setting the 1D/2D Barcode Scanner Symbologies The barcode scanner is shipped with default settings shown below. If the default setting suits the usage requirement, setting symbologies is not necessary. Symbologies Default Settings: Symbologies...
  • Page 29 Chapter 4: Operating the Device ※Warning※ 1. The reset to default button will change all setting to default. 2. N660X could disconnect with system after clicking the reset to default button. If the Disconnection happened please scan barcodes below in the following steps. Step 1.
  • Page 30 Rugged Windows Tablet M101SR User Guide 2.Click on Editor button under the Prefix or Suffix section and create Prefix/Suffix value by typing in the block or select desire characters in the Control chars, Printable chars, and Extended ASCII. as shown below:...
  • Page 31 Chapter 4: Operating the Device 3. When you finish creating Prefix/Suffix, please click on “Save to Device” on the side bar. 4. For checking the functionality of Prefix/Suffix, please chick on “Scan Data Window” icon on the top. Then scan a barcode to verify if the Prefix/Suffix appear correctly.

  • Page 32: Using The Hf Rfid Reader

    4.4.7 Using the HF RFID Reader The HF RFID Reader is optional for M101SR Tablet PC and is not re-workable by the end user. To use this feature, please make sure the tablet PC is built-in HF RFID reader before use, or contact our sales contact window for more details.
  • Page 33 Chapter 4: Operating the Device 4.4.7.1 RFID Trigger Setting Item Description Auto Scan The default setting for RFID trigger is Auto Scan. Under this setting, the RFID Reader will always be ready to scan tags. When the RFID tag is detected from RFID antenna, the data will be read automatically.
  • Page 34 Rugged Windows Tablet M101SR User Guide 4.4.7.2 Settings Item Description Sound The Sound check box defines whether a beep sound will come with the data scanning. Output to This setting defines the output type of the scanned data. Two options are available: Keyboard Wedge Under this setting, the data scanned is sent like keyboard data.
  • Page 35 Chapter 4: Operating the Device Item Description Prefix User can type in this field to define the characters BEFORE the data scanned. Suffix User can type in this field to define the characters AFTER the data scanned. The check box user can defines to append an “Enter” which is Append Enter followed by the characters.
  • Page 36 Rugged Windows Tablet M101SR User Guide Note: User can download the SDK from Winmate Download center website >> M101P >> Development Kit or check the Driver CD which is shipped with the tablet. http://www.winmate.com/DownCenter/DownLoadCenter.asp?DownType=2207&OnlyCon 4.4.7.3 RFID Output Setting Item Description Select RFID The default setting for built-in HF RFID Reader is to Read UID.

  • Page 37: Turn On/Off The Gps External Antenna

    Chapter 4: Operating the Device 4.4.8 Turn on/off the GPS External Antenna The vehicle dock of M101SR Tablet PC supports external GPS antenna through standard SMA connector. To work with external GPS antenna, please make sure the tablet PC is well installed to vehicle dock, and the vehicle dock has connected with external GPS antenna.

  • Page 38: Chapter 5: Frequently Used Settings

    Rugged Windows Tablet M101SR User Guide Chapter 5: Frequently Used Settings 5.1 Screen Resolution Scaling and Setting The M101’s 1920 x 1200 high resolution display is perfect for viewing image, video, or other applications, however, Windows user interface (icons, buttons, and other user interface elements) may be too small to read and operate at the default Windows settings.

  • Page 39: Changing Screen Resolution

    Chapter 5: Frequently Used Settings 5.1.2 Changing Screen Resolution Alternatively, instead of changing the display scaling setting, user may choose to change the overall resolution setting to make screen elements bigger. 1. Tap and hold anywhere on the desktop for 3 seconds and release to bring up the context menu, and select “Display settings”...
  • Page 40 Rugged Windows Tablet M101SR User Guide 2. Click on the dropdown option next to “Resolution” and select the desire resolution by tapping on the scale: 3. Hit “Apply”. A prompt “Display Settings” prompt will show up to ask the user if the applied resolution is usable.

  • Page 41: Replacing Battery

    Chapter 5: Frequently Used Settings 5.2 Replacing Battery The M101SR Rugged Tablet supports hot-swap, meaning the tablet doesn’t need to be powered off to replace the main battery. To support hotswap, there is a backup battery inside the tablet that is charged together with the main battery.

  • Page 42: Using Recovery Wizard To Restore Computer

    Rugged Windows Tablet M101SR User Guide 5.3 Using Recovery Wizard to Restore Computer M101SR Tablet Computer has a dedicate recovery partition stored on the hard drive of the tablet to enable quick one-key recovery process. This partition occupies about 11GB of the storage space, and comes built-in to each M101SR Tablet Computer.
  • Page 43 Chapter 5: Frequently Used Settings 5. Wait till the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of recovery process. 6. After recovery is completed, please press any key to continue, and the tablet computer will shut down automatically.

  • Page 44: Docking Connector Pin Definition

    Rugged Windows Tablet M101SR User Guide 5.4 Docking Connector Pin Definition M101SR tablet computer supports one 19-pin docking connector at the bottom side. The pin definition is listed as the following table. 19 Pin Docking Connector Pin No. Description Pin No.
  • Page 45 Chapter 5: Frequently Used Settings Tap on "Port Setting" tab and click on "Advanced" button. Tap on the dropdown list and choose the correct COM Port Number (refer to the COM Port Definition Table), and click "OK". Double check "Device Manager" to make sure the COM Port number has been re-defined successfully, and then restart the system.

  • Page 46: Pairing With A Wireless Bluetooth Barcode Scanner

    Rugged Windows Tablet M101SR User Guide 5.6 Pairing with a Wireless Bluetooth Barcode Scanner The computer is affixed with a Bluetooth MAC (Media Access Control) address barcode label that enables wireless Bluetooth Barcode Scanner to quickly establish Bluetooth connection with the computer. It is encoded with leading characters to instruct the wireless Bluetooth barcode scanner to initial Bluetooth Serial Port Profile pairing request.
  • Page 47 Chapter 5: Frequently Used Settings 4. go to “Options” tab, and make sure that in the Discovery section, the computer is set to “Allow Bluetooth devices to find this computer”, as shown below: Click OK to continue. 5. In the Bluetooth Settings menu, go to “COM Ports” tab. COM port has to be setup for the wireless Bluetooth Barcode Scanner to communicate via the Bluetooth Serial Port Profile.
  • Page 48 Rugged Windows Tablet M101SR User Guide 6. You are in “Add COM Port” window. Choose “Incoming (device initiates the connection)”, and click “OK”. 7. The computer will automatically assign COM Port to the Bluetooth connection. In the screenshot below, COM4 is allocated.
  • Page 49 Chapter 5: Frequently Used Settings Click OK to continue. 8. Next, the user has to configure the application that is used to accept the scanned data from the wireless Bluetooth Barcode Scanner. The application has to be configured to accept the same COM Port that has been assigned for the Bluetooth Serial Port Profile in the previous step.

  • Page 50: Set Up The Barcode Scanner For Bluetooth Pairing

    Rugged Windows Tablet M101SR User Guide 5.6.2 Set up the Barcode Scanner for Bluetooth Pairing IMPORTANT The wireless Bluetooth Barcode Scanner has to be configured as Bluetooth Serial Port Profile Master device to establish connection via Bluetooth MAC address barcode label.
  • Page 51 Chapter 5: Frequently Used Settings In order to ensure that Bluetooth Device is successfully pared to the Computer, follow the steps below: 1. Locate the Bluetooth icon in the Notification Area. Select Show Bluetooth Devices. You can access this menu in the Control Panel: Control Panel ...

  • Page 52: Chapter 6: Troubleshooting

    M101S Rugged Tablet User Guide Chapter 6: Troubleshooting 6.1 Basic Troubleshooting Problem Solution  The removable battery is not charging. Make sure the AC adapter is properly connected, and that the removable battery is properly inserted.  Nothing appears on the screen. The tablet computer may be in sleep mode.
  • Page 53 Chapter 6: Troubleshooting  No sound is produced. Adjust volume of the tablet computer by pressing on the volume rocker.  If using an external audio device, make sure that the cable is properly connected.  I cannot project the tablet computer Make sure the VGA driver is installed.

  • Page 54: Appendix A: Order Information

    M101S Rugged Tablet User Guide Appendix A: Order Information M101SR Series Rugged Tablet is available for order in the following configurations: Order Information 1D/2D Barcode HF RFID Reader M101SR M101SR-HF Optional Optional Default M101SR-BH Optional Optional Default M101SR-H2 Optional Optional...
  • Page 56 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © 2018 Winmate Inc. All rights reserved.
