4 SETTING/CHECKING MODES

Besides the ordinary print mode, the printer has the following modes to set or to check
settings of the printer.

Self-test Mode

Hexadecimal Dumping Mode

4.1 Print a Parameter Setting Page (Self-test Page)

Before you connect the printer to the computer, make sure that the printer is in proper
working order.
You can do this by printing a configuration status label.
1. Make sure the media is properly loaded, the top cover of the printer is closed and the
printer is power off. Then, press and hold the Feed button once you are ready.
2. Hold down Feed Key and then switch on printer till Power LED blinks once, buzzer beeps
once.
3. The printer will print out a parameter setting page.
