4M STEAM Motorised Origami Bird Manual

MOTORISED ORIGAMI BIRD
A. SAFETY MESSAGES
1. Please read these instructions carefully before using the product. 2. Adult supervision and assistance are recommended at all times. 3.
This kit is intended for children over 8 years of age. 4. This kit and the finished product contain small parts that present a choking hazard.
Keep away from children under 3 years of age. 5. Only install battery after you have assembled the product. Adult supervision is required.
B. USE OF BATTERY
1. Requires one 1.5V AAA battery (not included). 2. For best results, always use fresh battery. 3. Make sure you insert the battery with the
correct polarities. 4. Remove the battery from the kit when not in use. 5. Replace exhausted battery straight away to avoid possible damage
to the kit. 6. Rechargeable battery must be removed from the kit before recharging. 7. Rechargeable battery should be recharged under
adult supervision. 8. Make sure that the supply terminals in the battery case are not short circuited. 9. Do not attempt to recharge
non-rechargeable battery.
C. CONTENTS
A
G
J
Part A: Gearbox housing x 1, Part B: battery compartment cover x 1, Part C: flower-shaped terminal peg x 4, Part D: flower-shaped terminal
cap x 4, Part E: screw x 1, Part F: washer screw x 2, Part G: bottle hub x 1, Part H: string x 1, Part I: push rod x 1, Part J: adhesive tape x
2, Part K: foam piece x 1, Part L: pipe cleaner x 1, Part M: template x 1, Part N: wire stand x 1, Part O: large origami paper x 2, small origami
paper x 1, detailed instructions. (Also required, but not included in the kit: a small crosshead screwdriver, one 1.5 V AAA battery.)
D. ORIGAMI BIRD
1 2
Make a valley fold and Fold the resulting
ensure the holes are in triangle in half,
the correct orientation widthways.
as shown.
7 8
Fold the left and right Now, open the pocket
corners toward the center by pulling the bottom
line and then fold the top corner up and form a
corner toward the center. diamond shape.
Unfold to leave creases.
:
