Edimax AR-7064Sg+ Specifications

Wireless ADSL 2+ Modem Router
Wireless ADSL 2+ Modem Router
Super-G
108Mbps
Wireless Super
Wireless Super
Integrated 4 Ports 10/100Mbps Switch
- G ADSL 2+ Router
- G ADSL 2+ Router
Features
ADSL Compliance
• ITU-T G.992.2 (G.lite) and G.992.1 (G.dmt)
compliant for Annex A, B, I, J, L, M, and U-R2
• ITU-T G.992.3, G.992.4 for ADSL2
• ITU-T G.992.5 for ADSL2+
• Downstream rates at up to 24Mbps and upstream rates at up to 2Mbps
•Network Protocol and Features
• PPPoA (RFC2364), PPPoE (RFC2516), classical IPOA (RFC1577),
multiple protocol over AAL5 (RFC1483, RFC2684), DHCP client mode
support
• DHCP server and client mode, NAT/NAPT support
• Dynamic Domain Name System (DDNS)
• Software DMZ and Port Forwarding
• 4-port 10/100Mbps Switch with MDI/MDI-X, compliant with IEEE802.3
and 802.3u
• Ethernet to ADSL-self-learning (up to 128MAC) transparent bridging
Management
• Configuration and management via WWW browser with password
protected access
• Firmware upgraded via Web-based GUI
• Easy of use with quick start setup
• Factory default setting reset button
Hardware Interface
• IEEE 802.11b/g and Super-G wireless access point
• Up to 108Mbps wireless operation rate
• Wireless security with up to 128-bit WEP Encryption, WPA-PSK,
802.11x
AR-7064Sg+
