- Page 1 Edimax AR-7284WnA Wireless 11n ADSL 2+ Modem Router Quick Installation Guide Edimax Technology (UK) Limited | Quick Installation Guide (AR-7284WnA) www.edimax.co.uk...
-
Page 2: Hardware Setup
Note: Please use the power adapter provided with the router, do NOT use any other power adapter from other sources. Edimax Technology (UK) Limited | Quick Installation Guide (AR-7284WnA) www.edimax.co.uk... -
Page 3: Router Configuration
To configure the router to the internet, open Internet Explorer, type http://192.168.2.1' into the address bar and press Enter. At the Login page, select ‘'admin', Password, type '1234'. Click 'login'. Step 1 – Click Setup Wizard. Edimax Technology (UK) Limited | Quick Installation Guide (AR-7284WnA) www.edimax.co.uk... - Page 4 Step 2 – Click Next. Step 3 – Tick on Automatically synchronize with Internet time servers. Select GMT time Zone. Click Next. Edimax Technology (UK) Limited | Quick Installation Guide (AR-7284WnA) www.edimax.co.uk...
- Page 5 UK ISPs. If you are not sure what protocol to use, please contact your ISP for their settings. Protocol = PPPoA Encapsulation Mode = VC-Mux VPI = 0 VCI = 38 Then, enter your ISP broadband’s username and password. Click Next to continue. Edimax Technology (UK) Limited | Quick Installation Guide (AR-7284WnA) www.edimax.co.uk...
- Page 6 SSID – by default is edimax_0. This is the default name of your wireless. Select Visible. For Security Level, by default the wireless is unsecure. You can secure the wireless with WPA-PSK. Edimax Technology (UK) Limited | Quick Installation Guide (AR-7284WnA) www.edimax.co.uk...
- Page 7 Select WPA-PSK and enter your own password into WPA Pre-shared key. Please remember this WPA Pre-shared key. You will need this key to connect to the router wirelessly. Click Next. Edimax Technology (UK) Limited | Quick Installation Guide (AR-7284WnA) www.edimax.co.uk...
- Page 8 Step 7 – Internet will be connected and you can check the status by clicking on Status>Internet Info. If the Internet is not connected, repeat the setup wizard. Check your ISP settings and username and password in Step 4. Edimax Technology (UK) Limited | Quick Installation Guide (AR-7284WnA) www.edimax.co.uk...
