ENVIRONMENT
User and Installation Guide
v.21.03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Thingsee and is the answer not in the manual?

Questions and answers

Related Manuals for Haltian Thingsee

Summary of Contents for Haltian Thingsee

  • Page 1 ENVIRONMENT User and Installation Guide v.21.03...
  • Page 2 Welcome to use Thingsee Congratulations on choosing Haltian Thingsee as your IoT solution. We at Haltian want to make IoT easy and accessible for everyone, so we have created a solution platform that is easy to use, scalable and secure. I hope our solution will help you achieve your business goals! Pasi Leipälä...

  • Page 3: Sales Package Content

    In addition, it has an accelerometer and a magnetic switch. Thingsee ENVIRONMENT’s magnetic switch recognition can be used to monitor the open/closed position of doors and windows, and the ambient light sensor can recognize if the lights are on or off.

  • Page 4: Note Before Installation

    Note before installation Please make sure the Thingsee gateway device is installed before you install the sensor. To ensure strong enough signal strength for data delivery, keep the maximum distance between installed sensors under 20 m. If the distance between a measuring sensor and the gateway is > 20 m...
  • Page 5 Escalators Nearby heating or cooling devices and/or vents Direct sun light Nearby halogen lamps, fluorescent lamps or similar lamps with hot surface Nearby radio equipment like WiFi routers or any other similar high power RF transmitters Inside metal box or covered with a metal plate Inside or underneath a metal cabinet or box Near elevator motors or similar targets causing a strong magnetic field...

  • Page 6: Installation

    Installation Please make sure the Thingsee gateway device is installed before you install the sensors. To identify the sensor, read the QR code on the front of the device with a QR code reader or Thingsee installation application on your mobile device.

  • Page 7: Changing The Batteries

    Clean the surface you will attach the sensor to with IPA -solvent (isopropyl alcohol). Remove the tape’s paper cover from the backside of the sensor. Tape with paper cover Attach the sensor to its place by pushing it firmly against the surface for a minimum of 5 seconds.
  • Page 8 When the sensor is on the installed surface: Installation surface B-cover B-cover Place the opening A-cover key to the Bend the hole on the key to the side of the direction sensor shown Place the batteries inside the B-cover. Batteries Attach the A-cover to the B-cover attached to the installed surface.

  • Page 9: Environment Monitoring

    Thingsee ENVIRONMENT is used to monitor doors and windows with the magnet holder accessory. The magnet holder is attached to the door or window, and Thingsee ENVIRONMENT is attached to the frame, so that when the door/window is closed, the sensor detects the magnet by its side.

  • Page 10: Magnet Position

    Magnet positions The small magnet inside the magnet holder accessory is positioned so that the magnet is aligned with the magnetic switch inside Thingsee ENVIRONMENT. The magnetic switch is on the left side of the device. When the magnet holder comes across the sensor device, the magnet is placed in magnet position 1 (see image 1).
  • Page 11 Machine usage mode Thingsee ENVIRONMENT’s accelerometer can detect the smallest of G-forces so it can be used to detect the vibration of small or big machines. The device is simply installed to where the vibration of the machine is felt when it’s turned on.

  • Page 12: Detection Capability

    Detection capability Temperature -40 ºC to + 85 ºC. Recommended to -20º C to • +50 ºC due to primary battery specification. Accuracy ±0,3 ºC. Humidity can be measured between 0 - 100 % RH. • Accuracy ±5 %. • Accelerometer reports orientation or vibrations count in machine usage monitoring mode from 0 - 8G and 0 - 16G in high movement mode.

  • Page 13: Other Default Settings

    Other default settings • Battery reporting interval 6 hours • Sensor is in routing mode Changing the default settings The following parameters are configurable remotely over Thingsee Operations Cloud • Measurement interval • Reporting interval • Event based reporting thresholds •...

  • Page 14: Device Info

    Up to 4 years with 1 minute interval Up to 6 years with 15 minutes interval Up to 4 years with Machine Usage Mode Radio sensitivity: -95 dBm (BTLE) More device info can be found at support.haltian.com Device measurements Weight: 35 g (including batteries)
  • Page 15 CERTIFICATION IN CERTIFICATION INFORMATION EU DECLARATION OF CONFORMITY Hereby, Haltian Products Oy declares that the radio equipment Thingsee AIR is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: haltian.com Haltian Products Oy vakuuttaa, etta radiolaitetyyppi Thingsee AIR on direktiivin 2014/53/EU mukainen.
  • Page 16 - Do not paint the device. Paint can prevent proper operation. Damage If the device is damaged contact support@haltian.com. Only qualified personnel may repair this device. Small children Your device is not a toy. It may contain small parts. Keep them out of the reach of small children.
  • Page 17 Get to know other Thingsee devices Thingsee PRESENCE Thingsee ENVIRONMENT Thingsee BEAM Thingsee LEAKAGE Thingsee ENVIRONMENT Thingsee ANGLE RUGGED RUGGED RUGGED Thingsee AIR Thingsee GATEWAY Thingsee GATEWAY Thingsee GATEWAY GLOBAL For all devices and more information, visit our website www.haltian.com or contact sales@haltian.com...
