- Page 1 PRESENCE User and Installation Guide v.21.01...
- Page 2 Welcome to use Thingsee IoT Solution Suite Congratulations on choosing Haltian Thingsee as your IoT solution. We at Haltian want to make IoT easy and accessible for everyone, so we have created a solution platform that is easy to use, scalable and secure.
- Page 3 Thingsee Visitor Counter Dome is available for this purpose. Using workspace occupancy detection Thingsee PRESENCE can be installed under a table to detect the usage of a working space. Sensor sensitivity should be decreased to avoid unwanted detections outside the working space. This is possible with Thingsee Occupancy Dome.
- Page 4 Thingsee PRESENCE detection capability changes related to the height of the space. Following chart describes different distances. Adjusted sensitivity levels shown as white lines inside the maximum area are for illustration purposes only.
-
Page 5: Changing The Batteries
Things to avoid in installation Nearby heating or cooling devices and/or vents. Direct sun light. Nearby halogen lamps or similar lamps with hot surface. Places where a door or a similar object can block the required detection area. Attachment to surfaces which can vibrate as it may cause false functionality. -
Page 6: Installation
QR code reader or Thingsee installation application on your mobile device. Identifying the device is not necessary, but it will help you keep track of your IoT installation and help Haltian support to solve possible issues. QR code Carefully pull out the battery security tab. - Page 7 5-10 cm wall door Installing the sensor to a door opening Install Thingsee PRESENCE sensor to the top middle of the door opening. Make sure that there are no objects between the sensor and the area to be detected. roof...
- Page 8 The detection beam can easily be adjusted with a separate, easy to install, Visitor Counter Dome. It makes the detection beam more accurate. Note that with the Dome, the detection area is narrowed related to the long side of the Thingsee PRESENCE sensor. Attachment Clips Detection area shape Detection area shape and dimension related to the most common installation distances.
- Page 9 Installing the sensor under a table Install Thingsee PRESENCE under the table as middle as possible. If there are any objects, such as table legs, under the table, place the sensor on the user side of the object. Make sure there is 50 mm gap between Thingsee PRESENSE and the object so that it can be easily maintained.
-
Page 10: Device Info
Good to know about installing the Dome The Dome can be attached with screws to ensure the installation. Use a correct screw type! When using the attachment clips only, the screw attachement parts can be cut off. Do not damage attachment clips while cutting! Device info Operating temperature: -20 °C …... - Page 11 The following parameters are configurable remotely over Thingsee Operations Cloud • Reporting interval • Sensor sensitivity level Mesh network node role configuration • Routing • Non-routing Movement indication LED ON/OFF For further information, please refer to Haltian support pages at: https://support.haltian.com/...
- Page 12 Hereby, Haltian Products Oy declares that the radio equipment Thingsee PRESENCE is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.haltian.com Haltian Products Oy vakuuttaa, etta radiolaitetyyppi Thingsee PRESENCE on direktiivin 2014/53/EU mukainen. EU- vaatimustenmukaisuusvakuutuksen täysimittainen teksti on saatavilla seuraavassa internetosoitteessa: www.haltian.com...
- Page 13 - Do not paint the device. Paint can prevent proper operation. Damage If the device is damaged contact support@haltian.com. Only qualified personnel may repair this device. Small children Your device is not a toy. It may contain small parts. Keep them out of the reach of small children.
- Page 14 Get to know other Thingsee devices Thingsee PRESENCE Thingsee ENVIRONMENT Thingsee DISTANCE Thingsee AIR Thingsee BEAM Thingsee LEAKAGE Thingsee ENVIRONMENT Thingsee ANGLE RUGGED RUGGED RUGGED Thingsee GATEWAY Thingsee GATEWAY Thingsee GATEWAY GLOBAL For all devices and more information, visit our website www.haltian.com or contact sales@haltian.com...
