- Page 1 INSTRUCTION MANUAL 21" 2-in-1 Gas Push Lawn Mower Model # DB2194C Have product questions or need technical support? Please feel free to contact us! Website: www.Amerisuninc.com www.powersmartusa.com Toll free: 1-800-791-9458 Mon-Fri 9-5 EST Email: support@amerisuninc.com...
-
Page 3: Table Of Contents
Maintenance……………………………………………………………... Storage……………………………………………………………………. 16 Troubleshooting…………………………………………………………. Exploded view & parts list……………………………………………… Warranty………………………………………………………………… TECHNICAL DATA 21" 2-in-1 Gas Push Lawn Mower Model # DB2194C Engine type: 4 stroke, OHV, single cylinder with forced air cooling system Displacement: 161cc Fuel tank capacity: 0.21 Gallon Oil capacity: 15.2fl.oz... -
Page 4: Introduction
INTRODUCTION ® Thank You for Purchasing a PowerSmart Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the ® information in this manual. PowerSmart reserves the right to change this product and specifications at any time without prior notice. -
Page 5: General Safety Procedures
GENERAL SAFETY PROCEDURES For any questions regarding the hazard and safety notices listed in this manual or on the product, please call (800) 791-9458 Mon-Fri 9-5 EST before using the lawn mower. DANGER: CARBON MONOXIDE Using an engine indoors CAN KILL YOU IN MINUTES. Engine exhaust contains carbon monoxide (CO). -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS General Operation Read, understand, and follow all instructions on the machine and in the manual(s) before starting. 1. Do not put hands or feet near or under the machine. Keep clear of the discharge opening at all times. 2. - Page 7 4. Use extra care when approaching blind corners, shrubs, trees, or other objects that may block your view of a child. Service 1. Safe Handling of Gasoline 2. To avoid personal injury or property damage, use extreme care in handling gasoline. Gasoline is extremely flammable and the vapors are explosive.
-
Page 8: Knowing Your Lawn Mower
KNOWING YOUR LAWN MOWER Please use the illustration below to familiarize yourself with the location and function of the components that control of your lawn mower. Recoil starter handle Cutting height adjustment lever Cutting height adjustment lever Primer bulb Rear wheel Gas tank cap Side discharge chute Lower handle... -
Page 9: Lawn Mower Preparation
LAWN MOWER PREPARATION The following section describes steps necessary to prepare the lawn mower for use. If after reading this section, you are unsure about how to perform any of the steps please call (800)791-9458 Mon-Fri 9-5 EST for customer service. Failure to perform these steps properly can damage the lawn mower or shorten its lifespan. - Page 10 ATTACH LOWER & UPPER HANDLE 1. Take lower handle and line up the hole in the lower handle with the hole on the handle bracket. 2. Secure the lower handle with Sleeve with provided M6 Hexagonal flange bolts on each side. flange bolts 3.
- Page 11 SIDE DISCHARGE CHUTE 1. Lift the spring-loaded discharge cover located on the side of the mower. 2. Slide two hooks of the side discharge chute under the hinge pin and lower the spring on the side discharge cover. Caution: Do not attempt to remove the permanently mounted spring loaded side discharge cover at any time.
-
Page 12: Operation
OPERATION ADD OIL The lawn mower is shipped without oil. User must add the proper amount of oil before operating the lawn mower for the first time. The oil capacity of the engine crankcase is 15.2 fl. oz. For general use, we recommend 5W, 4-stroke engine oil. - Page 13 ENGINE START/STOP LEVER Engine start/stop lever This lawn mower comes equipped with an engine start/stop lever to prevent unintentional starting and to ensure safe operation. Releasing this lever will quickly stop the blade in case of danger. The lever must be actuated before the lawn mower is started.
- Page 14 Turn off the engine before doing any checks on the blade. Keep in mind that the blade continues to rotate for a few seconds after the engine has been turned off. Never attempt to manually stop the blade. Regularly check to see if the blade is securely attached, is in good condition and is sharp. If the contrary is the case, sharpen the blade or replace it.
-
Page 15: Maintenance
MAINTENANCE Proper routine maintenance of this mower will help prolong the life of the machine. Always observe safety rules when performing any maintenance. The warranty on this lawn mower does not cover items that have been subjected to operator abuse or negligence. -
Page 16: Storage
STORAGE CAUTION: Never place any type of storage cover or tarp on the MOWER while it is still hot. If the MOWER is being stored for short periods of time (30 to 60 days), add stabilized fuel to the gas tank until it is full. -
Page 17: Troubleshooting
TROUBLESHOOTING Problem Cause Solution Engine start/stop lever Engage engine start/stop lever. disengaged. Spark plug wire disconnected. Connect spark plug wire. Fuel tank empty or stale fuel. Fill tank with clean, fresh gasoline. Engine fails to start Engine not primed. Press primer bulb. Faulty spark plug. -
Page 18: Exploded View & Parts List
EXPLODED VIEW AND PARTS LIST... - Page 19 Item Stock# Description Item Stock# Description 1 303190275 Engine 203050386 8" Right wheel 2 303042023 Flat washer 303060133 Axle sleeve Rear adjustment 3 303041022 Washer 303180938 spring leaf assembly 4 303020265 Hex washer screw 303071059 Rear axle seaming Side discharge 5 203050381 203021112 Wheel sleeve deflector...
- Page 20 ENGINE EXPLODED VIEW AND PART LIST...
- Page 21 Item Stock# Description Item Stock# Description 5787.06012.00.01 Reel bolt M6x12 0096.06000.00.01 Flat mat E65.0001.001.00.00 Cylinder head cover E65.3200.C01.04.02 Fuel tank cap E65.3000.001.00.00 Gasket, cylinder head cover 5787.06025.00.01 Reel bolt M6x25 E65.0100.001.00.00 Rocker assembly E65.3200.C01.04.01 Fuel tank E65.0100.001.00.04 Lock nut P70.3208.001.00.00 Filter E65.0100.001.00.03 Adjusting nut...
- Page 22 To make a claim under this Limited Warranty, you must return the entire power tool product; transportation prepaid, to PowerSmart. The owner must include a legible copy of the original receipt, which shall list the date of purchase, along with the company’s name where the product was purchased.
