- Page 1 INSTRUCTION MANUAL 21" 3-in-1 Self Propelled Lawn Mower Model # DB2194S Have product questions or need technical support? Please feel free to contact us! Website: www.Amerisuninc.com www.powersmartusa.com Toll free: 1-800-791-9458 Mon-Fri 9-5 EST Email: support@amerisuninc.com...
-
Page 3: Table Of Contents
Storage……………………………………………………………………. 17 Troubleshooting…………………………………………………………. Exploded view & parts list……………………………………………… Warranty………………………………………………………………… TECHNICAL DATA 21" 3-in-1 Self Propelled Lawn Mower Model # DB2194S Engine type: 4 stroke, OHV, single cylinder with forced air cooling system Displacement: 161 cc Fuel tank capacity: 0.21 Gallon Oil capacity: 15.2 fl.oz... -
Page 4: Introduction
INTRODUCTION ® Thank You for Purchasing a PowerSmart Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the ® information in this manual. PowerSmart reserves the right to change this product and specifications at any time without prior notice. -
Page 5: General Safety Procedures
GENERAL SAFETY PROCEDURES For any questions regarding the hazard and safety notices listed in this manual or on the product, please call (800) 791-9458 Mon-Fri 9-5 EST before using the lawn mower. DANGER: CARBON MONOXIDE Using an engine indoors CAN KILL YOU IN MINUTES. Engine exhaust contains carbon monoxide (CO). -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS General Operation Read, understand, and follow all instructions on the machine and in the manual(s) before starting. 1. Do not put hands or feet near or under the machine. Keep clear of the discharge opening at all times. 2. - Page 7 4. Use extra care when approaching blind corners, shrubs, trees, or other objects that may block your view of a child. Service 1. Safe Handling of Gasoline 2. To avoid personal injury or property damage, use extreme care in handling gasoline. Gasoline is extremely flammable and the vapors are explosive.
-
Page 8: Knowing Your Lawn Mower
KNOWING YOUR LAWN MOWER Please use the illustration below to familiarize yourself with the location and function of the components that control of your lawn mower. Recoil starter handle Primer Bulb Grass catcher Fuel tank cap Cutting height adjustment lever Rear discharge door Rear wheel Lower handle... -
Page 9: Lawn Mower Preparation
LAWN MOWER PREPARATION The following section describes steps necessary to prepare the lawn mower for use. If after reading this section, you are unsure about how to perform any of the steps please call (800) 791-9458 Mon-Fri 9-5 EST for customer service. Failure to perform these steps properly can damage the lawn mower or shorten its lifespan. -
Page 10: Recoil Starter Handle
ATTACH LOWER & UPPER HANDLE 1. Take lower handle and line up the hole in the lower handle with the hole on the handle bracket. 2. Secure the lower handle with Sleeve with provided M6 Hexagonal flange bolts on each side. flange bolts 3. -
Page 11: Grass Catcher
GRASS CATCHER Attach grass catcher 1. Lift mower rear discharge door. 2. Place grass catcher into the slots in the handle brackets. 3. Release the rear discharge door so that it rests on the grass catcher. Remove grass catcher 1. Lift mower rear discharge door. 2. -
Page 12: Cutting Height Adjustment Lever
ADJUSTING THE CUTTING HEIGHT Warning! Cutting height adjustments should only be performed after the engine and blades have come to a complete stop! It is always best to begin cutting your lawn with a higher deck height to prevent scalping your lawn. The cutting height is adjusted with a single lever. -
Page 13: Operation
OPERATION ADD OIL The lawn mower is shipped without oil. User must add the proper amount of oil before operating the lawn mower for the first time. The oil capacity of the engine crankcase is 15.2 fl. oz. For general use, we recommend 5W, 4-stroke engine oil. -
Page 14: Side Discharge Chute
This lawn mower comes equipped with an engine start/stop lever to Engine start/stop lever prevent unintentional starting and to ensure safe operation. Releasing this lever will quickly stop the blade in case of danger. The lever must be actuated before the lawn mower is started. When the engine start/stop lever is released, it must return to its initial position. -
Page 15: Oil Dipstick
Always mow along inclines (not up and down). You can prevent the lawn mower from slipping down by holding a position at an angle upwards. Select the cutting height according to the length of the grass. If necessary, mow a number of times so that you never cut more than 2 inches of grass in one go. Turn off the engine before doing any checks on the blade. -
Page 16: Maintenance
MAINTENANCE Proper routine maintenance of this mower will help prolong the life of the machine. Always observe safety rules when performing any maintenance. The warranty on this lawn mower does not cover items that have been subjected to operator abuse or negligence. -
Page 17: Storage
STORAGE CAUTION: Never place any type of storage cover or tarp on the MOWER while it is still hot. If the MOWER is being stored for short periods of time (30 to 60 days), add stabilized fuel to the gas tank until it is full. -
Page 18: Troubleshooting
TROUBLESHOOTING Problem Cause Solution Engine start/stop lever Engage engine start/stop lever. disengaged. Spark plug wire disconnected. Connect spark plug wire. Fuel tank empty or stale fuel. Fill tank with clean, fresh gasoline. Engine fails to start Engine not primed. Press primer bulb. Faulty spark plug. -
Page 19: Exploded View & Parts List
EXPLODED VIEW AND PARTS LIST... - Page 20 Item Stock# Description Item Stock# Description 303190275 Engine 303160470 Advance gear Right 303042023 Fflat washer 303123017A Cylindrical pin 303041022 Washer 203010750 Rear defense cover Hex washer screw 303020265 303180942 Rear self drive axle seaming M8×30mm 203050381 Side discharge deflector 303071059 Rear adjustment spring leaf 303090066A Spring pin shaft...
- Page 21 ENGINE EXPLODED VIEW AND PART LIST...
- Page 22 Item Stock # Description Item Stock # Description 5787.06012.00.01 Reel bolt M6x12 0096.06000.00.01 Flat mat E65.0001.001.00.00 Cylinder head cover E65.3200.C01.04.02 Fuel tank cap E65.3000.001.00.00 Gasket, cylinder head cover 5787.06025.00.01 Reel bolt M6x25 E65.0100.001.00.00 Rocker assembly E65.3200.C01.04.01 Fuel tank E65.0100.001.00.04 Lock nut P70.3208.001.00.00 Filter E65.0100.001.00.03...
- Page 23 To make a claim under this Limited Warranty, you must return the entire power tool product; transportation prepaid, to PowerSmart. The owner must include a legible copy of the original receipt, which shall list the date of purchase, along with the company’s name where the product was purchased.
