INSTRUCTION MANUAL
EN 21" 2-in-1 GAS PUSH LAWN MOWER
ES 21" 2-en-1 CORTADORA DE CÉSPED A GASOLINA
Model # DB2194CR
Have product questions or need technical support? Please feel free to contact us!
Website:
www.Amerisuninc.com
www.powersmartusa.com
Toll free: 1-800-791-9458 Mon-Fri 9-5 EST
Email: support@amerisuninc.com
Advertisement
Table of Contents
Related Manuals for Powersmart DB2194CR
Summary of Contents for Powersmart DB2194CR
- Page 1 INSTRUCTION MANUAL EN 21" 2-in-1 GAS PUSH LAWN MOWER ES 21" 2-en-1 CORTADORA DE CÉSPED A GASOLINA Model # DB2194CR Have product questions or need technical support? Please feel free to contact us! Website: www.Amerisuninc.com www.powersmartusa.com Toll free: 1-800-791-9458 Mon-Fri 9-5 EST...
-
Page 3: Table Of Contents
Maintenance……………………………………………………………... Storage……………………………………………………………………. 18 Troubleshooting…………………………………………………………. Exploded view & parts list……………………………………………… Warranty………………………………………………………………… TECHNICAL DATA 21 inch 2-in-1 Gas Push Lawn Mower Model # DB2194CR Engine type: 4 stroke, OHV, single cylinder with forced air-cooling system Displacement: 170cc Fuel tank capacity: 0.40 Gallon Oil capacity: 16.9 fl.oz... -
Page 4: Introduction
INTRODUCTION ® Thank You for Purchasing a PowerSmart Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the information in this manual. PowerSmart ® reserves the right to change this product and specifications at any time without prior notice. -
Page 5: General Safety Procedures
GENERAL SAFETY PROCEDURES For any questions regarding the hazard and safety notices listed in this manual or on the product, please call (800) 791-9458 Mon-Fri 9-5 EST before using the engine. DANGER: CARBON MONOXIDE Using an engine indoors CAN KILL YOU IN MINUTES. Engine exhaust contains carbon monoxide (CO). -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death. I.General Operation 1. Read, understand, and follow instructions and warnings in this manual and on the machine, engine and attachments. - Page 7 V. SLOPE SPECIFIC Slopes are a major factor related to accidents. Operation on slopes requires extra caution. 1. Travel in the manufacturer recommended direction on slopes. Use caution while operating near drop offs. 2. Avoid mowing wet grass. (Poor footing could cause a slip and fall accident.) 3.
- Page 8 WARNING LABLE INSTRUCTIONS Read carefully the manual before use. Danger-flying objects; keep safe distance from the machine as long as the engine is running. Do not open or remove safety shields while engine is running. Pay more attention to the operator’s hands and feet to avoid injury. Do not open or remove safety shields while engine is running.
- Page 9 Look behind while backing Steep slope hazard When mowing,please wear the glasses ad ear plugs to defend the operator himself When repairing, please pull off the spark plug boot, then repair it according to the operational manual Hot surfaces Keep bystanders away. Safety label found on the lawn mower: KEEP HANDS AND FEET AWAY.
-
Page 10: Knowing Your Lawn Mower
KNOWING YOUR LAWN MOWER Please use the illustration below to familiarize yourself with the location and function of the components that control of your lawn mower. Recoil Starter handle Cutting height adjustment lever Cutting height adjustment lever Primer bulb Rear wheel Lower handle Side discharge chute Upper handle... -
Page 11: Lawn Mower Preparation
LAWN MOWER PREPARATION The following section describes steps necessary to prepare the lawn mower for use. If after reading this section, you are unsure about how to perform any of the steps please call (800)791-9458 Mon-Fri 9-5 EST for customer service. Failure to perform these steps properly can damage the lawn mower or shorten its lifespan. - Page 12 3. Lock the cable to the lower handle using cable clip. Cable Clip 4. Insert the recoil starter handle cable into the hook provided on the upper handle. You must engage the start/stop control to release the recoil starter handle. Start/Stop Control Recoil starter handle SIDE DISCHARGE CHUTE...
-
Page 13: Operation
ADJUSTING THE CUTTING HEIGHT Warning! Cutting height adjustments should only be performed after the engine and blades have come to a complete stop! It is always best to begin cutting your lawn with a higher deck height to prevent scalping your lawn. The cutting height is adjusted with front and rear levers. - Page 14 Adding Gasoline 1. Remove the fuel tank cap and check fuel level. 2. If the level is too low, refuel the tank, remember adding fuel not over the fuel upper level. Warning: 1. Gasoline is extremely flammable and is explosive under certain conditions. 2.
- Page 15 START THE ENGINE To start the engine, perform the following steps: 1. Check the oil and fuel levels. 2. Press the primer bulb 3 times. 3. Engage the engine Start/Stop Control and simultaneously pull on the recoil starter. Pull on the recoil starter handle slowly until a slight resistance is felt, then pull quickly to start the engine.
-
Page 16: Maintenance
MAINTENANCE Proper routine maintenance of this mower will help prolong the life of the machine. Always observe safety rules when performing any maintenance. The warranty on this lawn mower does not cover items that have been subjected to operator abuse or negligence. - Page 17 CHECKING THE OIL The oil capacity of the engine crankcase is 16.9 fl. oz. Check the oil level of the engine according to the Recommended Maintenance Schedule. The lawn mower should be checked before each use for proper oil level. This is a critical step for proper engine starting.
-
Page 18: Storage
2. Unscrew the spark plug from the engine using the spark plug wrench provided. There is limited space for the wrench to turn. Use both rows of holes in the spark plug wrench to gain leverage to loosen the plug. 3. -
Page 19: Troubleshooting
3. Remove the spark plug. Use an oil-can to fill the cylinder with approx. 2 ml of oil. Slowly pull back the starter handle, which will bathe the cylinder wall with oil. Screw the spark plug back in. 4. Clean the cooling fins of the cylinder and the housing. 5. -
Page 20: Exploded View & Parts List
EXPLODED VIEW AND PARTS LIST... - Page 21 Item Stock# Description Item Stock# Description 303190312 Engine 303020558 Screw M6x35 303020241 Bolt M8x25 203050386 8 inch Right wheel Rear adjustment spring 203050381 Side discharge deflector 303071059 leaf assembly 303090066A Spring pin shaft 303180938A Rear axle seaming 303130335 Torsional spring 203050387 8 inch Left wheel 303160456...
- Page 22 Engine explode view and part list...
- Page 23 Item Stock # Description Item Stock # Description E01-1 11310-Z3C0110-00A0 CRANKCASE SUBASSEMBLY. E04-3 90408-Z030210-0000 WASHER， FLAT E01-2 90682-Z240110-0000 SEAL, OIL E04-4 14200-Z2P0110-00A0 CAMSHAFT ASSY. E01-3 90682-Z030210-0000 SEAL, OIL E04-5 13122-Z240110-00A0 CLIP, PISTON PIN E01-4 90103-0410-51 SCREW E04-6 13121-Z240110-00A0 PIN, PISTON E01-5 11321-Z2P0110-0000 PIECE, BREATH...
- Page 24 To make a claim under this Limited Warranty, you must return the entire power tool product; transportation prepaid, to PowerSmart. The owner must include a legible copy of the original receipt, which shall list the date of purchase, along with the company’s name where the product was purchased.
