NEC MultiSync PA322UHD-2 User Manual page 13

Detaching the HDMI and DisplayPort Input Card
Caution: Do not touch the option board immediately after it has been removed.
1. Turn off the power of your computer, monitor and other connected equipments.
2. Connect attached thumbscrews to the holes on the HDMI and DisplayPort Input Card (Figure G.1).
3. Disconnect outside screws (Figure G.2).
4. Pull out the HDMI and DisplayPort Input Card using the thumbscrews (Figure G.3).
NOTE: When you use slot 2 type option board accessories, please contact your supplier for detailed information.
Refer to the option board's manual for further information.
Depending on the option board which you use, some OSD functions may not be activated.
Use the 2 screws removed from the monitor to attach the option board to the monitor.
You can use only the option board which supports power supply under 16V/1.25A.
Select ADVANCED in OFF MODE to allow the monitor to supply power to option board slot during power saving
mode (see page 23).
Figure G.1
Figure G.2
Figure G.3
English-11
