Marine coaxial loudspeakers with transflective rgb led lighting (optional) (9 pages)
Summary of Contents for JL Audio C1-650
Page 1
Should you have any questions regarding the instructions in this manual, please contact your authorized JL Audio dealer for assistance, or call the JL Audio Technical Support Department at (954) 443-1100 during business hours (USA - Eastern Time Zone).
Page 2
1.96 in. / 50 mm Height (B) 0.90 in. / 23 mm Depth (C) 1.34 in. / 34 mm Due to ongoing product development, all specifications are subject to change without notice. 2 | JL Audio - C1-650 Owner’s Manual...
C1-650 SPECIFICATIONS: GETTING STARTED • Turn off the audio system. It is also advisable to disconnect the negative (–) Continuous Power Handling: 50 Watts terminal of your vehicle’s battery whenever Recommended Amp Power: 10-75 Watts per channel (RMS) performing installation work.
Page 4
For this reason, they are generally more desirable than higher mounting locations. Higher mounting locations often result in extreme near- side soundstage bias which compromises the stereo listening experience. 4 | JL Audio - C1-650 Owner’s Manual...
TWEETER INSTALLATION CROSSOVER NETWORK INSTALLATION C1 tweeters have been designed for surface The crossover networks supplied with your C1 or flush-mounting. Before choosing a method, System should be installed in a dry location inside carefully inspect the desired mounting location your vehicle.
5) Using a 1/4-inch (6 mm) drill bit, drill the hole for the tweeter’s wires at the location you marked in step 3. 6) Screw the surface-mount fixture to the vehicle panel using the supplied #6 sheet metal screws (hand-tighten). 6 | JL Audio - C1-650 Owner’s Manual...
DIAGRAM E: Flush-Mount Tweeter Installation < > 10 mm length 25 mm length Stud bolts are provided in two lengths to accommodate different panel thicknesses. FLUSH-MOUNT INSTALLATION 1) Detach the preinstalled surface-mount 6) Attach the spring clip from behind the panel using fixture by inserting a small flat screwdriver the supplied M5 nut and tighten by hand until the into the slots behind the tweeter flange...
Page 8
WA R N I N G Hand-tighten the screws evenly in a criss-cross pattern to avoid bending the speaker frame or stripping the mounting screws. 8 | JL Audio - C1-650 Owner’s Manual...
Page 9
DIAGRAM F: Speaker Installation with Adaptor Ring (GM applications) DIAGRAM G: Speaker Installation with Adaptor Ring (Honda/other applications)
Page 12
JL AUDIO dealer. Should service be necessary under this warranty for any reason due to manufacturing defect or malfunction, JL AUDIO will (at its discretion), repair or replace the defective product with new or remanufactured product at no charge. Damage caused by the following is not covered under warranty: accident, misuse, abuse, product modification or neglect, failure to follow installation instructions, unauthorized repair attempts, misrepresentations by the seller.
