Assembly Instructions
Models:
TXRT236, TXRCT236
TXRRT236, TXRBT236
__(1) Table top
__(4) Leg
__(2) Foot
__(2) Brace
__(1) Umbrella Brace
__(1) Hardware pack
TOOLS NEEDED
4mm HEX KEY: INCLUDED
Qty.
Description
1
Table plug
1
A - 1 1/2" Bolt
4
B - 2 1/2" Bolt (fine thread)
C - 14x2 1/2" Screw
8
6
D - 14x3" Screw
Step 1
Attach feet to legs using
(4) 2 1/2" Chair bolts (
Step 3
Attach leg braces using
(4) 3" screws
(fine thread
)
Attach umbrella brace to
the leg braces using (2) 3" screws.
Install 1 1/2" bolt into threaded insert on
the umbrella brace.
Set table upright and tighten all bolts
fine thread
)
B
Step 2
Lay the table top on a flat surface.
Attach the leg assemblies to the table top using
(8) 2 1/2" screws.
C
D
A
D
C
D
D
10/27/2010
