TRUE
manufacturing co
CONGRATULATIONS!
You have just purchased the finest commercial refrigerator
available. You can expect many years of trouble-free operation.
TABLE OF CONTENTS
WARRANTY
TRUE MANUFACTURING CO., INC.
2001 East Terra Lane • O'Fallon, Missouri 63366-4434
(636)-240-2400 • FAX (636)-272-2408 • INT'L FAX (636)272-7546 • (800)-325-6152
Parts Department (800)-424-TRUE • Parts Department FAX# (636)-272-9471
Web: www.truemfg.com
.,
.
inc
1
2
3
4
4
5
6
6
10
16
17
18
19
tmw
INSTALLATION MANUAL
tmw
TMW-36F-QT-SD
TMW-36F-FT-SD
INSTALLATION MANUAL
-
true meat well
-
true meat well
Advertisement
Table of Contents
Related Manuals for True Manufacturing Company TMW-36F-QT-SD
Summary of Contents for True Manufacturing Company TMW-36F-QT-SD
-
Page 1: Table Of Contents
Proper Disposal, Connecting Electricity, & Adapter Plugs INSTALLATION Ownership, Uncrating, & How to Connect to Electricity Wire Gauge Chart Locating and Leveling SETUP Standard Accessories TMW-36F-QT-SD OPERATION Startup Mechanical Temperature Controls Sequence of Operation Electronic Temperature Controls Sequence of Operation MAINTENANCE, CARE, CLEANING Cleaning Condenser Coil... -
Page 2: Safety Information
TRUE truemfg NOTICE TO CUSTOMER Loss or spoilage of products in your refrigerator/ freezer is not covered by warranty. In addition to following recommended installation procedures you must run the refrigerator/freezer 24 hours prior to usage. SAFETY INFORMATION How to Maintain Your True Refrigerator to Receive the Most Efficient and Successful Operation. You have selected one of the finest commercial refrigeration units made. -
Page 3: Proper Disposal, Connecting Electricity, & Adapter Plugs
TRUE truemfg DANGER! WARNING! RISK OF CHILD HOW TO CONNECT ELECTRICITY DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR ENTRAPMENT REMOVE THE GROUND PRONG FROM THE POWER CORD. FOR PERSONAL SAFETY, THIS APPLIANCE MUST BE PROPERLY GROUNDED. PROPER DISPOSAL OF THE REFRIGERATOR The power cord from this appliance is equipped with a grounding Child entrapment and suffocation are not problems of the past. -
Page 4: Installation
TRUE truemfg INSTALLATION OWNERSHIP ELECTRIC INSTALLATION & SAFETY INFORMATION To ensure that your unit works properly from the first day, it must be installed properly. We highly recommend a trained refrigeration • If the supply cord is damaged, it must be replaced by a special mechanic and electrician install your TRUE equipment. -
Page 5: Wire Gauge Chart
TRUE truemfg WIRE GAUGE CHART 115 Volt s Distance In Feet To Center of Load 230 Volts Distance In Feet To Center of Load Amps 20 30 40 50 60 70 80 90 100 120 140 160 Amps 20 30 40 50 60 70 80 90 100 120 140 160 LOCATING LEVELING A. -
Page 6: Setup
TRUE truemfg SETUP STANDARD ACCESSORIES MODELS TMW-36F AND TMW-36-F-QT REVERSIBLE LID INSTRUCTIONS A. Remove lid. See figure 1. Lift top cover off unit and rotate 180 degrees. See figures 2 & 3. C. Lower top cover onto locking pins. See figure 4. D. -
Page 7: Operation
TRUE truemfg OPERATION STARTUP A. The compressor is ready to operate. Plug in the cooler. D. Good air flow in your TRUE unit is critical. Be careful to load product so that it neither presses against the back wall, Temperature control gives freezers an approximate temperature nor comes within four inches of the evaporator housing. - Page 8 TRUE truemfg WHEN TO MAKE AN ADJUSTMENT TO A MECHANICAL TEMPERATURE CONTROL We advise to make a mechanical temperature control adjustment only for a high altitude location. HOW TO ADJUST A MECHANICAL TEMPERATURE CONTROL OPERATION INSTRUCTIONS: Scale Guide for Measuring Back of Temperature Control REQUIRED TOOLS: Compressor...
- Page 9 TRUE truemfg INSTRUCTIONS: DANFOSS TEMPERATURE CONTROL ADJUSTMENT FOR HIGH ALTITUDE APPLICATIONS STEP 1 - Unplug cooler. STEP 2 - Remove the screws that secure the temperature control to the inset box. STEP 3 - To make these adjustments it may be necessary to remove the temperature control from the housing. NOTE: You may have to remove the wires attached to the control.
- Page 10 TRUE truemfg CHART CCW Adjustment (based on 360°/ Height complete turn) 2000' 42° 3000' 78° 4000' 114° 5000' 150° 6000' 186° 7000' 222° 8000' 258° 9000' 294° 10,000' 330° BUL. NO.
-
Page 11: Electronic Temperature Controls Sequence Of Operation
TRUE truemfg ELECTRONIC TEMPERATURE CONTROLS LAE ELECTRONIC TEMPERATURE CONTROL GENERAL SEQUENCE OF OPERATION t1 = Thermostat t2 = Defrost t3 = Display t3 probe is not installed and / or activated in all applications when t3 is not installed and / or activated, the display probe is t1. LAE MODEL TMW ELECTRONIC CONTROL GENERAL SEQUENCE OF OPERATION 1. - Page 12 TRUE truemfg HOW TO DIAGNOSE AN LAE ELECTRONIC CONTROL Indicator lights for Refrigeration/Heating Mode, Fan Operation, Defrost Mode. LAE Control LAE Control Icons Compressor Running Evaporator Fan Running Cabinet in Defrost Activation of 2nd Parameter Set Alarm Info / Set Point Manual Defrost / Manual Activation Stand-By...
- Page 13 TRUE truemfg LAE Control Info / Set Point Manual Defrost / Button Down Button Manual Activation Stand-By Up Button Button HOW TO TURN OFF THE LAE ELECTRONIC CONTROL: May need to unlock control. WHY: Turning off the control will deactivate all electrical components. CAUTION: Turning off the control will not shut off power to the cabinet.
- Page 14 TRUE truemfg LAE Control Info / Set Point Manual Defrost / Button Down Button Manual Activation Stand-By Up Button Button CHANGING THE "SET POINT": May need to unlock control. WHY: The set point is the temperature at which the compressor will shut off. NOTE: The “set point”...
- Page 15 TRUE truemfg LAE Control Info / Set Point Manual Defrost / Button Down Button Manual Activation Stand-By Up Button Button DISPLAYING TEMPERATURE PROBES, T1, T2, T3: WHY: To display temperature probe readings in different locations of the cabinet. HOW TO DISPLAY PROBE TEMPERATURES: STEP 1 - To display T1 temperature, press and release the info button .
- Page 16 TRUE truemfg LAE CONTROLLER PARAMETER SETTINGS FOR CELSIUS AR2-28 For LAE control model AR2-28 ONLY, ALL parameters with a formula (X-32) / 1.8 shown need to be converted for Celsius applications. (X-32) / 1.8 (X-32) / 1.8 (X-32) / 1.8 EXAMPLE: IISM (X) / 1.8...
-
Page 17: Maintenance, Care, Cleaning
TRUE truemfg MAINTENANCE, CARE, CLEANING CLEANING THE CONDENSER COIL When using electrical appliances, basic safety precautions should be followed, including the following: TOOLS REQUIRED • Phillips Screwdriver • Air Tank or CO2 Tank • Stiff Bristle Brush • Vacuum Cleaner •... -
Page 18: Important Warranty Information
TRUE truemfg IMPORTANT WARRANTY INFORMATION THE CLEANING OF THE CONDENSER IS NOT COVERED BY THE WARRANTY! Condensers accumulate dirt and require cleaning every 30 days. Dirty condensers result in compressor failure, product loss, and lost HOW TO CLEAN THE CONDENSER: sales, which are not covered by warranty. -
Page 19: Stainless Steel Equipment Care And Cleaning
TRUE truemfg STAINLESS STEEL EQUIPMENT CARE 8 STEPS THAT CAN HELP PREVENT RUST ON AND CLEANING STAINLESS STEEL: CAUTION: Do not use any steel wool, abrasive or chlorine based USING THE CORRECT CLEANING TOOLS products to clean stainless steel surfaces. Use non-abrasive tools when cleaning your stainless steel products. -
Page 20: Warranty
TRUE truemfg WARRANTY INFORMATION ( U.S.A. & CANADA ONLY! ) THIS WARRANTY ONLY APPLIES TO UNITS SHIPPED FROM TRUE'S MANUFACTURING FACILITIES AFTER SEPTEMBER 1, 2015. THREE-YEAR PARTS & LABOR WARRANTY TRUE warrants to the original purchaser of every new TRUE refrigerated unit, the cabinet and all parts thereof, to be free from defects in material or workmanship, under normal and proper use and maintenance service as specified by TRUE and upon proper installation and start-up in accordance with the instruction packet supplied with each TRUE unit.
