Operating instructions
Cabinet and locker lock – BS80MLM41 / 4 2
blueSmart reader unit:
Cabinet and locker lock – BS80ML
The BS80MLM41 / 4 2 cabinet and locker lock is an electronic furniture lock.
Type M41 features a rigid locking bolt, which allows opening and closing
exclusively by means of an authorised identification medium. The type M42
is equipped with a spring-loaded bolt and can only be opened with an au-
thorised identification medium, but can be closed again by simply closing
the furniture door against the spring pressure. Improper use can destroy
the system and render any claims null and void. These operating instruc-
tions provide you the information you need to install and operate the
BS80MLM41 / 4 2 without trouble.
Technical data:
Frequency:
Range:
Length of line:
Power supply for
control electronics:
Visual signalling:
Acoustic signalling:
Temperature range:
125 kHz
It is essential to observe national legislation on
approved radio frequencies.
Approx. 10 mm between reader unit and
identification medium.
Up to 1 meter
Battery type: 1 x CR123A lithium 3V
2-colour LED (red/green)
Buzzer
Operation: +5 °C to +50 °C at
30% to 80% relative air humidity,
non-condensing.
Storage: -25 °C to +70 °C at
30% at 80% relative air humidity,
non-condensing.
