Ground / Leakage mA Current Specifications
Range
0.200 to 0.999mA
1.00 to 9.99mA
10.0 to 99.99mA
100.0 to 750.0mA
(Autorange, 50/60Hz, True RMS, Crest Factor <3.0)
Ground/Leakage A Current Specifications
Range
0.20 to 15A
Max Current 100A Continuous; 200A for less than 60 seconds
(50/60Hz, True RMS, Crest Factor <2.0)
Accuracy (% of reading)
± (2.5% ± 0.05mA)
± (2.5% ± 0.05mA)
± (2.0% ± 0.3mA)
± (2.5% ± 3mA)
Accuracy (% of reading)
±(2.0% ±0.05A)
5
382356 V2.0 5/03
