Broadwell Platform Controller Hub-
Low Power (PCH-LP)
SPI Programming Guide
June 2014
Revision 1.0
Intel Confidential
Document Number:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCH-LP and is the answer not in the manual?

Questions and answers

Related Manuals for Intel PCH-LP

Summary of Contents for Intel PCH-LP

  • Page 1 Broadwell Platform Controller Hub- Low Power (PCH-LP) SPI Programming Guide June 2014 Revision 1.0 Intel Confidential Document Number:...
  • Page 2 Service Provider. Consult your system manufacturer and Service Provider for availability and functionality. Service may not be available in all countries. Intel assumes no liability for lost or stolen data and/or systems or any other damages resulting thereof. For more information, visit http://www.intel.com/go/anti-theft.

  • Page 3: Table Of Contents

    Flash Region Sizes.................. 12 Hardware vs. Software Sequencing..............13 ............15 PCH SPI Flash Compatibility Requirement ® Intel microarchitecture code name Broadwell PCH-LP SPI Flash Requirements ..15 3.1.1 SPI-based BIOS Requirements ..............15 3.1.2 Integrated LAN Firmware SPI Flash Requirements........16 3.1.2.1 SPI Flash Unlocking Requirements for Integrated LAN ....
  • Page 4 Intel ME VSCC Table for Broadwell PCH-LP Platforms38 ® 4.4.3 Intel ME VSCC Table Settings for Broadwell PCH-LP Family Systems ....40 ........41 Serial Flash Discoverable Parameter (SFDP) Overview Introduction ......................41 Discoverable Parameter Opcode and Flash Cycle ............41 Parameter Table Supported on PCH..............42 Detail JEDEC Specification...................42...
  • Page 5 ........65 Intel ME Disable for Debug/Flash Burning Purposes ® 10.1 Intel ME Disable....................65 ® 10.1.1 Erasing/Programming Intel ME Region ............ 65 Recommendations for SPI Flash Programming in Manufacturing Environments .................. 69 FAQ and Troubleshooting 12.1 FAQ......................... 69 12.2 Troubleshooting ....................
  • Page 6 Recommended Read/Write Settings for Platforms Using Intel® ME Firmware (Cont’d) ..37 Jidn - JEDEC ID Portion of Intel® ME VSCC Table ............38 Vsccn – Vendor-Specific Component Capabilities Portion of the Broadwell PCH-LP Platforms Recommended Opcodes for FPT Operation ..............45 Recommended Opcodes for FPT Operation ..............45 VSCC0 - Vendor-Specific Component Capabilities Register for SPI Component 0 ..46...
  • Page 7 Initial release of document. April 2013 Added section 4.1.2.3 for flash invalid instructions 4-7. August 2013 523462 Updated section 6.4 table 6-1 and table 6-2. Sept 2013 Added Strap 14 bit 30 configuration information. June 2014 § § Intel Confidential...
  • Page 8 Intel Confidential...

  • Page 9: Introduction

    This tool programs the SPI flash device on the Broadwell PCH-LP platforms. This section will talk about requirements needed for FPT to work. Chapter 9, “SPI Flash Programming Procedures” Guide on how to program the SPI flash on the Intel CRB and PCH based platforms. ® Chapter 10, “Intel ME Disable for Debug/Flash Burning Purposes”...

  • Page 10: Terminology

    Intel firmware that adds Intel Active Management Technology, Braidwood ® Firmware (Intel ME FW) Technology, Intel Anti-Theft Technology, Corwin Springs, Castle Peak, Sentry Peak, etc. Intel PCH Intel Platform Controller Hub Intel PCHn family All PCHn derivatives including PCHn (desktop) and PCHnM (mobile) Low Pin Count Bus- bus on where legacy devices such a FWH reside PCH–LP...

  • Page 11: Pch Spi Flash Architecture

    TPM on SPI Bus Broadwell PCH-LP Family supports Intel TPM on the SPI bus. Intel TPM attached to the system may be using LPC or SPI. SPI Intel TPM is accessed much like direct reads and direct writes. Boot Destination Option 2.5.1...

  • Page 12: Flash Regions

    PDR – Platform Data Region The descriptor (Region 0) must be located in the first sector of component 0 (offset 0x10). Descriptor and Intel ME regions are required for all Broadwell PCH-LP Family based platforms. If Regions 0, 2, 3 or 4 are defined they must be on SPI. BIOS can be on either FWH or SPI.

  • Page 13: Hardware Vs. Software Sequencing

    Hardware sequencing has a predefined list of opcodes with only the erase opcode being ® programmable. This mode is only available if the descriptor is present and valid. Intel ME Firmware and Integrated LAN FW, and integrated LAN drivers all must use HW sequencing, so BIOS must properly set up the PCH to account for this.
  • Page 14 PCH SPI Flash Architecture 523462 Intel Confidential...

  • Page 15: Pch Spi Flash Compatibility Requirement

    ® microarchitecture code name Broadwell Intel PCH-LP SPI Flash Requirements • Broadwell PCH-LP Family allows for up to two SPI flash devices to store BIOS, ® Intel ME FW and security keys for Platform Data Region and integrated LAN information.

  • Page 16: Integrated Lan Firmware Spi Flash Requirements

    3.1.3 Intel Management Engine Firmware (Intel ME FW) SPI Flash Requirements Intel Management Firmware must meet the SPI flash based BIOS Requirements plus: 3.1.4 SFDP 3.1.5 JEDEC ID (Opcode 9Fh) 3.1.6 Multiple Page Write Usage Model 3.1.7 Hardware Sequencing Requirements Flash part must be uniform 4 KB erasable block throughout the entire part.

  • Page 17: Sfdp

    The Intel firmware usage models require the capability for multiple data updates within any given page. These data updates occur via byte-writes without executing a preceding erase to the given page. Both the BIOS and Intel Management Engine firmware multiple page write usage models apply to sequential and non- sequential data writes.

  • Page 18: Hardware Sequencing Requirements

    Discoverable opcodes are obtained from each Read Discoverable component’s SFDP table Dual I/O Fast Read Discoverable Opcode is optained from each component’s SFDP table Quad I/O Fast Read Discoverable Opcode is optained from each component’s SFDP table 523462 Intel Confidential...

  • Page 19: Broadwell Pch-Lp Spi Ac Electrical Compatibility Guidelines

    SPI_CLK High time 26.37 t189a SPI_CLK Low time 26.82 Notes: 1.Typical clock frequency driven by Broadwell PCH-LP Family is 17.86 MHz. 2.Measurement point for low time and high time is taken at .5(VccME3_3). Table 3-2. SPI Timings (33 MHz) Parameter Units...
  • Page 20 2, 3 Notes: 1.Typical clock frequency driven by Broadwell PCH-LP Family is 50 MHz. 2.When using 50 MHz mode ensure target flash component can meet t188c and t189c specifications. Recommended to use SPI flash component rated at 66 MHz or faster.

  • Page 21: Spi Flash Dc Electrical Compatibility Guidelines

    Output Fall Slew Rate (0.6 Vcc - 0.2 Vcc) V/ns Note: 1.Testing condition: 1K pull up to Vcc, 1kohm pull down and 10 pF pull down and 1/2 inch trace. See Figure 3.3 for more detail. Figure 3-2. PCH Test Load § § 523462 Intel Confidential...
  • Page 22 PCH SPI Flash Compatibility Requirement 523462 Intel Confidential...

  • Page 23: Descriptor Overview

    The Flash Descriptor is a data structure that is programmed on the SPI flash part on Broadwell PCH-LP based platforms. The Descriptor data structure describes the layout of the flash as well as defining configuration parameters for the PCH. The descriptor is on the SPI flash itself and is not in memory mapped space like PCH programming registers.

  • Page 24: Flash Descriptor Content

    • PCH chipset soft strap sections contain PCH configurable parameters. • The Reserved region is for future chipset usage. ® • The Descriptor Upper Map determines the length and base address of the Intel VSCC Table. ® • The Intel ME VSCC Table holds the JEDEC ID and the ME VSCC information for all the SPI Flash part(s) supported by the NVM image.

  • Page 25: Flmap0 - Flash Map 0 Register (Flash Descriptor Records)25

    Set this field to 10b Flash Master Base Address (FMBA). This identifies address bits [11:4] for the Master portion of the Flash Descriptor. Bits [24:12] and bits [3:0] are 0. Set this field to 06h. This will define FMBA as 60h 523462 Intel Confidential...

  • Page 26: Flmap2-Flash Map 2 Register

    Notes: 1.If more than one Flash component exists, this field must be set to the lowest common frequency of the different Flash components. 2.If setting to 50 MHz, ensure flash meets timing requirements defined in Table 3-3 523462 Intel Confidential...
  • Page 27 2.It is strongly recommended to set this bit to 1b Read Clock Frequency. 000 = 20 MHz All other Settings = Reserved 19:17 Note: 1.If more than one Flash component exists, this field must be set to the lowest common frequency of the different Flash components. 523462 Intel Confidential...

  • Page 28: Flill-Flash Invalid Instructions Register (Flash Descriptor Records)28

    Invalid Instruction 7. See definition of Invalid Instruction 0 23:16 Invalid Instruction 6. See definition of Invalid Instruction 0 15:8 Invalid Instruction 5. See definition of Invalid Instruction 0 Invalid Instruction 4. See definition of Invalid Instruction 0 523462 Intel Confidential...

  • Page 29: Flash Descriptor Region Section

    3.Region limit address Bits[11:0] are assumed to be FFFh Reserved Region Base. This specifies address bits 26:12 for the Region Base. 14:0 Note: If the BIOS region is not used, the Region Base must be programmed to 7FFFh 523462 Intel Confidential...

  • Page 30: Flreg2-Flash Region 2 (Intel® Me) Register

    Region Limit. This specifies bits 26:12 of the ending address for this Region. Notes: 30:16 ® 1.Ensure size is a correct reflection of actual Intel ME firmware size that will be used in the platform 2.Region limit address Bits[11:0] are assumed to be FFFh...

  • Page 31: Flash Descriptor Master Section

    Requester ID: This is the Requester ID (Bus/Device/Function Number_ of the Host CPU 15:0 For the host CPU, this should be set to Bus/Device/Function: 0/0/0 4.1.4.2 FLMSTR2—Flash Master 2 (Intel ® (Flash Descriptor Records) Memory Address: FMBA + 004h Size:32 bits...

  • Page 32: Pch Softstraps

    ® 4.1.7 Intel ME Vendor Specific Component Capabilities Table Entries in this table allow support for a SPI flash part for Intel Management Engine ® capabilities including Intel Active Management Technology. Since Flash Partition Boundary Address (FPBA) has been removed, UVSCC and LVSCC has been replaced with VSCC0 and VSCC1 in Broadwell PCH-LP.

  • Page 33: Jidn-Jedec-Id Register N (Flash Descriptor Records)33

    4.If bit 3 (WSR) is set to 1b and bit 4 (WEWS) is set to 0b then sequence of 50h 01h 00h is sent to unlock the SPI flash on EVERY write and erase that Intel Management Engine firmware performs.
  • Page 34 Descriptor Overview ® Note: “n” is an integer denoting the index of the Intel ME VSCC table. Bits Description 31:24 Reserved SPI Component Device ID 1. This field identifies the second byte of the Device ID of the SPI 23:16 Flash Component.

  • Page 35: Vsccn-Vendor Specific Component Capabilities N (Flash Descriptor Records)35

    5.If bit 3 (WSR) is set to 0b and bit 4 (WEWS) is set to 0b or 1b then sequence of 60h is sent to unlock the SPI flash on EVERY write and erase that Processor or Intel GbE FW performs.

  • Page 36: Oem Section

    Regions of the flash can be defined from read or write access by setting a protection parameter in the Master section of the Descriptor. There are only three masters that ® have the ability to access other regions: CPU/BIOS, Intel ME Firmware, and GbE software/driver running on CPU.

  • Page 37: Intel Recommended Permissions For Region Access

    1.‡ = Value dependent on if PDR is implemented and if Host access is desired. 4.3.2 Overriding Region Access Once access Intel recommended Flash settings have been put into the flash descriptor, it may be necessary to update the ME region with a Host program or write a new Flash descriptor.

  • Page 38: Me Vscc) Table

    This is the first byte returned by the Read JEDEC-ID command (opcode 9Fh). ® If using Flash Image Tool (FIT) refer to System Tools user guide in the Intel ME FW kit and the respective FW Bring up Guide on how to build the image. If not, refer to 4.1.6.1...

  • Page 39: Vsccn - Vendor-Specific Component Capabilities Portion Of The Broadwell Pch-Lp Platforms

    4.If bit 3 (WSR) is set to 1b and bit 4 (WEWS) is set to 0b then sequence of 50h 01h 00h is sent to unlock the SPI flash on EVERY write and erase that Intel Management Engine firmware performs.
  • Page 40 Descriptor Overview Erase Opcode (EO) and Block/Sector Erase Size (BSES) should be set based on ® the flash part and the firmware on the platform. For Intel ME enabled platforms this should be 4 KB. Write Status Required (WSR) or Write Enable on Write Status (WEWS) should be set on flash devices that require an opcode to enable a write to the status register.

  • Page 41: Serial Flash Discoverable Parameter (Sfdp) Overview

    Figure 5-1. SFDP Read Instruction Sequence Dis cov ery 24 Bit W ait Sta te s O pco de Addre ss Da ta By te D ata Byte Addr + 1h Hi gh Z 523462 Intel Confidential...

  • Page 42: Parameter Table Supported On Pch

    • Dual Output Fast Read Opcode • Dual I/O Fast Read Opcode • Quad Output Fast Read Opcode • Quad I/O Fast Read Opcode Detail JEDEC Specification Please refer to www.jedec.com JESD216 for detail SFDP specification on SPI. § § 523462 Intel Confidential...

  • Page 43: Configuring Bios/Gbe For Spi Flash Access

    BIOS region only. It should not affect the ME or GbE regions. All the SPI flash devices that meet the SPI flash requirements in the Broadwell PCH-LP Family External Design Specification (EDS) will be unlocked by writing a 00h to the SPI flash’s status register.

  • Page 44: Locking Spi Flash Via Status Register

    “90h” opcode. Intel utilities such as the Flash Programming Tool will incorrectly detect the flash part in the system and it may lead to undesired program operation.

  • Page 45: Recommendations For Flash Configuration Lockdown And Vendor Component Lock Bits45

    Flash Partition Boundary Address (FBPBA) has been removed and UVSCC and LVSCC has been replaced with VSCC0 and VSCC1 in Broadwell PCH-LP. VSCC0 is for SPI component 0 and VSCC1 is for SPI component 1. SPI controller will determine which...

  • Page 46: Vscc0 - Vendor-Specific Component Capabilities Register For Spi Component 0

    Refer to VSCC— Lower Vendor Specific Component Capabilities Register and in the Broadwell PCH-LP Family External Design Specification (EDS). See text below the tables for explanation on how to determine VSCC register values. Table 6-3. VSCC0 - Vendor-Specific Component Capabilities Register for SPI Component...
  • Page 47 Hardware takes no action based on the value of this register. The contents of this register are to be used only by software and can be read in the HSFSTS.BERASE register in both the BIOS and the GbE program registers if FLA is less than FPBA. 523462 Intel Confidential...
  • Page 48 ‘1’ = 06h will be the opcode used to unlock the status register if WSR (bit 3) is set to 1b. This register is locked by the Vendor Component Lock (VCL) bit. Table 6-5 Please refer to for a description of how these bits is used. 523462 Intel Confidential...

  • Page 49: Description Of How Wsr And Wews Is Used

    If write enable (06h) will unlock the status register. Opcodes sequence sent to SPI flash will bit 06h 01h 00h. Sequence of 60h is sent to unlock the SPI flash on EVERY write and erase that 0 or 1b Processor or Intel GbE FW performs. 523462 Intel Confidential...

  • Page 50: Host Vscc Register Settings

    When VCL and FLOCKDN are set, it is possible that you may not be able to use in system programming methodologies including Intel Flash Programming Tool if programmed improperly. It will require a system reset to unlock this register and BIOS not to set this bits.

  • Page 51: Flash Image Tool

    The purpose of the Flash Image Tool is to simplify the creation and configuration of the Flash image for the Broadwell PCH-LP family platforms. The Flash Image Tool makes a flash image by creating a descriptor and combining the following image files: •...

  • Page 52: Flash Space Allocation

    Intel ME Clock control, Intel AMT, etc. • GbE: Optional region that contains code and configuration data for Intel integrated Gigabit Ethernet and 10/100 Ethernet. • Platform Data Region: Optional region that contains data reserved for BIOS/Host usage.

  • Page 53: Editable Flash Image Region List

    Some SPI flash devices support both standard and fast read opcodes. Fast reads are able to operate at faster frequencies than the regular reads. For PCH to support these faster read commands, fast read support must be set to true. For Broadwell PCH-LP, ®...

  • Page 54: Descriptor Region - Fast Read Support Options

    The Upper and Lower Flash Erase sizes and Flash Partition Boundary address is not editable from this view. In order to modify these entries you must enter the Build Settings dialog box. Note that asymmetric flash parts are no longer supported. 523462 Intel Confidential...

  • Page 55: Region Access Control

    The setting shown above is the minimum set of the read/write parameters for GbE LAN master access recommended for production phase. It will lock down descriptor region ® with a necessary level of security for Intel ME enabled systems. There are recommended settings (intended for debug/manufacturing or production phase) provided by FITC for different Master Access.

  • Page 56: Pch Soft Straps

    A and the respective FW Bringup Guide. Management Engine VSCC Table This section is used to store information to setup flash access for Intel ME. This does not have any effect on the usage of the Flash programming Tool (FPT) if the information in this section is incorrect, the Intel ME Firmware may not communicate ®...

  • Page 57: Removing An Existing Table Entry

    Vendor ID, Device ID 0 and Device ID 1 (three components of JEDEC ® ® ID) See 4 .4 Intel ME Vendor-Specific Component Capabilities (Intel ME VSCC) Table for more detailed information on how to set the VSCC register value. Figure 7-10. VSCC Table Entry 7.4.2...
  • Page 58 Flash Image Tool 523462 Intel Confidential...

  • Page 59: Flash Programming Tool

    This tool can program an individual region, or the entire flash device. • Descriptor • BIOS • Gigabit Ethernet ® • Intel • Platform Data Region BIOS Support FPT requires proper opcodes programmed if the FLOCKDN bit is set. Please refer to Software Sequencing Opcode Recommendations 6.3 SPI Protected Range Register...

  • Page 60: Configuring A Fparts.txt Entry

    This defines the size of flash space for the flash programming tool. This value is the size of the flash in bits in hexadecimal (0x) notation. For example 8 Mb part = (8*1024*1024) = (8,388,608) convert to hex  0x800000. 523462 Intel Confidential...

  • Page 61: Block Erase Size (In Bytes - 256B, 4K, 64K)

    This field dictates how many bytes will be written for each write command. Broadwell PCH-LP only supports 1 or 64 B writes. Flash devices that allow writes more than a single byte at a time usually support up to 256 bytes at a time. Look to see how many bytes the 02h opcode can support.
  • Page 62 Flash Programming Tool 523462 Intel Confidential...

  • Page 63: Spi Flash Programming Procedures

    SPI Flash Programming Procedures SPI Flash Programming Procedures This chapter assumes the use of Intel flash tools: Flash Programming Tool and Flash Image Tool (FPT and FITC). Updating BIOS If the target system does not have a have a working BIOS and no alternate method of booting (for example: FWH) then you must use a 3 party out of system programmer.
  • Page 64 SPI Flash Programming Procedures 523462 Intel Confidential...

  • Page 65: Intel Me Disable For Debug/Flash Burning Purposes

    3. Use -disableME command line option through FPT tool. ® HECI ME region unlock - There is a HECI command that allows Intel ME FW to boot up in a temporarily disabled state and allows for a host program to overwrite the ME region.
  • Page 66 ® Intel ME Disable for Debug/Flash Burning Purposes 523462 Intel Confidential...

  • Page 67: Recommendations For Spi Flash Programming In Manufacturing

    Please note that not all of these options will be optimal for your manufacturing process. Any method of programming SPI flash where the system is not powered will ® not result in any interference from Intel ME FW. The following methods are ® for Intel ME FW: •...
  • Page 68 Recommendations for SPI Flash Programming in Manufacturing Environments 523462 Intel Confidential...

  • Page 69: Faq And Troubleshooting

    Q: How do I find the Flash Programming Tool (FPT) and Flash Image Tool (FITC) for my platform? A: The aforementioned flash tools are included in the system tools director in Intel® ME FW kit. Please ensure that you download the appropriate kit for the target platform.
  • Page 70 PCH-LP Family External Design Specification (EDS), support may be added for the device. BIOS will have to set up the Host VSCC registers. The Intel Management Engine ® VSCC table in the descriptor will also have to be set up in order to get Intel ® ®...

  • Page 71: Troubleshooting

    Hardware Sequencing Flash Status Register in the Broadwell PCH-LP Family External Design Specification (EDS) for the location for the HSFS. Try reflashing the SPI device with a Party programmer. If you still see this error message, please contact your BIOS vendor to ensure that they are not setting this bit.
  • Page 72 7 .2 Modifying the Flash 4 5 6 H Descriptor Region for more information. This error can also result if BIOS has not correctly set up software sequencing. See Software Sequencing Opcode Recommendations for Opcodes required for FPT operation. § § 523462 Intel Confidential...

  • Page 73: Aappendix A - Descriptor Configuration

    The following section describes functionality and how to set soft strapping for a target platform. Improper setting of soft straps can lead to undesired operation and may lead to returns/recalls. Only default values that will be provided are for softstraps that are reserved. 523462 Intel Confidential...

  • Page 74: Pchstrp0-Strap 0 Record (Flash Descriptor Records)

    Notes: client and switch network interface devices. If not using Intel integrated wired LAN or if disabling it, then set to '1' If using Intel integrated wired LAN solution AND the If not using Intel’s integrated wired solution, then this...
  • Page 75 BIOS developer and the platform hardware designer. SMLink0 Enable (SML0_EN): Configures if SMLink0 This bit MUST be set to ’1’ when Intel NFC enabled on segment is enabled the platform. 0 = Disabled...

  • Page 76: Pchstrp1-Strap 1 Record (Flash Descriptor Records)

    Quad I/O Read Enable (QIORE): This soft strap only has effect if Quad Output Read is discovered as supported via the SFDP ‘0’: Quad I/O Read is disabled ‘1’: Quad I/O Read is enabled (Default) Chipset configuration, set to ‘1111b’ 523462 Intel Confidential...

  • Page 77: Pchstrp2-Strap 2 Record (Flash Descriptor Records)

    31:25 Intel ME SMBus I C* Address (MESMI2CA): This address is only used by Intel ME FW for testing purposes. If MESMI2CEN (PCHSTRP2 bit 24) is set Defines 7 bit Intel ME SMBus I C target address to 1 then the address used in this field must be non-...

  • Page 78: Pchstrp3-Strap 3 Record (Flash Descriptor Records)

    SMBus communication between the Intel integrated MAC and PHY. Reserved, set to ’0’ 15:9 This is the Intel integrated wired MAC’s SMBus address. GbE MAC SMBus Address: This field must be programmed to 70h. This is the 7 bit SMBus address uses to accept SMBus cycles from the PHY.
  • Page 79 APPENDIX A - Descriptor Configuration Bits Description Usage Gbe MAC SMBus Address Enable This bit must be set to ’1’ if Intel integrated wired LAN (GBEMAC_SMBUS_ADDR_EN): solution is used. 0 = Disable 1 = Enable If not using, or if disabling Intel integrated wired LAN solution, then this field must be set to ’0’.

  • Page 80: Pchstrp5-Strap 5 Record (Flash Descriptor Records)

    4 byte payload to an external MESMAUDID[31:16] - Subsystem Device ID master when a GET UDID Block read command is made to Intel ME SMBus ASD’s address. The values contained in MESMAUDID[15:0] and MESMAUDID[31:16] are provided as bytes 8-9 and 10-11 of...

  • Page 81: Pchstrp9-Strap 9 Record (Flash Descriptor Records)

    1b. 13:12 Reserved, set to ‘0’ Intel PHY Over PCI Express Enable (PHY_PCIE_EN): This bit MUST be set to ’1’ if using Intel integrated wired LAN solution. 0 = Intel integrated wired MAC/PHY communication is not enabled over PCI Express*.
  • Page 82 The platform 101: Port 5 Lane 3 hardware designer or schematic review can 110-111: Reserved determine what PCIe Port the Intel wired PHY is routed. Chipset configuration. set to’1’b Reserved, set to ’0’ PCIe Lane Reversal 2 (PCIELR2) If configuring PCIe port 5 as a x4 PCIe bus, reversing the lanes of this port is done via this strap.

  • Page 83: Pchstrp10-Strap 10 Record (Flash Descriptor Records)

    This bit will only be set to ’1’ in order to work around issues in pre-production hardware and Intel ME FW. Note: This field should only be set to ’1b’ if the Intel ME binary loaded in the platform has a ME ROM Bypass image Reserved, Default set to ’0’...

  • Page 84: Pchstrp11-Strap 11 Record (Flash Descriptor Records)

    The setting This bit MUST be set to ’0’ if PCH thermal reporting is of this field must be determined by the BIOS not used. developer and the platform hardware designer. 523462 Intel Confidential...

  • Page 85: Pchstrp12-Strap 12 Record (Flash Descriptor Records)

    1x4. Note: This setting is dependent on the board design. The platform hardware designer must Note: This field only is in effect if PCIEPCS3 is set to '11'b. determine if this port needs lane reversal. 523462 Intel Confidential...
  • Page 86 0 = OPI PLL is the source (default) 1 = PCIe PLL is the source. PCIe NAND x1 or x2 Select (PNX1X2S): 0 = NAND Cycle Router configured for PCIe NAND x1 1 = NAND Cycle Router configured for PCIe NAND x2 523462 Intel Confidential...

  • Page 87: Pchstrp15-Strap 15 Record (Flash Descriptor Records)

    1 = Enable Intel integrated wired LAN Solution This must be set to ’0’ if not using Intel’s integrated Notes: This must be set to '1' if the platform is using Intel's wired LAN solution or if disabling it. integrated wired LAN solution. Set to ’0’ if not using Intel integrated wired LAN solution or if disabling it.

  • Page 88: Pchstrp16-Strap 16 Record (Flash Descriptor Records)

    0 = Integrated System Clock (default) 1 = External Clock A.20 PCHSTRP18—Strap 18 Record (Flash Descriptor Records) Flash Address: FPSBA + 048h Size: 32 bits Default Flash Address: 148h Recommended Value: Bits Description Usage 31:0 Reserved, set to ’0’ 523462 Intel Confidential...

  • Page 89: Pchstrp19-Strap 19 Record (Flash Descriptor Records)

    Reserved, set to ‘1’ Reserved, set to ’0’ A.22 PCHSTRP20—Strap 20 Record (Flash Descriptor Records) Flash Address: FPSBA + 050h Size: 32 bits Default Flash Address: 150h Recommended Value: Bits Description Usage 31:0 Reserved, set to ’0’ 523462 Intel Confidential...
  • Page 90 APPENDIX A - Descriptor Configuration A.23 CPUSTRP0—Strap 0 Record (Flash Descriptor Records) Flash Address: FCPUSBA + 000h Size: 32 bits Default Flash Address: 200h Recommended Value: Bits Description Usage 31:0 Reserved, set to ’0’ 523462 Intel Confidential...
