Data Sync Engineering WB-MP3 Manual

Player System
Player System
Features Background Music Play & Wireless Remote
Features Background Music Play & Wireless Remote
It's the rockin' 50's and 60's all over again ...
WALLBOX MODELS
• AMI W-40
• AMI W-80
• AMI W-120
• AMI WQ-200
• Rock-Ola 500
• Rock-Ola 1555
• Rock-Ola 1558
• Rowe WRA
• Rowe WRB
• Rowe WRC
• Seeburg 3W1
KIT CONTENTS
• NEW! SD-Card MP3 Player System
• Full Featured Wireless Remote
• 16GB SD Memory Card & USB R/W Adapter
• RCA to RCA Line Out Audio Cable
• Power supply cable assembly (9VDC / 200mA)
Wallbox transformer is NOT included    
The WB-MP3 is a Secure Digital (SD-Card) music player for vintage jukebox wallboxes. Make selections on the
wallbox and instantly your songs are played, one by one, in the order received. Same way as it was back in the
40's, 50's, 60's and 70's. Any number of the same wallbox models can be connected to the player. Setup is
easy, create folders (or playlists) on your memory card, store the wallbox song files in the folder, program your
wallbox type and your ready to go.
The Background Music feature allows non-stop music play when all wallbox song selections have been
played. From the wireless remote, you can choose the starting play from any folder and song number. Up to
100 folders (00 to 99) each having up to 100 songs (00 to 99) provide remote access for up to 10,000 songs.
Background song plays auto-increment through all song files and folders and also remembers the next song
to play at each power-up. A new wallbox selection can be programmed to either cancel the current background
play or wait until the end of the background song before playing the selections.
A stereo RCA cable provide the "line-out" signal for your external amplifier or you can connect to a set of
amplified speakers. The wireless remote is used to control volume level, pause or cancel song play.
The MP3 player supports all MPEG layer-III encodings at fixed and variable bit-rates up to and including 320
kbits/s (the 192 kbits/s rate is generally recommended). A 24-bit DAC provides 96dB of audio dynamic range.
The player works with any FAT32 formatted "standard SD card" or "micro SD card with Adapter".
Data Sync Engineering
P.O. Box 539, 2 Footbridge Lane
Blairstown, New Jersey 07825
for
for
• Seeburg 3W100
• Seeburg 3WA
• Seeburg SC1-4
• Seeburg SCH1-4
• Wurlitzer 3020
• Wurlitzer 5207
• Wurlitzer 5210
• Wurlitzer 5220
• Wurlitzer 5250
• Johnny Rockets
•
Other 3-wire models
Copyright © 2009 / 2015 Data Sync Engineering. All Rights Reserved.
Designated trademarks and brands are the property of their respective owners.
Wallbox Selectors
Wallbox Selectors
TEL: (908) 362-6299
FAX: (908) 362-5889
www.datasynceng.com
