• Works with all laptop/notebook HDD's
• Supports all layer-III (MP3) encodings
• Variable or fixed bit rates to 320 Kbps
• Detects master/slave drive setting
• Automatic power down on no activity
• Can also be used as a portable player
The MP3-DSP is a series of hard disk drive MP3 players designed to simulate CD changers used in
jukeboxes, wallboxes, home automation systems and other personal entertainment products. The
player works with any 44-pin ATA/IDE 2.5 inch hard disk drive from 2 to 60GB having a maximum
height of 9.5mm, uses the FAT32 filesystem and supports both long and short filenames.
The MP3-DSP incorporates an adaptable interface that provides easy integration into existing audio
systems. The various model configurations include a connector cable or adapter cable specific to the
application. In most cases, a different cable is all that is needed for a new application. In addition, the
MP3-DSP employs a 9600-baud serial port interface offering direct control from any processor-based
system.
The player supports all layer-III (MP3) encodings at fixed and variable bit-rates up to and including 320
kbits/s. A 24-bit DAC provides 96dB of audio dynamic range. Stored audio control settings include a
12-step digital bass enhance control (0..+18 dB), a 12-step tone attenuation (0..-18 dB), a 12-step
treble enhance control (0..+18 dB), a 96-step digital primary volume control (0..-96 dB), and a 96-step
secondary volume control (0..-96 dB for the Rowe CD Combo).
The kit versions come with a USB downloader circuit board and the MP3-DSP digital subsystem player
circuit board. The USB downloader adds a drive letter to your computer and is used to transfer MP3
files onto your disk drive. It can also be used as an external USB hard drive. The MP3-DSP is the
actual MP3 player and CD changer simulator allowing emulation of up to 256 discs, each having up to
99 tracks.
Data Sync Engineering
P.O. Box 539, Footbridge Lane, Bldg 3
Blairstown, New Jersey 07825
Designated trademarks and brands are the property of their respective owners.
Copyright © 2002-2003 Data Sync Engineering. All Rights Reserved.
MP3-DSP
MP3 Subsystem Player
For Jukeboxes, Wallboxes and
Home Automation Systems
TEL: (908) 362-6299
FAX: (908) 362-5889
Email: sales@datasynceng.com
Web: www.datasynceng.com
Advertisement
Related Manuals for Data Sync Engineering MP3-DSP
Summary of Contents for Data Sync Engineering MP3-DSP
- Page 1 The USB downloader adds a drive letter to your computer and is used to transfer MP3 files onto your disk drive. It can also be used as an external USB hard drive. The MP3-DSP is the actual MP3 player and CD changer simulator allowing emulation of up to 256 discs, each having up to 99 tracks.
- Page 2 MP3-DSP Kit Contents Your kit comes with a USB downloader circuit board, MP3-DSP digital music player / CD emulator circuit board, PC connector cables, enclosure, power supply and a storage pouch. Depending on your model type, additional cables and/or adapters will also be included.
- Page 3 Assembling The Hard Disk Drive The hard disk drive has two sets of connector pins. 43-pins on the left side and 4-pins on the right. Position the disk drive onto the circuit board then align the left side pins with the connector. Slide the disk drive forward into the connector.
- Page 4 Creating New Folders for Disc Numbers Assemble your disk drive to the USB downloader board. Open Windows Explorer Connect your keyboard power supply plug to the USB downloader then plug the USB cable into your computer. Within a few moments, a new disk drive letter should appear. For this example we see “Removable Disk F:”...
- Page 5 Drag & Drop Your MP3 Song Files Select the disk and directory for your source of MP3 song files then click the + at “Removable Disk (F:)” to expand the folders. If you wish to copy the entire set of songs, click on the first song at the top, scroll down to the last song, hold down the SHIFT key then click the last song.
- Page 6 Quick Test of the MP3-DSP Player Connect your disk drive to the MP3-DSP digital music player board. Apply the adhesive foam pad to the top half of the enclosure, above the DIN connector. Assemble enclosure. Plug in the 9-pin mini DIN connector (arrow or notch facing up).
- Page 7 Installation for MP3-DSP Model V02 Installation for MP3-DSP Model V03 The MP3-DSP V02 kit was designed to upgrade your ROWE/AMI Combo Jukebox to play MP3 music files from a hard disk drive. Any combo jukebox that uses the 4-07773-xx Central Control Computer can be upgraded.
- Page 8 NOTEPAD then save the file as "WP32.TXT". It doesn't matter what you type in for text, only the filename is looked at. When the MP3-DSP is powered up, it searches for MP3 and TXT files. Each only the filename is looked at. When the MP3-DSP is powered up, it searches for MP3 and TXT files. Each TXT filename is examined.
