• Works with all laptop/notebook HDD's
• Supports all layer-III (MP3) encodings
• Variable or fixed bit rates to 320 Kbps
• Detects master/slave drive setting
• Automatic power down on no activity
• Can also be used as a portable player
The RCU-MP3 kit was designed to upgrade your ROWE/AMI Combo Jukebox to play MP3 music files from a
hard disk drive or Compact Flash memory card . Any combo jukebox that uses the 4-07773-xx Central Control
Computer can be upgraded. This includes models R -90, R-91, R-92, R-93 and R-94. The player automatically
adapts to your jukebox offering support of 6 discs with each having up to 32 tracks or more. Most non-combo
jukeboxes can also be upgraded by replacing the CCC EPROM program with a combo support version.
The player works with any 44-pin ATA/IDE 2.5 inch hard disk drive from 2GB and up having a maximum height
of 9.5mm, uses the FAT32 filesystem and supports both long and short filenames. The player supports all
layer-III (MP3) encodings at fixed and variable bit-rates up to and including 320 kbits/s. A 24-bit DAC provides
96dB of audio dynamic range.
The kit comes with a USB external HDD circuit board and the MP3-DSP digital subsystem player circuit board.
The USB external HDD adds a drive letter to your computer and is used to transfer MP3 files onto your disk
drive.
CD Initialization
To perform the CD initialization, place the jukebox service switch into the SERVICE position then enter 777 on
the keypad. When initialization starts, four dashes will appear on the CCC display. When the initialization is
complete, the CCC display will go blank.
Playing MP3 Songs
On a combo jukebox, CD's are selected by entering a four digit number. The first digit is always "5" for CD
selections. The second digit is the disc # less one. To select disc "1", you would enter "0". The last two digits
are the track # of the song you wish to play. For example, if you wanted to play disc 3, track 9, you would enter
"5209" on the keypad.
Data Sync Engineering
P.O. Box 539, Footbridge Lane, Bldg 3
Blairstown, New Jersey 07825
Designated trademarks and brands are the property of their respective owners.
Upgrade Your ROWE/AMI
Copyright © 2003 Data Sync Engineering. All Rights Reserved.
RCU-MP3
CD Combo Player to a
Hard Disk MP3 Player
TEL: (908) 362-6299
FAX: (908) 362-5889
www.datasynceng.com
Advertisement
Table of Contents
Related Manuals for Data Sync Engineering RCU-MP3
Summary of Contents for Data Sync Engineering RCU-MP3
- Page 1 • Can also be used as a portable player The RCU-MP3 kit was designed to upgrade your ROWE/AMI Combo Jukebox to play MP3 music files from a hard disk drive or Compact Flash memory card . Any combo jukebox that uses the 4-07773-xx Central Control Computer can be upgraded.
- Page 2 MP3-DSP Kit Contents Your kit comes with a USB external HDD circuit board, MP3-DSP digital music player circuit board, PC connector cables, jukebox connector cables, enclosure, power supply and a storage pouch. The hard disk drive is NOT included. This is your USB external HDD circuit board. When assembled with your disk drive and plugged into the USB port, it will add a drive letter to your computer and allow you to transfer files between your PC and...
- Page 3 Assembling The Hard Disk Drive The hard disk drive has two sets of connector pins. 43-pins on the left side and 4-pins on the right. Position the disk drive onto the circuit board then align the left side pins with the connector. Slide the disk drive forward into the connector.
- Page 4 Optional Compact Flash Card Adapter The 44-pin IDE connector adapter allows CF memory card usage. Works with FAT32 formatted cards having a capacity of 512MB and up. Song capacities using 128 Kbps (near CD quality) 512MB 128 songs (about 6 CD’s) 250 songs (about 12 CD’s) 500 songs (about 25 CD’s) 1,000 songs (about 50 CD’s)
- Page 5 Drag & Drop Your MP3 Song Files Select the disk and directory for your source of MP3 song files then click the + at “Removable Disk (F:)” to expand the folders. If you wish to copy the entire set of songs, click on the first song at the top, scroll down to the last song, hold down the SHIFT key then click the last song.
- Page 6 Don't forget to delete this file when you're done testing. DISCLAIMER – PLEASE READ The RCU-MP3 kit was developed for jukebox owners for non public performance use. We do not supply jukebox licenses and do not have any knowledge of what is required. It is the jukebox...
