Textron EZ-GO Express L6 Service & Parts Manual page 91

THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
1 605721
2 605445
3 00665G9
4 00643G1
5 12262G1
6
7
8 00665G9
9 11098G5
10 70289G02
11 624030
12 652245
13 624030
14
15 70492G01
16 652629G103
17 652629G203
18
19 32195G3
20 652580
21 00643G1
22 11098G5
23 608654
24 00974G01
25 642085
26 10435G1
27 10194G1
28 00532G6
29 10044G01
1 2 3 4 5
Leaf Spring.......................................................................................................
Leaf Spring Bushing (Front) .............................................................................
Hex Head Bolt (SS), 3/8" - 16 x 3.5" Lg ...........................................................
Flat Washer, 3/8"..............................................................................................
Flanged Lock Nut, 3/8" - 16 .............................................................................
Hex Head Bolt (SS), 3/8" - 16 x 3.5" Lg ...........................................................
Lock Nut, 3/8" - 16 ...........................................................................................
Split Spacer (Steel), I.D .376" x O.D 1" x 1" Lg................................................
Flanged Bushing ..............................................................................................
Shackle Plate ...................................................................................................
Flanged Bushing ..............................................................................................
Rubber Bumper................................................................................................
Spring Plate (Driver Side) ................................................................................
Spring Plate (Passenger Side).........................................................................
U-Bolt, 3/8" - 16 x 5" Lg....................................................................................
Rear Suspension Plate ....................................................................................
Flat Washer, 3/8"..............................................................................................
Lock Nut, 3/8" - 16 ...........................................................................................
Split Lock Washer, M10 ...................................................................................
Hex Nut, M10 ...................................................................................................
Shock Absorber................................................................................................
Shock Absorber Washer, 1.25" O.D x .406" I.D ...............................................
Rubber Bushing ...............................................................................................
Hex Nut, 3/8" - 24.............................................................................................
Vinyl Cap..........................................................................................................
10015775 Service Parts Manual
REAR SUSPENSION
DESCRIPTION QTY.
2
2
1
1
1
2
2
2
2
2
2
1
1
1
2
1
4
4
1
1
2
4
4
2
1
Page N-2
