OPERATOR'S MANUAL
MAGNETIC BOX AND PAN BRAKE
MODEL: BB-7216M
Baileigh Industrial, Inc.
P.O. Box 531
Manitowoc, WI 54221-0531
Phone: 920.684.4990
Fax: 920.684.3944
sales@baileigh.com
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC.
IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss
caused by an omission or error in this Operator's Manual, resulting from accident, negligence, or other occurrence.
Rev. 09/2016
© 2016 Baileigh Industrial, Inc.

Advertisement

Table of Contents
loading

Summary of Contents for Baileigh Industrial BB-7216M

  • Page 1 REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC. IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other occurrence.
  • Page 2: Table Of Contents

    Table of Contents THANK YOU & WARRANTY ..................1 INTRODUCTION ......................3 GENERAL NOTES ......................3 SAFETY INSTRUCTIONS ....................4 SAFETY PRECAUTIONS ....................6 Dear Valued Customer: ....................6 TECHNICAL SPECIFICATIONS ..................8 TECHNICAL SUPPORT ....................8 UNPACKING AND CHECKING CONTENTS ..............9 Cleaning ........................
  • Page 3: Thank You & Warranty

    THANK YOU & WARRANTY Thank you for your purchase of a machine from Baileigh Industrial. We hope that you find it productive and useful to you for a long time to come. Inspection & Acceptance. Buyer shall inspect all Goods within ten (10) days after receipt thereof. Buyer’s payment shall constitute final acceptance of the Goods and shall act as a waiver of the Buyer’s rights to inspect or...
  • Page 4 • A 30% re-stocking fee applies to all returns. Baileigh Industrial makes every effort to ensure that our posted specifications, images, pricing and product availability are as correct and timely as possible. We apologize for any discrepancies that may occur. Baileigh Industrial reserves the right to make any and all changes deemed necessary in the course of business including but not limited to pricing, product specifications, quantities, and product availability.
  • Page 5: Introduction

    After receiving your equipment remove the protective container. Do a complete visual inspection, and if damage is noted, photograph it for insurance claims and contact your carrier at once, requesting inspection. Also contact Baileigh Industrial and inform them of the unexpected occurrence. Temporarily suspend installation.
  • Page 6: Safety Instructions

    IMPORTANT PLEASE READ THIS OPERATORS MANUAL CAREFULLY It contains important safety information, instructions, and necessary operating procedures. The continual observance of these procedures will help increase your production and extend the life of the equipment. SAFETY INSTRUCTIONS LEARN TO RECOGNIZE SAFETY INFORMATION This is the safety alert symbol.
  • Page 7 SAVE THESE INSTRUCTIONS. Refer to them often and use them to instruct others. PROTECT EYES Wear safety glasses or suitable eye protection when working on or around machinery. BEWARE OF CRUSH HAZARD Placing fingers or hands between the clamping leaf and the magnetic bed could cause serious personal injury.
  • Page 8: Safety Precautions

    SAFETY PRECAUTIONS Metal working can be dangerous if safe and proper operating procedures are not followed. As with all machinery, there are certain hazards involved with the operation of the product. Using the machine with respect and caution will considerably lessen the possibility of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator may result.
  • Page 9 7. Dressing material edges. Always chamfer and deburr all sharp edges. 8. Do not force tool. Your machine will do a better and safer job if used as intended. DO NOT use inappropriate attachments in an attempt to exceed the machines rated capacity. 9.
  • Page 10: Technical Specifications

    TECHNICAL SPECIFICATIONS 72” (1829mm) Bend Length Bend Material Thickness 16ga. (1.51mm) mild steel* Bending Leaf Extension Removed 20ga. (0.91mm) stainless steel** Bend Material Thickness 18ga. (1.21mm) mild steel* Bending Leaf Extension Installed 21ga. (0.83mm) stainless steel** 0 – 180 degrees Bend Angle Box Depth Unlimited...
  • Page 11: Unpacking And Checking Contents

    UNPACKING AND CHECKING CONTENTS Your Baileigh machine is shipped complete. Separate all parts from the packing material and check each item carefully. Make certain all items are accounted for before discarding any packing material. WARNING: SUFFOCATION HAZARD! Immediately discard any plastic bags and packing materials to eliminate choking and suffocation hazards to children and animals.
  • Page 13 Item Description Qty. Body and Pedestal Tool Tray Back Stop Collars Back Stop Bars Segmented Clamp Bar (Assortment) Wide Clamp Bar – Short Wide Clamp Bar – Long Left Foot Right Foot Bag of Hardware Foot Switch...
  • Page 14: Transporting And Lifting

    TRANSPORTING AND LIFTING IMPORTANT: Lifting and carrying operations should be carried out by skilled workers, such as a truck operator, crane operator, etc. If a crane is used to lift the machine, attach the lifting chain carefully, making sure the machine is well balanced. Follow these guidelines when lifting with truck or trolley: •...
  • Page 15: Installation

    INSTALLATION IMPORTANT: Consider the following when looking for a suitable location to place the machine: • Overall weight of the machine. • Weight of material being processed. • Sizes of material to be processed through the machine. • Space needed for auxiliary stands, work tables, or other machinery. •...
  • Page 16: Overall Dimensions

    OVERALL DIMENSIONS...
  • Page 17: Assembly And Set Up

    ASSEMBLY AND SET UP WARNING: For your own safety, DO NOT connect the machine to the power source until the machine is completely assembled and you read and understand the entire instruction manual. Attaching the Legs 1. Use slings to remove the magnet body from the crate. Rest the body on wooden blocks.
  • Page 18: Removing And Installing The Bending Extension Bar

    Footswitch 1. Unstrap and straighten out the footswitch cable. 2. Grasp the connector end and plug into the receptacle at the back of the machine. 3. Tighten the connector sleeve. figure 5 Removing and Installing the Bending Extension Bar Note: For mild steel, 16ga., extension OFF.
  • Page 19: Electrical

    220VAC ±5% (209VAC to 231VAC). Failure to comply will damage the machine voiding the warranty. If needed, contact Baileigh Industrial at 920-684-4990 to purchase a Buck Boost transformer. The service personal will be able to assist in placing the order for the transformer or provide specifications so that you will be able to obtain the proper transformer for your application.
  • Page 20 WARNING: In all cases, make certain the receptacle in question is properly grounded. If you are not sure, have a qualified electrician check the receptacle • Improper connection of the equipment-grounding conductor can result in risk of electric shock. The conductor with insulation having an outer surface that is green with or without yellow stripes is the equipment-grounding conductor.
  • Page 21: Operation

    OPERATION CAUTION: Always wear proper eye protection with side shields, safety footwear, and leather gloves to protect from burrs and sharp edges. When handling large heavy materials make sure they are properly supported. Keep hands and fingers clear of the clamping beam. Stand off to the side of the machine to avoid getting hit with the bending apron as it comes up to bend.
  • Page 22 5. If using a full length clamping bar, use the lift handles (A) to raise the clamping bar and then position the piece part under the clamp bar. Use the backstop if needed. IMPORTANT: NEVER activate the magnetic circuit with the clamping bar raised. The bar will snap down possible causing injury and or damaging the bar, the magnet table, or the material.
  • Page 23: Bending Edges Of Materials

    Important: Each time the machine switches OFF, a short pulse of reverse current is sent through the electromagnet to demagnetize it as well as the piece part. The timer is set to 2-3 seconds to help collapse the magnetic field. 12.
  • Page 24: Magnetism Notes

    Magnetism Notes Heat will reduce the strength of magnetic field. This is important to know when using the magnetic brake for long periods of time. If is recommended to keep the amount of time that the magnetic coils are energized as short as possible. When the coils of the magnet are energized, the electrical current flowing through the coils creates heat.
  • Page 25: Bending Allowance

    BENDING ALLOWANCE In order to bend sheet metal accurately, you will need to consider the total length of each bend. This is referred to as bend allowance. Subtract the bend allowance from the sum of the outside dimensions of the piece part to obtain the actual overall length or width of the piece. Because of differences in sheet metal hardness, and whether the bend is made with the grain or against it, exact allowances must sometimes be made by trial and error.
  • Page 26: Bend Configurations

    BEND CONFIGURATIONS Return Bends Rolled Edge Closed Channel Stiffening Rib Angle Bend Fins BENDING EXAMPLES Folding Over a Lip The thickness, width, and length of material are factors to consider when folding a lip. DO NOT exceed 20ga. (.035”) for material thickness. 1.
  • Page 27 Rolling an Edge Use a piece of solid steel round or a pipe to accomplish this. 1. Position the clamping bar and the round bar as shown in (fig. 14) to ensure that the piece part is positioned correctly. Energize the electromagnet. figure 14 2.
  • Page 28: Lubrication And Maintenance

    LUBRICATION AND MAINTENANCE WARNING: Make sure the electrical disconnect is OFF before working on the machine. Maintenance should be performed on a regular basis by qualified personnel. Always follow proper safety precautions when working on or around any machinery. • Check daily for any unsafe conditions and fix immediately. •...
  • Page 29: Checking Machine Accuracy

    Checking Machine Accuracy To achieve and maintain accurate bends on the Baileigh BB-7216M magnetic brake, the working surface of the bending beam and the bending edge of the clamp bar need to be straight. Both of these surfaces must also be parallel to each other. This can be checked periodically with a precision straight edge.
  • Page 30: Parts Diagram

    PARTS DIAGRAM...
  • Page 31: Parts List

    Parts List Item Description Qty. Right feet Left feet Screw M8x16 Right stand Right Shield Left Shield Electrical box Material box Left stand Right folding bar Left handle Rubber washer Back gauge Limited block Screw M8x20 Magnetic working table Bending board 16.1 Bending board 16.2...
  • Page 32 Item Description Qty. Connect bar Pin shaft Shaft washer 10 Connect bar Cover Screw M6x16 Nut M6 Fixed nut Shaft washer 18 Key 6x20 Bolt M6x35 Cover 18x20x20 Stand Bolt M8x25 Connect shaft Handle ball Right handle Screw M8x16 Folding board Folding board strip Screw M8x20 Screw M8x20...
  • Page 33 Item Description Qty. Graduated scale Left folding bar Screw M8x20 Connect bar Screw M8x6 Block Screw M8x20 Shaft Cover Screw M8x20 Stand Screw M8x16 Connect board Screw M8x30 Screw M8x20...
  • Page 34: Electrical Components

    ELECTRICAL COMPONENTS Shown with cover panel removed Voltage Tests Reference Point Any BLUE Wire Any BLACK Wire Test Point Light Clamping Condition 220V AC 25V AC +25V DC +25V DC -300V DC Full Clamping Condition 220V AC 220V AC +215V DC +215V DC +215V DC...
  • Page 35: Electrical Schematic

    ELECTRICAL SCHEMATIC Magnet Control Board KS50 CBB61A 1.5W 450V 1.5uf CBB22 104J 10K? 400V DC450V 470uf KPBC2 KPBC1 220V Stop Pedal Start Pedal...
  • Page 36: Electrical Components

    Electrical Components Red Stop Push Button - NC Contact Contactor, CU-16, Primary coil activation circuit. Creates light clamping pressure. Contactor, CU-16, Primary coil activation circuit. Creates full clamping pressure. Control Board, Holds components C1, C2, C3, C4, D1, KS50, R1, and Control Board R2.
  • Page 37: Troubleshooting

    TROUBLESHOOTING WARNING: Make sure the electrical disconnect is OFF before working on the machine. FAULT PROBABLE CAUSE REMEDY Machine is not plugged in to a Have qualified electrician check live circuit circuit. Bending leaf lifted before start Return bending leaf to lower button is pressed position and press start button Bending leaf micro-switch out of...
  • Page 38 Full Clamping Not Operating If you are not achieving a full clamp, the angle micro switch may not be fully actuated. To check that the angle micro switch is being fully actuated. • The micro switch can be found on the electrical panel located at the end of the square brass section.
  • Page 39 NOTES:...
