Product introduction

Motherboard overview

• Unplug the power cord from the wall socket before touching any component.
• Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due
to static electricity.
• Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, or components.
• Unplug the power cord before installing or removing the motherboard. Failure to do so
can cause you physical injury and damage to motherboard components.
Place this
side towards
the rear of the
chassis
20
19
18
Scan the QR code to get the detailed pin definitions.
ASUS PRIME H310M-C R2.0
1 2
19.3cm(7.6in)
KBMS
USB5-8
ATX12V
LAN_U31G1_34
CHA_FAN
2280 2260
AUDIO
PCIEX1_1
Super
I/O
ASM
PCIEX1_2
1083
ALC
887 PCI
COM2
LPT
AAFP
17
16 15 14
3 4 5
CPU_FAN
DIGI
+VRM
LGA1151
M.2(SOCKET3)
PCIE SATA IRST
X2 V X
PCIEX16
ASM1480
Intel
®
H310
LPC DEBUG
USB914
TPM
SATA6G_4 SATA6G_3 SATA6G_2
13 12 11 8
1
1 1
1 6
1 7
CLRTC
128Mb
BIOS
1 8
SPEAKER
1 9
F_PANEL
10
1-1
