4 - MTSCRA Library Data Type and Structures
*/
4.6

ARQC

getTransactionProgress will return the ARQC after device request a acquirer decision for a transaction.
type : 771 (0x303)
data : hex string contains byte array for following structure
Offset Field
Name
0 Message
Length
2 ARQC
Message
{"type":771,"data":"01ABFD8201A7DFDF250F423330364639363039323831354141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"};
4.7

Transaction Result

getTransactionProgress will return the transaction data after device complete a transation
type : 772 (0x304)
data : hex string contains byte array for following structure
Offset Field
Name
0 Signature
Required
1 Batch Data
Length
3 Batch Data
Dynamag, DynaMAX, and eDynamo| Secure Card Reader Authenticator | Programmer's Reference (WCF)
Page 25
Two byte binary, most significant byte first. This gives the total length of the
ARQC message that follows.
See Appendix A. It is expected that the host will use this data to process a
request.
This field indicates whether a card holder signature is required to complete the
transaction:

0x00 – No signature required

0x01 – Signature required
If a signature is required, it is expected that the host will acquire the signature
from the card holder as part of the transaction data.
Two byte binary, most significant byte first. This gives the total length of the
ARQC message that follows.
See Appendix C. It is expected that the host will save this data as a record of
the transaction.
Value
Value
