Specifications

Find Quality Products Online at:
Range 220 lbs, 100kg, 980 Newtons
Accuracy (23 o C) ±(0.5%rdg + 0.1lbs, 0.1kg or 0.4N)
Resolution 0.05lbs, 0.05kg, 0.2 Newtons
Overload Capacity 150kg
Circuit Custom LSI microprocessor
Zero adjust Button for Peak Hold and normal display zero
Display 5-digit
Update Rate Fast mode 0.2 seconds; Slow mode 0.6 seconds
Over range Indicators LCD displays
compression measurements
Zero / Tare Control Up to Maximum capacity
Full Scale Deflection <1mm
Transducer type S-type load cell with 2 hooks (thread size: M10 x 1.5mm ISO) and
6.5 ft (2m) cable
Peak Hold Freezes Max reading on display
Data Output RS-232 serial interface with 16-bit data stream output
Operating Temperature 0°C to 50°C (32 °F to 122 °F)
Operating RH Max. 80% Relative Humidity (RH)
Power Supply 6
Power consumption 12mA (approx.)
Weight Meter: 450g (1 lb); 278g (0.61 lbs) w/out batteries
Sensor: 635g (1.40 lbs)
Dimensions Meter: 215 x 90 x 45 mm (
Sensor with 2 hooks: 162 x 51 x 22 mm (6.4 x 2.0 x 0.9 )
Cable length: 2m (6.5 ft.)
