Summary of Contents for Hans Grohe Raindance Rainfall 28433007
- Page 1 ZH 用户手册 / 组装说明 EN Instructions for use / assembly instructions Raindance Rainfall 28433007...
- Page 2 中文 安全技巧 符号说明 装配时为避免挤压和切割受伤，必须戴上手套。 本产品只允许作为洗浴、卫生和洁身之用。 请勿使用含有乙酸的硅胶！ 头顶花洒夹持杆只为夹持头顶花洒而设计，不得让其承载其它物品！ 不得让儿童和肢体、精神和/或意识有障碍的成人在不受监管的情况下 安装实例 (参见第页 8) 使用淋浴系统。受酒精或毒品影响的人员不得使用淋浴系统。 必须避免让身体敏感部位（如眼睛）接触到莲蓬头喷水。必须保持莲蓬 中心淋浴盆 头与人头之间有足够的距离。 冷热水管间过大的压力差必须予以平衡。 安装提示 热水 • 安装前必须检查产品是否受到运输损害。 安装后将不认可运输损害或表 面损伤。 冷水 • 管道和阀门必须根据通用标准进行安装、冲洗和检查。 • 请遵守当地国家现行的安装规定。 该区域需要一个加固边壁。 • 由有资格的专业人员进行产品安装时请注意：在所有加固区域中，加固 表面是否平整（无突出的接缝或瓷砖），墙体结构是否适合产品安装且 未显露出任何缺点。 截止阀 • 必须装上花洒所附带的滤柱式过滤网，以过滤管道里的杂质污物。杂质 污物会影响花洒的功能和/或损坏花洒的功能部件，由此而产生的产品 损坏不属于汉斯格雅的保修范围。 Quattro 四通转换器 • 如果连续流热水器导致任何问题，或者出现了不同的水压，您必须在冷 Quattro 水端安装水流限制器（单独订购，商品编号 97510000）。 通用的三通截止阀和换向阀 技术参数 0,6 MPa 工作压强： 最大 Trio 0,2 - 0,4 MPa 推荐工作压强：...
-
Page 3: Installation Instructions
English Safety Notes Symbol description Gloves should be worn during installation to prevent crushing and cutting Do not use silicone containing acetic acid! injuries. The product may only be used for bathing, hygienic and body cleaning pur- poses. Installation example (see page 8) The arm of the shower head is intended only to hold the shower head. Do not load it down with other objects! Center shower tub Children as well as adults with physical, mental and/or sensoric impairments must not use this product without proper supervision. Persons under the influ- ence of alcohol or drugs are prohibited from using this product. Warm water Do not allow the streams of the shower touch sensitive body parts (such as your eyes). An adequate distance must be kept between the shower and you. The hot and cold supplies must be of equal pressures. Cold water Installation Instructions • Prior to installation, inspect the product for transport damages. After it has been The wall must be reinforced in this area. installed, no transport or surface damage will be honoured. • The pipes and the fixture must be installed, flushed and tested as per the applica- Shut off valve ble standards. • The plumbing codes applicable in the respective countries must be observed. Quattro 4-Way Diverter Valve • During installation of the product by qualified trained personnel, make sure that the entire fastening surface is even and smooth (no protruding seams or tile Quattro offset), that the finish of the wall is suitable to apply the product and has no weak Trio 2-Way Diverter Valve with integrated Shut-off valve points. • The filter insert must be use to protect the shower against incoming dirt by pipe- Trio work. Incoming dirt leads to defects or/and can damage parts of the shower;... - Page 4 SW 5 mm SW 4 mm SW 2 mm...
- Page 5 SW 4 mm SW 4 mm SW 4 mm (5 Nm)
- Page 6 ( 2 N SW 4 mm (2 Nm)
- Page 8 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 Q = l/min 9 12 15 18 21 24 27 30 Q = l/sec Raindance Rainfall = Rain = Rainflow...
- Page 9 iBox universal DN 20 01800187 (3/4") i n fl 15714007+ 01800187...
- Page 10 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 Q = l/min 9 12 15 18 21 24 27 30 Q = l/sec Raindance Rainfall = Rain = Rainflow Raindance Select S 120 = Rain...
- Page 11 iBox universal DN 20 01800187 (3/4") i n fl 15932007 + 15930187 Quattro 15972007 + 15970187 Highflow 15741007+ 01800187...
- Page 12 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 Q = l/min 9 12 15 18 21 24 27 30 Q = l/sec Raindance Rainfall = Rain = Rainflow Raindance Select S 120 = Rain...
- Page 13 iBox universal DN 20 01800187 (3/4") i n fl 15932007 + 15981187 Trio Highflow 15741007+ 01800187 15972007 + 15973187...
- Page 14 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 Q = l/min 9 12 15 18 21 24 27 30 Q = l/sec Raindance Rainfall = Rain = Rainflow Raindance Select S 120 = Rain = Rain...
- Page 15 iBox universal DN 20 01800187 (3/4") i n fl 15932007 + 15930187 Quattro 15972007 + 15970180 28430007 Highflow 15741007+ 01800187...
-
Page 16: Warranty
中文 English 汉斯格雅产品的清洁建议 Cleaning Recommendation for Hansgrohe Products Today, modern sanitary and kitchen tapware, showers, accessories, washstands, 现代的卫浴龙头、厨房龙头、花洒、配件、盥洗台、浴盆和加热器采用的 tubs and radiators consist of very different materials to comply with the needs of the 制造材料非常迥异，以适应产品外形设计和使用功能的市场需求。 market with regard to design and functionality. 为了避免产品损坏和由此引发的投诉及争议，必须在使用和清洁产品时遵 To avoid damage and reclamations, it is necessary to consider certain criteria when 循有关规程。 cleaning. With regard to caring for the Hansgrohe products, the 在保养汉斯格雅产品时，原则上必须注意： following must in principle be heeded: • 只能使用那些有明确注明是适用于本产品的清洁剂。 • Only use cleaning material which is explicitly provided for this type of application. • 不允许使用含有盐酸、蚁酸、氯漂或醋酸的清洁剂，因为这些清洁剂会 给产品表面造成严重的损伤。 • Never use cleaning materials, which contain hydrochloric acid, formic acid, chlorine pale lye or acetic acid, as they cause considerable damage. • 含磷酸的清洁剂必须在特定条件下使用。... - Page 18 SW 4 mm SW 2 mm 98513000 SW 4 mm 98133000 (16x2) 98181000 (18x2)
- Page 19 SW 4 mm (5 Nm) ( 2 N SW 5 mm (2 Nm)
- Page 20 98513000 95170000 98133000 (16x2) 95659000 98214000 (12x2) 98181000 (18x2) 96525000 (M5x20) 92137000 93246000 92246000 97767000 (M4x6) 92247000 92247400 95794000 98133000 (16x2) 13595000 (25 mm) 95521000 Hansgrohe · Auestraße 5 – 9 · D-77761 Schiltach · Telefon +49 (0) 78 36/51-1282 · Telefax +49 (0) 7836/511440 E-Mail: info@hansgrohe.com · Internet: www.hansgrohe.com...
