Whale EP1632 Manual

High Flow Watermaster Pump with Intelligent Control (IC)
INSTALLATION & USER INSTRUCTIONS
Thank you for purchasing this Whale® product.
For over 40 years, Whale® has led the way in the design and manufacture of freshwater and waste systems
including: pumps, plumbing faucets, showers for low voltage applications. The company and its products have built a
reputation for quality, reliability and innovation backed up by excellent customer service.
Typical Installation
The Watermaster® IC is designed for use in recreational vehicles to simplify the supply of freshwater to caravans
and motorhomes, where a Whale® High Flow Watermaster® pump is used to supply the taps and showers.
The Watermaster® socket (already installed or available separately) must be mounted so that the rear of the socket
is accessible from within the vehicle.
Ensure at least 30mm clearance below the socket to allow for wiring. Following a "once only" calibration the
Watermaster® IC unit removes the need for adjustment of the pressure switch, removes the requirement to have a
surge damper in the system and switches off the pump when it runs dry. For information on our full product range
visit: www.whalepumps.com
This product is designed for use with freshwater. If it is intended for use with any other liquid, it is the user's
responsibility to ensure that the materials are fully compatible with the liquids to be used and that a system of safe
working practice is applied to installation, use and maintenance.
SPECIFICATION
Product Codes
Voltage
Nominal Current
Recommended Fuse Size
Weight
Materials
Accessories
Service Kits
Performance Data @ 13.6V
Discharge Head -
0 m (0ft)
1 m (3ft)
3 m (9ft)
Compatible Pumps
Operating Temperature Range
Storage Temperature Range
EP1632
Voltage range 9.5V d.c. to 14.5V d.c. (normal operation)
Voltage range 8.5V d.c. to 9.5V d.c. (limited operation, see Section 1)
Operating 3.7 Amps
Standby 0.007 Amps
5 Amp automotive
0.65kg
Pump Body: ABS, Seals: Nitrile®, Strainer: Polypropylene
Impeller: PBT, Cable: PVC, Grease Seal: Nitrile®
Wire: PVC insulated copper, Hose: PVC, Plug: PBT
Watermaster IC: Polycarbonate
WF1230 – inline water filter (available separately)
Watermaster® IC is not a serviceable part
EP1612 - Replacement High Flow plug and pump kit
Flow Rate Per Minute / Current Draw -
15.8 ltrs / 3.8 amps
14.8 ltrs / 3.7 amps
12.8 ltrs / 3.5 amps
For use with Whale® High Flow Watermaster® (EP1612) only
3ºC to 40ºC
-30ºC to 60ºC
EP1632
