ERNITEC V2000 Setup Manual

Package Content
Inspect the packaging carton. Make sure the DVR is properly delivered. Remove all items from the
box and make sure the box contains the following items.
EDNS Vseries DVR
Front Panel
1 MODE
2 PLAY/STOP
3 FREEZE
4 SEQUENCE
5 SEARCH
6 MENU
7 Channels
8 Power LED
9 Alarm LED
10 Network LED
11 Record LED
12 Power Key
13 DOME(PTZ)
14 COPY
15 CALL
16 Direction Keys
Ernitec EDNS V2000 DVR
Setup Guide
SATA Cable
Press this key to view in full-screen or multiple window modes.
Press once to start the playback of recorded video. Press again to exit.
Press this key to freeze the current viewing screen.
Press this key to start automatic sequence display of cameras.
Press this key to search recorded video by date/time or event.
Press this key to enter the OSD setup menu.
1. In Live and Playback modes, press any key to view the corresponding
video in full-screen.
2. In input interface, 1~10 can be used for direct input of numbers 0~9.
3. In Dome Camera Control mode, 1 is for entering the Set/ Go preset
menu; 11~16 is for quick access of preset points 1~6.
It lights up when power source is connected.
It lights up when an alarm is triggered.
It lights up when network is connected. In addition, it blinks when data is
being transmitted via the network.
It blinks when videos are being recorded.
Press and hold this key to trigger the quick shutdown function.
Press this key to enter Dome Camera Control mode.
This key is used for marking time in quick video export function.
Press this key to enter Call Monitor Control mode.
1. In Zoom mode, these keys function as normal direction keys.
2. In the OSD setup menu, the direction keys are used to move the
cursor to previous or next fields. To change the value in the selected
field, press UP / DOWN keys.
Power
Power Cord
Adaptor
User's
Manual
1
