- Page 1 Network Video Recorder Quick Start Guide MVINVR-08POE4MP-E...
-
Page 2: Table Of Contents
Network Video Recorder Quick Start Guide TABLE OF CONTENTS Chapter1 Panels Description .......................... 6 1.1.1 MVINVR-08POE04MP-E ......................6 1.2 Rear Panel ............................6 1.2.1 MVINVR-08POE04MP-E ......................6 Chapter 2 Installation and Connections ......................8 2.1 Installation ............................8 2.2 Hard Disk Installation .......................... 8 2.2.1 MVINVR-08POE04MP-E ...................... - Page 3 Network Video Recorder Quick Start Guide Quick Start Guide About this Manual This Manual is applicable to Network Video Recorder (NVR). The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
-
Page 4: Regulatory Information
Network Video Recorder Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 5 Network Video Recorder Quick Start Guide Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text. Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results.
-
Page 6: Safety Instructions
Network Video Recorder Quick Start Guide Safety Instructions Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region. -
Page 7: Chapter1 Panels Description
Network Video Recorder Quick Start Guide Chapter1 Panels Description 1.1.1 MVINVR-08POE04MP-E Figure 1-1 MVINVR-08POE04MP-E Table 1-1 Panel Description No. Name Connections POWER Turns green when NVR is powered up. Flickers red when data is being read from or written to HDD. Flickers blue when network connection is functioning Tx/Rx properly. - Page 8 Network Video Recorder Quick Start Guide Figure 1-3 Panel Description No. Name Description Audio In RCA connector for audio input. Audio Out RCA connector for audio output. VGA Interface DB9 connector for VGA output. Display local video output and menu. HDMI Interface HDMI video output connector.
-
Page 9: Chapter 2 Installation And Connections
Network Video Recorder Quick Start Guide Chapter 2 Installation and Connections 2.1 Installation During installation of the NVR: Use brackets for rack mounting. Ensure ample room for audio and video cables. When routing cables, ensure that the bend radius of the cables are no less than five times than its diameter. - Page 10 Network Video Recorder Quick Start Guide Figure 2-2 Insert Panel Key Step 3 Press the buttons on the panel of two sides and open the front panel. Figure 2-3 Open Panel Lock Step 4 Insert the hard disk along the slot until it is placed into position. Figure 2-4 Insert Hard Disk Step 5 Repeat the above steps to install other hard disks onto the NVR.
-
Page 11: Other Models
Network Video Recorder Quick Start Guide Figure 2-5 Lock Panel 2.2.2 Other Models Purpose: The following section introduces the HDD installation for the MVINVR-08POE04MP-E and DS-7700NI series NVR. Take the example of MVINVR-08POE04MP-E to describe installation steps. Step 1 Remove the cover from the NVR by unfastening the screws on the rear and side panel. Figure 2-6 Remove Cover Step 2 Connect one end of the data cable to the motherboard of NVR and the other end to the HDD. - Page 12 Network Video Recorder Quick Start Guide Figure 2-8 Connect Power Cable Step 4 Place the HDD on the bottom of the device and then fasten the screws on the bottom to fix the HDD. Figure 2-9 Fix Hard Disk...
-
Page 13: Connections
Network Video Recorder Quick Start Guide 2.3 Connections 2.3.1 Alarm Input Wiring The alarm input is an open/closed relay. To connect the alarm input to the device, use the following diagram. If the alarm input is not an open/close relay, please connect an external relay between the alarm input and the device. -
Page 14: Alarm Connection
Network Video Recorder Quick Start Guide If you connect an AC load to the alarm output 3 of the NVR, then you must remove the JP 3 jumper. 2.3.3 Alarm Connection To connect alarm devices to the NVR: Step 1 Disconnect pluggable block from the ALARM IN /ALARM OUT terminal block. Step 2 Unfasten stop screws from the pluggable block, insert signal cables into slots and fasten stop screws. -
Page 15: Hdd Storage Calculation Chart
Network Video Recorder Quick Start Guide 2.4 HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used 128K 160K 192K 224K... -
Page 16: Chapter 3 Menu Operation
Network Video Recorder Quick Start Guide Chapter 3 Menu Operation 3.1 Start up Your Device Proper startup and shutdown procedures are crucial to expanding the life of the NVR. To start your device: Step 1 Check the power supply is plugged into an electrical outlet. It is HIGHLY recommended that an Uninterruptible Power Supply (UPS) be used in conjunction with the device. -
Page 17: Configure Unlock Pattern For Login
Network Video Recorder Quick Start Guide We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your product. -
Page 18: Login To The System
Network Video Recorder Quick Start Guide Connect at least 4 dots to draw the pattern. Each dot can be connected for once only. Step 3 Draw the same pattern again to confirm it. When the two patterns match, the pattern is configured successfully. -
Page 19: Enter Wizard To Configure Quick Basic Settings
Network Video Recorder Quick Start Guide 3.5 Enter Wizard to Configure Quick Basic Settings The Setup Wizard can walk you through some important settings of the device. By default, the Setup Wizard starts once the device has loaded. Check the checkbox to enable Setup Wizard when device starts. Click Next to continue the setup wizard. -
Page 20: Add Ip Cameras
Network Video Recorder Quick Start Guide Figure 3-5 Network Settings Step 2 Select the General tab. Step 3 In the General Settings interface, you can configure the following settings: NIC Type, IPv4 Address, IPv4 Gateway, MTU and DNS Server. Step 4 If the DHCP server is available, you can check the checkbox of DHCP to automatically obtain an IP address and other network settings from that server. -
Page 21: Start Live View
Network Video Recorder Quick Start Guide Figure 3-6 Add IP Camera Step 3 Enter IP address, protocol, management port, and other information of the IP camera to add. Step 4 Enter the login user name and password of the IP camera. Step 5 Click Add to finish the adding of the IP camera. -
Page 22: Recording Settings
Network Video Recorder Quick Start Guide Purpose: The device supports the RAID storage function. Through one-touch configuration, you can quickly create the disk array. By default, the array type to be created is RAID 5. Before you start: Enable RAID function. ... -
Page 23: Playback
Network Video Recorder Quick Start Guide Option 2: Step 1 Go to Storage > Recording Schedule. Step 2 Select a camera. Step 3 Check the Enable Schedule. Step 4 Select a Record Type. The record type can be Continuous, Motion Detection, Alarm, Motion | Alarm, Motion &... - Page 24 Network Video Recorder Quick Start Guide Step 3 Select a date in the calendar. Use the toolbar in the bottom part of playback interface to control the playing and realize a series of operations. Click the channel(s) to perform simultaneous playback of multiple channels. Figure 3-9 Playback Interface...
-
Page 25: Chapter 4 Access By Web Browser
Network Video Recorder Quick Start Guide Chapter 4 Access by Web Browser You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. - Page 26 Network Video Recorder Quick Start Guide If the device is already activated, enter the user name and password in the login interface, and click the Login button. Figure 4-2 Login Step 3 Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in.
- Page 27 Network Video Recorder Quick Start Guide MVINVR-08POE04MP-E_18V1_QIG...
