- Page 1 Designing, Manufacturing and Supplying WB Series Electric Isolated Sensor and Digital Electrical Transducer since 1989 USER USER MANUAL MANUAL USER USER MANUAL MANUAL WBP214P7 WBP214P75 5 5 5 active active power transducer WBP214P7 WBP214P7 active active power power power transducer...
- Page 2 Application Application Application WBP214P75 adopts special made isolation module, professional MCU controller and the technologies of fast speed data synchronizing sampling and processing to isolate and convert active power from three-phase three-wire electric circuit into a load independent output DC average current signal 4-20mA.
- Page 3 WBP214P75 has certain advantages of input/output isolation, high performance, low drifting by temperature, and low power consuming, etc. Product Dimensional Drawing (unit: Product Product Product Dimensional Dimensional Dimensional Drawing Drawing Drawing (unit: (unit: (unit: mm) Product Product Terminal Terminal Identification...
- Page 4 20 times of nominal input current, continuous. 9. Output impedance: 6V 10. Auxiliary Power: +12Vdc/+24Vdc 11. Current consumption for static status: 12. Isolation Voltage(Input/Output/Power): 1500V , for 1 minute 13. Output Ripple: ＜10mV ≤1.0×10 14. Drifting by Temperature: /℃ 15. Ambient Temperature: -10℃～+50℃...
- Page 5 Auxiliary power: 24V±0.5％，ripple≤5mV Ambient temperature: 25℃±2℃ Relative humidity : RH(45～75)％ Accuracy for Signal Power Source instrument: 0.05 Auxiliary Power Three Phase 250Ω Calibration Meter Transducer (3) Warming up the transducer for 3 minutes (4) Based on the indication of 3-phase AC Calibration Meter, set one set of input value which is within the measuring range of the transducer Ur (line voltage), Ir, COSφ, and the 3-phase input is balanced.
- Page 6 Don’t dismantle the product, and carry with care to avoiding bump and fall of the product; If the product has been using under the environment with strong magnetic field interference, please pay attention to the shield of input wire, and the output signal wire should be as short as possible.
