Heating Input : 60,000 - 80,000 BTU/h
Standard Features
• Integrated communicating ComfortBridge™ Technology
• Commissioning and diagnostics via indoor board Bluetooth
with the CoolCloud™ phone and tablet application
• Heavy-duty stainless-steel, dual-diameter tubular
heat exchanger
• Single-stage gas valve
• Durable Hot-surface igniter
• Quiet, modulating draft inducer
• Self-diagnostic control board
• Variable-speed ECM blower motor
• Eligible for installation in California's South Coast Air
Quality Management District (SCAQMD) and San
Joaquin Valley Air Pollution Control District (SJVUAPCD).
This furnace complies with the 14 ng/J NOx emission
limit in SCAQMD Rule 1111 and SJVUAPCD Rule 4905.
• EMI line filter kit must be installed. (It is intended for
field installation only on "VS" model, Bluetooth® capable
Ultra Low NOx Gas Furnaces. The purpose of the EMI
Filter is to reduce electromagnetic interference between
the furnace and other electrical devices)
• AHRI Certified; ETL Listed
SS-AMVS80-U
Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Manufacturing Company, L.P., Houston, Texas.
Single-Stage, Variable-Speed ECM,
Multi-Position, Ultra-Low NOx
Cabinet Features
• Installation: upflow, horizontal left or right
• Convenient left or right connection
for gas and electrical service
• Heavy-gauge steel cabinet with
durable baked-enamel finish
• Foil faced insulated heat exchanger
* Complete warranty details available from your local dealer or at www.amana-hac.com. To receive the Lifetime Unit Replacement
Limited Warranty, Lifetime Heat Exchanger Limited Warranty (in each case, good for as long as you own your home), and 10-Year
Parts Limited Warranty, online registration must be completed within 60 days of installation. Online registration is not required in
California or Quebec.
www.amana-hac.com
AMVS80-U
Gas Furnace
80% AFUE
Contents
Nomenclature ........................................ 2
Product Specifications ........................... 3
Dimensions ............................................ 4
Airflow Data ........................................... 5
Wiring Diagrams .................................... 7
Accessories ............................................ 8
Minimum Filter Sizes ............................ 8
2/21
Supersedes 6/20
Advertisement
Related Manuals for Amana AMVS80-U
Summary of Contents for Amana AMVS80-U
-
Page 1: Table Of Contents
Parts Limited Warranty, online registration must be completed within 60 days of installation. Online registration is not required in California or Quebec. SS-AMVS80-U www.amana-hac.com 2/21 Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Manufacturing Company, L.P., Houston, Texas. Supersedes 6/20... -
Page 2: Nomenclature
Nomenclature 7,8,9 13,14 Brand Engineering A - Amana® Brand Major /Minor Revisions * Not used for inventory control. Configuration M - Upflow/Horizontal N - Natural Gas C - Downflow/Horizontal X - Low NOx U - Ultra-Low NOx Motor Cabinet Width V - Variable Speed ECM / ComfortBridge™... -
Page 3: Product Specifications
AMVS80-U Product Specifications AMVS80 AMVS80 0604BU* 0805CU* Heating Capacity Input 60,000 80,000 Natural Gas Output 48,000 64,000 AFUE ¹ Available AC @ 0.5” ESP 1.5 - 4.0 2.0 - 5.0 Temperature Rise Range (°F) 20 - 50 35 - 65... -
Page 4: Dimensions
AMVS80-U Dimensions Alternate Gas Inlet Alt. Flue Outlet — Horizontal Left 1¾” 1 ⁄ ” 19½” ➤ 33⅜” Alt. Gas Inlet 27⅞” 20” 23 ⁄ ” Alt. High Voltage High-Voltage Inlet 15” 13¼” Low-Voltage Inlet Alt. Low Voltage 23” ➤... -
Page 5: Airflow Data
AMVS80-U Heating Airflow Data AMVS800604BU AMVS800805CU MODEL / TEMP RISE RANGE (MID RISE) 20-50 (35) 35-65-(50) RISE RISE 1760 (MAX Recommended CFM & Expected Temperature Rise 1524 CAPABLE CFM) Minimum Recommended Heating CFM & Expected 1067 1422 Temperature Rise Maximum Recommended Heating CFM & Expected... - Page 6 Temperature Rise Range Chart www.amana-hac.com SS-AMVS80-U...
-
Page 7: Wiring Diagrams
Wiring Diagram MOB_PE LEFT CENTER RIGHT GV (13) DATA AC BREAK OFF BREAK OFF TABS TABS 2 R C R C G W Y SS-AMVS80-U www.amana-hac.com... -
Page 8: Accessories
Use 2 - 16 x 25 filters on side returns or 20 x 25 filter on bottom return if furnace is connected to a cooling unit over 4 tons nominal capacity. Amana® is a registered trademark of Maytag Corporation or its related companies and is used under license. All rights reserved.
