- Page 1 How to install the divider kit on the drawer 160...
-
Page 2: Upper Drawer
Upper drawer... - Page 3 Insert the long grid in the preset holes...
- Page 4 Use the positioning grid to keep the long grid in place...
- Page 5 Center the long grid and position it parallel to the bottom...
- Page 6 Mark the position of the holes to fix the dividing grid...
- Page 7 Use Ø4mm drill...
- Page 8 Use the plastic rivets to fix the dividing grid...
- Page 9 Put the top basket in. The installation for the upper drawer is over...
-
Page 10: Lower Drawer
Lower drawer... - Page 11 Put the short grid in and use both dividing grids to keep it in place. Center the short grid...
- Page 12 If possible remove the door and put it on a flat surface to ease the installation process. Put the dividing grid parallel to the drawer and center it to the short grid...
- Page 13 Mark the position of the holes to fix the dividing grid...
- Page 14 Use Ø4mm drill...
- Page 15 Use the plastic rivets to fix the dividing grid...
- Page 16 Repeat the operation for the other grid keeping in mind that the holes will run through the back of the drawer...
- Page 17 Once the installation of the other grid is done the fridge is ready to be used...
