5 Connector Pinouts

USB Connector (type B)
Pin No.
Serial Connector (DB9F)
Pin No.
Signal Name
1
VBUS
2
3
4
GND
Signal Name
1
DCD
2
3
4
5
GND
6
DSR
7
8
9
D-
D+
TxD
RxD
DTR
CTS
RTS
RI
17
