  • Page 1 EW9H3866MB Tumble Dryer User Manual...

  • Page 2: Table Of Contents

    1369/2017......................23 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
  • Page 4 1.2 General Safety Do not change the specification of this appliance. • If the tumble dryer is put on top of a washing machine, • use the stacking kit. The stacking kit, available from your authorized vendor, can be used only with the appliance specified in the instructions supplied with the accessory.

  • Page 5: Safety Instructions

    ENGLISH Items that have been soiled with substances such as • cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer. Items such as foam rubber (latex foam), shower caps, •...
  • Page 6 2.5 Care and cleaning • Always use a correctly installed shockproof socket. • Do not use multi-plug adapters and WARNING! extension cables. Risk of injury or damage to • Do not pull the mains cable to the appliance. disconnect the appliance. Always pull •...

  • Page 7: Product Description

    ENGLISH 3. PRODUCT DESCRIPTION Water container Control panel Internal light Appliance door Filter Rating plate Airflow slots Heat Exchanger lid Heat Exchanger cover Adjustable feet For ease of loading laundry or ease of installation the door is reversible. (see separate leaflet). 4.
  • Page 8 Press the touch buttons with your finger in the area with the symbol or name of the option. Do not wear gloves when you operate the control panel. Make sure that the control panel is always clean and dry.

  • Page 9: Programme Table

    ENGLISH 5. PROGRAMME TABLE Programme Load Properties / Fabric type Cycle to be used to dry cotton with "cotton cupboard" dryness 8 kg Cotton Eco level, with maximum energy sav‐ ing. Cycle defined to dry all types of Cotton 8 kg cotton ready to store (cupboard dry).

  • Page 10: Options

    Programme Load Properties / Fabric type Outdoor clothing, technical, sports fabrics, waterproof and breathable jackets, shell jackets 2 kg Outdoor with a removable fleece or inner insulation. Suitable for drying in tumble dryer. Leisure clothing such as jeans, sweat-shirts of different material...
  • Page 11 ENGLISH 6.6 Reverse Plus 6.7 Extra Silent Increase drum reversing frequency to The appliance operates with low noise reduce items twisting and entanglement. without effect on the drying quality. The To increase uniformity of drying result appliance operates slowly with longer and help reduce creases.

  • Page 12: Settings

    7. SETTINGS 7.2 Adjustment of the remaining moisture Every time you enter in the "Adjustment of remaining laundry moisture" mode, previously set degree of remaining moisture will change into next value ( e.g previously set will A. Time Dry touch button change into B.

  • Page 13: Before First Use

    ENGLISH Dryness level Display symbol Deactivating the water container indicator: maximum dryness 1. Press the on/off button to activate the appliance. more dry 2. Wait approximately 8 seconds. laundry 3. Press and hold touch buttons (H) and (G) at the same time. standard The display shows one of these 2 dry laundry...
  • Page 14 9.4 At the end of the 3. Set the correct programme and options for the type of load. programme The display shows the programme duration. When the programme is completed: • An intermittent acoustic signal The drying time you see on operates.

  • Page 15: Hints And Tips

    ENGLISH The time is reduced to 30 seconds if the selector knob is pointing to "Reset" position. 10. HINTS AND TIPS 10.1 Preparing the laundry • Use suitable programme for cottons, jersey and knitwear to reduce • Close the zips. shrinkage.
  • Page 16 5. 1) 1) If necessary remove fluff from the filter socket and gasket. You can use a vacuum cleaner. 11.2 Emptying the water container You can use the water from the water container as an alternative to distilled water (e.g.
  • Page 17 ENGLISH 11.3 Cleaning the Heat Exchanger...

  • Page 18: Troubleshooting

    11.5 Cleaning the control panel CAUTION! and housing Do not touch the metal surface with bare hands. Use a standard neutral soap detergent to Risk of injury. Wear clean the control panel and housing. protective gloves. Clean Use a moist cloth to clean. Dry the carefully to avoid damaging the metal surface.

  • Page 19: Technical Data

    ENGLISH Problem Possible solution Make sure that the filter is clean. The laundry is too wet. Spin the laundry in the washing machine again. Ensure that the room temperature is higher than +5°C and lower than +35°C. Optimal room temperature is 19°C to 24°C.
  • Page 20 Total power 700 W Energy efficiency class A+++ Energy consumption on the standard cot‐ 1,47 kWh ton programme with the full load. Energy consumption on the standard cot‐ 0,83 kWh ton programme with the partial load. 176,50 kWh Annual energy consumption...

  • Page 21: Quick Guide

    ENGLISH Energy Drying consump‐ Programme Spun at / residual humidity time tion Iron Dry 1400 rpm / 50% 120 min. 0,94 kWh 1000 rpm / 60% 137 min. 1,12 kWh Cotton Eco 4 kg Cupboard Dry 1400 rpm / 50% 93 min.
  • Page 22 14.2 Cleaning the filter At the end of each cycle the filter symbol appears on the display and you must clean the filter. 14.3 Programme table Programme Properties / Fabric type Load Cycle to be used to dry cotton with "cotton cupboard"...

  • Page 23: Product Information Sheet In Reference To E.u. Regulation 1369/2017

    15. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION 1369/2017 Product Information Sheet Trade Mark Electrolux Model EW9H3866MB, PNC916098182 Rated capacity in kg Air vented or condenser tumble dryer Condenser Energy efficiency class A+++ Energy consumption in kWh per year, based on 160 dry‐...
  • Page 24 The 'standard cotton programme' used at full and partial load is the standard drying programme to which the infor‐ mation in the label and the fiche relates, this programme is suitable for drying normal wet cotton laundry and it is the most efficient programme in terms of energy consumption for cotton.
  • Page 25 ENGLISH...
  • Page 26 www.electrolux.com...
  • Page 27 ENGLISH...
  • Page 28 www.electrolux.com/shop...
