- Page 1 EN User Manual | Tumble Dryer EW9H679E7...
-
Page 2: Table Of Contents
Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. PRODUCT DESCRIPTION................8 4. CONTROL PANEL..................9 5. - Page 3 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability. • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
- Page 4 similar accommodation where such use does not exceed (average) domestic usage levels. • Do not change the specification of this appliance. • If the tumble dryer is put on top of a washing machine, use the stacking kit. The stacking kit, available from your authorized vendor, can be used only with the appliance specified in the instructions supplied with the accessory.
-
Page 5: Safety Instructions
• WARNING: Do not damage the refrigerant circuit. • If the mains power supply cable is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard. • Do not exceed the maximum load of 8,0 kg (refer to the "Programme chart"... - Page 6 2.3 Use The appliance contains flammable gas, propane (R290), a gas with a high level of environmental compatibility. Keep fire and WARNING! ignition sources away from the appliance. Risk of injury, electric shock, fire, burns Be careful not to cause damage to the or damage to the appliance.
- Page 7 of environmental compatibility. Keep fire and These lamps are intended to withstand ignition sources away from the appliance. Be extreme physical conditions in household careful not to cause damage to the refrigerant appliances, such as temperature, circuit containing propane. vibration, humidity, or are intended to signal information about the operational •...
-
Page 8: Product Description
Access your appliance details, documentation and articles on how to use the best features (User Manual also available at electrolux.com/manuals ) • Get usage advice, troubleshooting, service and repair information (also available at electrolux.com/ support ) • Buy accessories, Consumable and Original Spare parts for you appliance (also available at electro‐... -
Page 9: Control Panel
4. CONTROL PANEL Programme knob and RESET switch Extra Silent touch button Extra Anticrease touch button On/Off button Dryness Level touch button Display Press the touch buttons with your finger Time Dry touch button in the area with the symbol or name of the option. -
Page 10: Programme Table
Symbol on the display Symbol description clean filter indicator: drain the water container indicator: child lock on wrong selection or knob is in the "Reset" position indicator: drying phase cooling phase indicator: anti-crease phase indicator: programme duration extension of default anti-crease phase: +30min, +60min, +90min, +2h) time drying selection (10min-2h) delay start selection (1h-20h) - Page 11 Load 1) Properties / Fabric type 2) Programme Gently dries for machine and hand-washable woollens. Re‐ move immediately the items when the programme is comple‐ ted. 1 kg Wool The wool drying cycle of this machine has been approved by The Woolmark Company for the drying of wool garments la‐...
-
Page 12: Options
6. OPTIONS 6.1 Extra Anticrease TIME DRYING RECOMMENDATION Extends the anti-crease phase by 30,60, 90 minutes or 2 hours at the end of the drying full drying of the cycle. This function reduces creases. The small laundry loads >40 min laundry can be removed during the anti- up to 4 kg, well spun (>1200 rpm). -
Page 13: Settings
Extra An‐ Extra Si‐ Reverse Programmes 1) Dryness Level Time Dry ticrease lent Plus Cottons ■ ■ ■ ■ ■ ■ ■ Synthetics ■ ■ ■ ■ ■ ■ ■ Delicates ■ ■ Duvet ■ Refresh ■ ■ ■ Silk ■... - Page 14 7.2 Adjustment of the remaining standard dry moisture laundry 7.3 Water container indicator Every time you enter in the "Adjustment By default, the water container indicator is on. of remaining laundry moisture" mode, It comes on when the programme is previously set degree of remaining completed or when it is necessary to empty moisture will change into next value ( e.g...
-
Page 15: Before First Use
the display shows the text Hr for 2 To activate this option follow steps below: seconds then 12 for 2 seconds followed 1. Switch the appliance on by pressing by 76. This value is displayed with a On/Off button. sequence of two digits at a time: the first 2. -
Page 16: Daily Use
Working pump and transferring condensation to the tank. Working fans. 9. DAILY USE 9.1 Start a programme without delay start Real drying time will depend on type of 1. Prepare the laundry and load the the load (quantity and composition), the appliance. - Page 17 9.3 Change a programme • Start/Pause indicator goes off. 1. Press the on/off button to deactivate the 1. Press the on/off button to deactivate appliance. appliance 2. Open the appliance door. 2. Press the on/off button to activate the 3. Remove the laundry. appliance.
-
Page 18: Hints And Tips
10. HINTS AND TIPS 10.1 Preparing the laundry • Remove all items from pockets. • Turn items with the internal layer made of cotton inside out. Cotton layer must be faced outwards. Loading the drum up to the maximum • Always set the programme suitable for the capacity indicated for the respective type of laundry. - Page 19 Empty the water container When the indicator flashes Clean the Heat Exchanger When the indicator flashes Clean the humidity sensor At least 3 or 4 times a year Clean drum Every two months Clean the control panel and housing Every two months Clean the airflow slots Every two months The following paragraphs explain how you should clean each part.
- Page 20 position. 4. To continue the programme press the Start/Pause button. 11.5 Cleaning the condenser If the symbol of the condenser flashes on the display, inspect the condenser and its compartment. If it is dirty, clean it. Do the check not less than once a 6 months. 11.4 Emptying the water container Empty the condensed water container after WARNING!
- Page 21 2. Open the condenser cover. 7. Put the filter back. 3. Turn the levers to unlock the condenser lid and lower the condenser lid. . 11.6 Cleaning the humidity sensor CAUTION! Risk of humidity sensor damage. Do not use abrasive materials or steel wool to clean the sensor.
-
Page 22: Troubleshooting
11.7 Cleaning the drum Use a moist cloth to clean. Dry the cleaned surfaces with a soft cloth. WARNING! CAUTION! Disconnect the appliance before you Do not use furniture cleaning agents or clean it. cleaning agents which can cause corrosion. Use a standard neutral soap detergent to clean the inner surface of the drum and drum 11.9 Cleaning the airflow slots... - Page 23 Error code Possible cause Remedy The mains supply is unstable. When the appliance is showing EH0, please wait until main supply is stable than press start. If the appliance paused the cycle with‐ out any indication then press the cycle start. If the warning will occur again check the power cord / socket integrity or main supply.
-
Page 24: Technical Data
• Incorrect setting of the conductivity sensor If the drying results are not satisfactory OPTIONS: Dryness Level - ( See chapter " Adjustment of target final moisture " for • The set programme was incorrect. better setting). • The filter is clogged. •... - Page 25 Weight 0,149 kg With reference to EN 61121. 8,0 kg of cotton centrifuged at 1000 rpm. With reference to EN 61121. 4,0 kg of cotton centrifuged at 1000 rpm. Energy consumption per year in kWh, based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of the low-power modes.
-
Page 26: Quick Guide
14. QUICK GUIDE 14.1 Daily use 1. Push the On/Off button to turn on the deactivate an option touch the relevant appliance. button. 2. Use the programme dial to set the 4. To start the programme , Touch the Start/ programme. - Page 27 14.3 Programme table Load 1) Properties / Fabric type 2) Programme Cotton fabrics programme designed for 8,0 kg Cottons Eco maximum energy saving. Cycle defined to dry cottons items of differ‐ Cottons 8,0 kg ent size / different weaving altogether. Blended garments containing mostly syn‐...
-
Page 28: Product Information Sheet In Reference To E.u. Regulation 1369/2017
15. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION 1369/2017 Product Information Sheet Trade Mark Electrolux Model EW9H679E7 PNC916900056 Rated capacity in kg Air vented or condenser tumble dryer Condenser Energy efficiency class A+++ Energy consumption in kWh per year, based on 160 drying cycles of the standard... -
Page 29: Environmental Concerns
The 'standard cotton programme' used at full and partial load is the standard dry‐ ing programme to which the information in the label and the fiche relates, this programme is suitable for drying normal wet cotton laundry and it is the most effi‐ cient programme in terms of energy consumption for cotton. - Page 32 136206010-A-072024...
