8. Verify and/or adjust all other lock parameters. (See LockView Instruction Manual for complete details.)
9. Click OK when done.

Manual Method

1. Login to LockView.
2. Go to Lock/User Editor; Lock Editor tab and click Add Lock.
3. Enter the required information: Lock Name; Lock Serial Number and Setup Code (supplied on green sticker set as Setup Cd).
4. Verify and/or adjust all other lock parameters and click OK. (See LockView Instruction Manual for complete details on these
options)
5. With the eLock in SETUP mode, connect the eLock via the USB cable to the computer on which LockView is installed.
6. After 30 seconds, the lock will be updated in LockView. Click Refresh to prompt the update.
NOTE: After 5 minutes of inactivity, the eLock will exit SETUP mode.

Section 8: LED Behavior

Each electronic lock membrane Keyhpad has a green, red and yellow LED.
During general lock use:
• Key press = 1 RED flash
Supervisor = Flash GREEN (2 blink pattern x 9)
•
User = Solid GREEN
•
Dual Credential Supervisor = Alternate RED & GREEN after first credential; flash GREEN (2 blink pattern x 9) after secondary PIN
•
Dual Credential User = Alternate RED & GREEN after first credential; solid GREEN after secondary PIN.
•
• Low Battery = Flash YELLOW
Note: Installation Of Poly Shelf And Basket Shelf
© 2019 InterMetro Industries Corporation, Wilkes-Barre, PA 18705
L01-652 REV B 01/20
On These Locations (Behind The Lock
Cover), Do Not Install Poly Shelf And
Basket Shelf.
