- Page 1 UWC2XL OWNER’S MANUAL 7/2019 WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury.
- Page 2 Limited to the warranty periods below, METAL MAN WORK GEAR CO will repair or replace the item under warranty that fails due to defects in material and workmanship. METAL MAN WORK GEAR CO must be notified within 30 days of the failure, so as to provide instructions on how to proceed with the repair of your unit and warranty claim processing.
- Page 3 GENERAL SAFETY RULES WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in serious injury or death. CAUTION: Do not allow persons to operate or assemble this unit until they have read this manual and have developed a thorough understanding of how this unit works. WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur.
- Page 4 Caster DESCRIPTION The METAL MAN UWC2XL Universal Welding Cart w/Handle is designed to hold portable wire welders, plasma cutters and TIG Welders. This cart features a fold down handle for easy towing of your welding unit. It also has a set of cable wraps on each side for easy and safe storage of your welding cables.
- Page 5 ASSEMBLY CONTINUED 7. Use 4 of the self-tapping screws to secure the bottom shelf to the frame using the pre-drilled holes in the bottom shelf and frame. 8. Located the pre-drilled holes in the side of the frame supports at the back. Slide the axle through the pre-drilled holes in the side of the frame supports.
- Page 6 DIAGRAM & PARTS LIST Page of 8...
- Page 7 Reference # Part# Description Qty. 105100001 COTTER PIN 2.5 MM X 25 MM 105100002 FLAT WASHER M12 105100003 RUBBER WHEEL 150MM X 35 MM 105100005 FRAME 105100004 AXLE 105100006 BOTTOM SHELF 105100010 GAS CYLINDER SUPPORT 105100007 GAS CYLINDER RETAINING CHAIN 105100191 10MM BOLT WITH INCLUDED WASHERS 105100015...
