- Page 1 Large Cylinder Cart OWNER’S MANUAL 8/2020 WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury.
- Page 2 Limited to the warranty periods below, METAL MAN WORK GEAR CO will repair or replace the item under warranty that fails due to defects in material and workmanship. METAL MAN WORK GEAR CO must be notified within 30 days of the failure, so as to provide instructions on how to proceed with the repair of your unit and warranty claim processing.
- Page 3 GENERAL SAFETY RULES WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in serious injury or death. CAUTION: Do not allow persons to operate or assemble this unit until they have read this manual and have developed a thorough understanding of how this unit works. WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur.
- Page 4 DESCRIPTION This Large Cylinder Cart is designed for easy assembly. It holds up to 11” acetylene cylinders and up to 10” oxygen cylinders. This unit comes in two separate subassemblies for easy shipping and quick assembly. It assembles with four nuts and bolts and one axle with two washers and cotter pins.
- Page 5 ASSEMBLY 1. Remove top and bottom halves from box and place on a flat surface. 2. Remove axle, wheels, flat washers, and cotter pins. 3. Slide axle through support holes on bottom of cylinder support. 4. Place wheel over axle followed by flat washer and secure with cotter pin (Repeat for opposite side).
- Page 6 DIAGRAM & PARTS DIAGRAM...
- Page 7 Reference # Part# Description Qty. HANDLE 105100188 TOOLBOX LID 105100181 CROSS RECESSED PAN HEAD SCREW 105100182 HINGE 105100075 HEXAGON NUT 105100064 FLAT WASHER 8 125300072 HEXAGON BOLT M8*45 105100183 BOTTOM ASSEMBLY 105100193 SOLID TIRE 105100194 FLAT WASHER 20 125300078 COTTER PIN 105100001 TOP ASSEMBLY 105100195...
- Page 8 Metal Man Work Gear Company 1760 Prospect Ct #120 Appleton, WI 54914 w w w . m e t a l m a n g e a r . c o m 8 8 8 - 7 6 2 - 4 0 4 5...
