HighSecLabs Mini-Matrix SX42PH-4 Quick Installation Manual

Quick Installation Guide
4/8 Ports High Security DP/HDMI
Mini-Matrix KVM Switches
Introduction
Thank you for purchasing this HSL Secure Mini-Matrix KVM Switch. This Mini-Matrix Switch is designed for use in secure defense and intelligence
environments across wide security gaps.
Unlike a regular secure KVM switch that enables the user to view and interact with only one of the connected computers at a time, this secure
mini-matrix enables viewing two of the connected computers and interact with them easily and intuitively.
Objectives
•
This guide includes instructions for installing and basic operation of HSL's DP/HDMI Mini-Matrix SX42PH-4, SX42PHU-4, SX82PH-4, SX82PHU-
4 devices.
•
For further assistance please refer to HSL website:
•
The following diagram references the SX42PHU-4 device but it is applicable to devices covered in this manual.
SX42PHU-4 Model is shown
Rear Panel Index:
1. PC fUSB input
2. PC Keyboard/Mouse input
3. Analog audio input
4. DP/HDMI input
5. Console Mouse USB
6. Mouse LED
7. Console Keyboard USB
8. Left Display DP/HDMI Out
9. Console Keyboard LED
10. Left Display EDID LED
11. Audio out
12. fUSB LED
13. fUSB out
14. Right Display EDID LED
15. RDC in – remote AFP connection
16. Right Display DP/HDMI Out
17. DC in
Installation Precautions:
Do not connect this product to computing devices that:
•
Are TEMPEST computers
•
Include telecommunication equipment
•
Include frame grabber video cards
•
Include special audio processing cards.
©2019 All rights reserved. HSL logo and product names are trademarks or service trademarks of HighSecLabs Ltd (HSL).
All other marks are the property of their respective owners. Images for demonstration purposes only.
SX42PH-4  SX42PHU-4  SX82PH-4  SX82PHU-4
http://www.highseclabs.com
WARNING: Peripherals' Warning - For security reasons, this product
does not support wireless keyboards. It is recommended not to
connect a microphone or headset to the audio output port.
NOTE: In order to comply with the product's Common Criteria
evaluation and to prevent unauthorized administrative access to
the product, the default administrator username and password
must be changed prior to first product use.
| QUICK INSTALLATION GUIDE
HDC19961 Rev.1.0
