- Page 1 BREDEL PUMP SERIES Additional information on Bredel 40 pump with bare shaft configuration...
- Page 2 Additional Information on Bredel 40 pump with bare shaft configuration Original Instructions...
- Page 3 Watson-Marlow Bredel B.V. The information provided can be changed without prior notification. Watson-Marlow Bredel B.V. or one of its representatives cannot be held liable for possible damage resulting from use of this manual. This is an extensive limitation of the liability which...
-
Page 4: Table Of Contents
Mounting the bare shaft hub onto the pump ......... 19 Mounting the Drive ................20 Mounting the pumphead ............... 22 TROUBLESHOOTING SPECIFICATIONS Bredel 40 bare shaft set ................ 26 6.1.1 Support set ................26 6.1.2 Bare Shaft Kit ................27 Weights ....................28 Torque ....................28 Coupling .................... -
Page 5: General
Service and Support For information with respect to specific adjustments, installation, maintenance or repair jobs which fall beyond the scope of this manual, contact your Bredel representative. Make sure you have the following data at hand: • Type and / or serial number of the hose pump. -
Page 6: Used Products And The Environment
Intended Use and Remarks on Safety The bare shaft set is exclusively designed for supporting a Bredel pumphead and a drive. Every other use is not in conformance with the intended use. Refer to the manual of the pumphead for more information on... -
Page 7: Warranty Conditions
GENERAL Warranty Conditions Refer to the manual of the pumphead for warranty conditions. These conditions are applicable to the bare shaft set as well. Damaged parts of the bare shaft set that are returned to the manufacturer must be accompanied by a fully filled in and signed safety form that can be found in the manual of the pumphead. -
Page 8: Description
To align the pump and the drive use alignment jigs. The jigs are not included in the package. Destined for pump- Support set (A) Bare shaft kit (B) Coupling size (C) head Bredel 40 Bredel 40 Bareshaft Bredel 40 Support Set Bareshaft Kit... -
Page 9: Installation
Follow the unpacking instructions on the packaging. Check that your delivery is correct and does not have transport damage. Report any damage immediately to your Bredel representative. This chapter will treat the installation of the bare shaft set. Refer to the manual of the pumphead for installation and setup of the complete pump and the pipework. -
Page 10: Mounting The Support Set And The Bare Shaft Kit To The Pumphead
INSTALLATION 3.2.1 Mounting the support set and the bare shaft kit to the pumphead For mounting the kit to the pumphead, the pump must not be part of a process line and must not contain lubricant. Use a hoist to place the pumphead (A) against the support set (B). - Page 11 INSTALLATION Clean the contact surfaces (B) for the bearing and the seal. Put some transmission oil on these surfaces (B). Place the retaining ring (C) in the groove (A) of the shaft. Apply an excessive amount of grease on the seal (D).
- Page 12 INSTALLATION Place the key (A) in the shaft end. Loosen the setscrew (B) from the coupling half. Screw a threaded rod (E) into the shaft end. Place the coupling half (C) on the shaft end. Install a disc (D) and nut (F) on the threaded rod (E).
-
Page 13: Mounting And Aligning The Drive
INSTALLATION 3.2.2 Mounting and aligning the Drive Use a hoist to lift the heavy drive. Mounting and aligning the drive must be done on the pump’s final operation position. Moving the complete pump assembly after alignment will require re- alignment at the pump’s final operation position. - Page 14 INSTALLATION Place coupling half (B) on the output shaft of the drive and slightly fasten screw (C). Make sure the shaft end has been shifted far enough into the coupling half but will not penetrate into the coupling spider (A). Use a hoist to place the drive on the support set.
- Page 15 INSTALLATION Drive a pin (A) into each drilled hole to fix the horizontal plate in the support set side plates. Use two alignment jigs (D) to check the C D C E alignment of the coupling halves in the horizontal plane. Looking from above both coupling halves (C) must touch the edge of both jigs.
-
Page 16: Maintenance
MAINTENANCE MAINTENANCE Cleaning Warning When cleaning the pump do not use a high-pressure spraying pistol. This might damage the seal and the bearing. Demounting the pumphead To demount the bare shaft hub the pump must be separated from the drive. This can be done in two ways: demounting the pumphead from the support set or demounting the drive from the support set. -
Page 17: Demounting The Drive
MAINTENANCE Attach a hoist to the pumphead (A). Remove the six sets of bolts and washers (B). Move the pumphead horizontally away from the support set to separate the coupling (A). Demounting the drive To demount the bare shaft hub the pump must be separated from the drive. -
Page 18: Demounting The Bare Shaft Hub
MAINTENANCE Move the drive (C) horizontally away from the support set to separate the coupling halves (A and B). Demounting the bare shaft hub Loosen screw (B) and remove the coupling half (A). Remove key (B) from the shaft end. Remove the eight sets of washers and bolts (A). -
Page 19: Disassembling The Bare Shaft Hub
MAINTENANCE Locate the two threaded holes (A) in the hub. Place two M10 bolts (B) with a threaded length of approximately 55mm. Turn the bolts (B) until they touch the face of the pumphead to which the hub is mounted. Gently turn the bolts (A) alternately half a turn clockwise to press the hub from the pumphead. -
Page 20: Assembling The Bare Shaft Hub
MAINTENANCE Use a suitable tool (B) to press the bearing (C) out of the hub (D). The seal (A) can get damaged during this step. Remove the seal (B) from the hub (A). Assembling the bare shaft hub Check the bearing and the seal before reuse. If necessary use a new bearing and a new seal. - Page 21 MAINTENANCE Use a suitable tool to press seal (B) into hub (A) until it rests on the collar. Keep the closed side of the seal upward. Apply an excessive amount of grease on the lip seal. Use a suitable tool to press bearing (B) into hub (A) until it rests on the rim.
-
Page 22: Mounting The Bare Shaft Hub Onto The Pump
MAINTENANCE Mounting the bare shaft hub onto the pump Clean the contact surfaces (B) for the bearing and the seal. Put some transmission oil on these surfaces (B). Place the retaining ring (C) in the groove (A) of the shaft. Apply an excessive amount of grease on the seal (D). -
Page 23: Mounting The Drive
MAINTENANCE Tighten the bolt or nuts in at least two crosswise cycles. In the last cycle tighten them with the correct torque. See section 6.3. Place the key (A) in the shaft end. Loosen the setscrew (B) from the coupling half. Screw a threaded rod (E) into the shaft end. - Page 24 MAINTENANCE Slide the drive (B) toward the pumphead. Make sure that the coupling halves (A) and the spider mesh correctly. Place the fasteners (A). Do not tighten them. Use two alignment jigs (D) to check the alignment of the coupling halves (C) in the horizontal plane.
-
Page 25: Mounting The Pumphead
MAINTENANCE Mounting the pumphead Attache a hoist to the pumphead. Move the pumphead horizontally towards the support set. Make sure the coupling halves (B) and the spider mesh correctly. Place the fasteners (A). Do not tighten them. Use two alignment jigs (D) to check the alignment of the coupling halves (C) in the horizontal and vertical plane. - Page 26 MAINTENANCE Tighten the fasteners (A) with the correct torque. See section 6.3. Place the coupling guard (B). Tighten the fasteners (A) with the correct torque. See section 6.3. Connect the suction and discharge lines and open any shut-off valves in these lines. Connect the drive to the electrical supply.
-
Page 27: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING WARNING Disconnect and lock the power supply to the pump drive before any work is carried out. In case the motor is fitted with a frequency controller and has a single phase power supply, wait at least two minutes to make sure that the capacitors have discharged. - Page 28 TROUBLESHOOTING Problem Possible cause Correction Cyclic movement of the Misalignment of pumphead Check the alignment of pumphead. and drive. pumphead and drive. See chapter 3. Check the fixation of the pumphead and the drive to the support set. Check the fixation of the support set components.
-
Page 29: Specifications
SPECIFICATIONS SPECIFICATIONS Bredel 40 bare shaft set 6.1.1 Support set Pos. Qty. Description Size Material Pump support steel Gearbox support steel Coupling guard steel ISO 8750 - 8 x 24 steel Thick flat washer steel Bolt M8 x 35 steel... -
Page 30: Bare Shaft Kit
SPECIFICATIONS 6.1.2 Bare Shaft Kit Pos. Qty. Description Size Material steel Joint shaft steel Bearing 6208-2RS1 steel Radial shaft seal CR 40 x 60 x 10 - HMS5-RG Retaining Ring DIN 472 - 80 x 2.5 Steel Retaining Ring DIN 471 - AV40 Steel Parallel key DIN 6885A - 12 x 8 x 70... -
Page 31: Weights
Weights Bare Shaft Set Weights [kg] Support set Bare shaft kit Coupling* Bredel 40 44.5 *Coupling weight is an approximation. The actual weight depends on the used coupling type. Torque Following table shows general tightening torques for steel fasteners with metric thread. - Page 32 SPECIFICATIONS Coupling L [mm] E [mm] s [mm] Maximum displace- Rated size ments torque [Nm] ∆ ∆ ∆ ∆ Ka ∆ ∆ ∆ ∆ Kr ∆ ∆ ∆ ∆ Kw [mm] [mm] [degrees] -1.0 0.36 +2.1...
-
