ZyPerPad User Guide
Panel Layout
Number Name
Buttons
1
RS232
2
LAN (PoE)
3
DC 12V
4
Rev 20211006
Description
Ten buttons on front panel. Buttons are not defined
by default. Configure buttons through the web user
interface.
Connect to RS232 enabled device for RS232. (Not
used with ZyPer Management Platform)
Connect to an Ethernet switch. PoE supported.
Not required if using PoE for power. Connect to DC
12V power adapter if needed. Power adapter not
included in package.
Page
4
of
26
